S6744
2001-07-10
1
TOSHIBA THYRISTOR SILICON PLANAR TYPE
S6744
MEDIUM POWER CONTROL APPLICATIONS
l Repetitive Peak Off-State Voltage : V
DRM
= 400V
Repetitive Peak Reverse Voltage
: V
RRM
= 400V
l Average On-State Current
: I
T (AV)
= 8A
l A Large Current Pulse Capability
MAXIMUM RATINGS
CHARACTERISTIC SYMBOL
RATING
UNIT
Repetitive Peak Off-State Voltage
and Repetitive Peak Reverse Voltage
V
DRM
V
RRM
400 V
Non-Repetitive Peak Reverse
Voltage (Non-Repetitive<5ms,
T
j
= 0~125C)
V
RSM
500 V
Average On-State Current
(Half Sine Waveform Tc = 72C)
I
T (AV)
8 A
R.M.S On-State Current
I
T (RMS)
12.6 A
200 (50Hz)
Peak One Cycle Surge On-State
Current (Non-Repetitive)
I
TSM
220 (60Hz)
A
I
2
t Limit Value
I
2
t 200
A
2
s
Repetitive Peak Surge On-State
Current (Note
1)
I
TRM
1300 A
Critical Rate of Rise of On-State
Current (Note
2)
di / dt
100
A / s
Peak Gate Power Dissipation
P
GM
5 W
Average Gate Power Dissipation
P
G (AV)
0.5 W
Peak Forward Gate Voltage
V
FGM
10 V
Peak Reverse Gate Voltage
V
RGM
-5 V
Peak Forward Gate Current
I
GM
2 A
Junction Temperature
T
j
-40~125 C
Storage Temperature Range
T
stg
-40~125 C
Note 1: C
M
500F, t
w
300s, V
D
350V
Note 2: di / dt Test condition
V
DRM
= 0.5 Rated, I
TM
25A, t
gw
10s, t
gr
250ns, i
gp
= I
GT
2.0
Unit: mm
JEDEC
JEITA
TOSHIBA 13-10J1B
Weight: 1.7 g
S6744
2001-07-10
2
ELECTRICAL CHARACTERISTICS
(Ta = 25C)
CHARACTERISTIC SYMBOL
TEST
CONDITION
MIN
TYP.
MAX
UNIT
Repetitive Peak Off-State Current and
Repetitive Peak Reverse Current
I
DRM
I
RRM
V
DRM
= V
RRM
= Rated
10 A
Peak On-State Voltage
V
TM
I
TM
= 25A
1.5 V
Gate Trigger Voltage
V
GT
1.0 V
Gate Trigger Current
I
GT
V
D
= 6V, R
L
= 10
20 mA
Gate Non-Trigger Voltage
V
GD
V
D
= Rated 2 / 3, Tc = 125C
0.2
V
Critical Rate of Rise of Off-State Voltage
dv / dt
V
DRM
= Rated,Tc = 125C,
Exponential Rise
50 V
/
s
Holding Current
I
H
V
D
= 6V, I
TM
= 1A
40 mA
Latching Current
I
L
V
D
= 6V, f = 50Hz,
t
gw
= 100s, i
G
= 40mA
60 mA
Thermal Resistance
R
th (j-a)
Junction to Ambient
70
C
/
W
MARKING
*1
TYPE
NAME
S6744 MARK S6744
*2
Example
8A
:
January
1998
8B : February 1998
8L : December 1998
S6744
2001-07-10
4
