FEATURES
Power dissipation
P
CM
: 0.625 W
Tamb=25
Collector current
I
CM
: 0.5 A
Collector-base voltage
V
(BR)CBO
: 40 V
ELECTRICAL CHARACTERISTICS
Tamb=25
unless otherwise specified
Parameter
Symbol
Test conditions
MIN
TYP
MAX
UNIT
Collector-base breakdown voltage
V(BR)
CBO
Ic= 100
A
, I
E
=0
40
V
Collector-emitter breakdown voltage
V(BR)
CEO
Ic= 0.1 mA
I
B
=0
25
V
Emitter-base breakdown voltage
V(BR)
EBO
I
E
= 100
A
I
C
=0
5
V
Collector cut-off current
I
CBO
V
CB
= 40 V , I
E
=0
0.1
A
Collector cut-off current
I
CEO
V
CE
= 20 V , I
B
=0
0.2
A
Emitter cut-off current
I
EBO
V
EB
=
3 V
I
C
=0 0.1
A
H
FE
1
V
CE
= 1 V, I
C
= 50mA
85
300
DC current gain(note)
H
FE
2
V
CE
= 1 V, I
C
= 500mA
50
Collector-emitter saturation voltage
V
CE
(sat)
I
C
= 500mA, I
B
= 50 mA
0.6
V
Base-emitter saturation voltage
V
BE
(sat)
I
C
= 500mA, I
B
= 50 mA
1.2
V
Base-emitter voltage
V
BE
I
E
= 100mA
1.4
V
Transition frequency
f
T
V
CE
= 6 V, I
C
= 20mA
f =
30MHz
150
MHz
CLASSIFICATION OF H
FE(1)
Rank
B
C
D
Range
85-160
120-200
160-300
Wing Shing Computer Components Co., (H.K.)Ltd.
Tel:(852)2341 9276 Fax:(852)2797 8153
Homepage:
http://www.wingshing.com
E-mail: wsccltd@hkstar.com
1 2 3
TO-92
1. EMITTER
2. BASE
3. COLLECTOR
TRANSISTOR (PNP)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
S8550
