SIDE LOOK PACKAGE
NPN PHOTOTRANSISTOR
Description
Package Dimensions
The MID-94A46 is a two bits NPN silicon phototransistor
Unit : mm
mounted in a special dark plastic side looking package
and suitable for the IRED (940nm) Type.
Features
l
Wide range of collector current
l
Low cost plastic package
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Maximum Rating
Unit
Power Dissipation
100
mW
Collector-Emitter Voltage
30
V
Emitter-Collector Voltage
5
V
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
260
o
C for 5 seconds
02/04/2002
-55
o
C to +100
o
C
-55
o
C to +100
o
C
Unity Opto Technology Co., Ltd.
NOTE 2
1.50 + 0.025
- 0.050
3.00 .08
1.00 .08
5.00 .08
C 0.8
1.77 .20
0.50 0.05
2.54 0.12
2 places
2.50 .08
1.00 0.12
2.50 .10
NOTE 3
45
1
2
3
1
2
33
0.70
0.65 mm max
2.90 0.12
5.70 .30
2.80 .08
4.77 .20
NOTES :
1. All dimensions are in millimeters.
2. PTR die vertical & horizontal placement tolerance is 0.12 mm
Allowed die rotation must be 5 or less.
3. Protruded resin under flange is 1.5mm max.
4. Lead spacing is measured where the leads emerge from the package.
MID-94A46
Optical-Electrical Characteristics
@ T
A
=25
o
C
Parameter
Test Conditions
Symbol
Min.
Typ .
Max.
Unit
Collector-Emitter
I
c
=100
A
Breakdown Voltage
Ee=0
Emitter-Collector
Ie=100
A
Breakdown Voltage
Ee=0
Collector-Emitter
I
c
=0.5 mA
Saturation Voltage
Ee=0.1mW/cm
2
Rise Time
V
R
=5V, R
L
=1K
Tr
-
10
-
Fall Time
I
C
=1mA
Tf
-
10
-
Collector Dark
V
CE
=10V
Current
Ee=0
On State Collector
V
CE
=5V
Current
Ee=0.1mW/cm
2
Typical Optical-Electrical Characteristic Curves
02/04/2002
I
C(ON)
-
-
-
-
-
-
-
V
(BR)CEO
V
(BR)ECO
V
CE(SAT)
I
CEO
30
nA
-
V
V
0.16
5
mA
100
0.4
0.1
0.4
V
S
Unity Opto Technology Co., Ltd.
0.001
0.01
0.1
1
10
100
1000
0
40
80
120
T
A
- Ambient Temperature -
o
C
FIG.1 COLLECTOR DARK CURRENT
VS AMBIENT TEMPERATURE
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
-75
-25
25
75
125
Vce = 5 V
Ee = 0.1 mW/cm
2
@
= 940 nm
T
A
- Ambient Temperature -
o
C
FIG.2 NORMALIZED COLLECTOR CURRENT
VS AMBIENT TEMPERATURE
0.0
0.4
0.8
1.2
1.6
2.0
0
0.1
0.2
0.3
0.4
0.5
0.6
Vce = 5 V
Ee - Irradiance - mW/cm
2
FIG.4 RELATIVE COLLECTOR CURRENT
VS IRRADIANCE
0
4
8
12
16
20
0
2
4
6
8
10
R
L
- Load Resistance - K
FIG.3 RISE AND FALL TIME
VS LOAD RESISTANCE
Iceo-Collector Dark Current -
A
Ic Normalized Collector Current
Vcc = 5 V
V
RL
= 1 V
F = 100 Hz
PW = 1 ms
Tr Tf - Rise and Fall Time - mS
Relative Collector Current (mA)
