1/74
January 2002
s
HIGH PERFORMANCE CPU
16-BIT CPU WITH 4-STAGE PIPELINE
80ns INSTRUCTION CYCLE TIME AT 25MHz
CPU CLOCK
400ns 16 X 16-BIT MULTIPLICATION
800ns 32 / 16-BIT DIVISION
ENHANCED BOOLEAN BIT MANIPULATION
FACILITIES
ADDITIONAL INSTRUCTIONS TO SUPPORT
HLL AND OPERATING SYSTEMS
SINGLE-CYCLE CONTEXT SWITCHING SUP-
PORT
s
MEMORY ORGANIZATION
256K BYTE ON-CHIP FLASH MEMORY
10K ERASING / PROGRAMMING CYCLES
UP TO 16M BYTE LINEAR ADDRESS SPACE
FOR CODE AND DATA (5M BYTE WITH CAN)
2K BYTE ON-CHIP INTERNAL RAM (IRAM)
6K BYTE ON-CHIP EXTENSION RAM (XRAM)
20 YEAR DATA RETENTION TIME
s
FAST AND FLEXIBLE BUS
PROGRAMMABLE EXTERNAL BUS CHARAC-
TE- RISTICS FOR DIFFERENT ADDRESS
RANGES
8-BIT OR 16-BIT EXTERNAL DATA BUS
MULTIPLEXED OR DEMULTIPLEXED EXTER-
NAL ADDRESS / DATA BUSES
FIVE PROGRAMMABLE CHIP-SELECT SIGNALS
HOLD-ACKNOWLEDGE BUS ARBITRATION
SUPPORT
s
INTERRUPT
8-CHANNEL PERIPHERAL EVENT CONTROL-
LER FOR SINGLE CYCLE, INTERRUPT DRIVEN
DATA TRANSFER
16-PRIORITY-LEVEL INTERRUPT SYSTEM
WITH 56 SOURCES, SAMPLE-RATE DOWN TO
40ns
s
TIMERS
TWO MULTI-FUNCTIONAL GENERAL PUR-
POSE TIMER UNITS WITH 5 TIMERS
TWO 16-CHANNEL CAPTURE / COMPARE
UNITS.
s
4-CHANNEL PWM UNIT
s
SERIAL CHANNELS
SYNCHRONOUS / ASYNCHRONOUS SERIAL
CHANNEL
HIGH-SPEED SYNCHRONOUS CHANNEL
s
A/D CONVERTER
16-CHANNEL 10-BIT
7.76S CONVERSION TIME
s
FAIL-SAFE PROTECTION
PROGRAMMABLE WATCHDOG TIMER
OSCILLATOR WATCHDOG
s
ON-CHIP CAN 2.0B INTERFACE
s
ON-CHIP BOOTSTRAP LOADER
s
CLOCK GENERATION
ON-CHIP PLL
DIRECT OR PRESCALED CLOCK INPUT.
s
UP TO 111 GENERAL PURPOSE I/O LINES
INDIVIDUALLY PROGRAMMABLE AS INPUT,
OUTPUT OR SPECIAL FUNCTION.
PROGRAMMABLE THRESHOLD (HYSTERESIS)
s
IDLE AND POWER DOWN MODES
s
SINGLE VOLTAGE SUPPLY: 5V
10%
s
144-PIN PQFP PACKAGE
PQFP144 (28 x 28 mm)
(Plastic Quad Flat Pack)
P.6
P.5
P.3
P.
.2
GP
T
s
ASC
BRG
FLASH
CPU Core
Watchdog
Interrupt controller
PEC
P.7
P.8
EBC
AD
C
BRG
SSC
PW
M
C
APC
O
M
2
C
APC
O
M
1
RAM
XR
A
M
CA
N
OSC
P.1
P.0
P.4
ST10F168
16-BIT MCU WITH 256K BYTE FLASH MEMORY AND 8K BYTE RAM
This is advance information on a new product now in development or undergoing evaluation. Details are subject to change without notice.
ST10F168
2/74
1
INTRODUCTION .........................................................................................................
4
2
PIN DATA ...................................................................................................................
5
3
FUNCTIONAL DESCRIPTION....................................................................................
10
4
MEMORY ORGANIZATION........................................................................................
11
5
FLASH MEMORY .......................................................................................................
13
5.1
PROGRAMMING / ERASING WITH ST EMBEDDED ALGORITHM KERNEL ..........
14
5.2
PROGRAMMING EXAMPLES ....................................................................................
16
5.3
FLASH MEMORY CONFIGURATION.........................................................................
18
5.4
FLASH PROTECTION ................................................................................................
18
5.5
BOOTSTRAP LOADER MODE ...................................................................................
18
6
CENTRAL PROCESSING UNIT (CPU) ......................................................................
19
6.1
INSTRUCTION SET SUMMARY.................................................................................
20
7
EXTERNAL BUS CONTROLLER...............................................................................
22
8
INTERRUPT SYSTEM ................................................................................................
23
9
CAPTURE / COMPARE (CAPCOM) UNIT .................................................................
26
10
GENERAL PURPOSE TIMER UNIT ...........................................................................
28
10.1
GPT1 ...........................................................................................................................
28
10.2
GPT2 ...........................................................................................................................
28
11
PWM MODULE ...........................................................................................................
31
12
PARALLEL PORTS ....................................................................................................
32
13
A/D CONVERTER .......................................................................................................
33
14
SERIAL CHANNELS ..................................................................................................
34
15
CAN MODULE ............................................................................................................
36
16
WATCHDOG TIMER ...................................................................................................
36
17
SYSTEM RESET .........................................................................................................
37
17.1
ASYNCHRONOUS RESET (LONG HARDWARE RESET) ........................................
37
17.2
SYNCHRONOUS RESET (WARM RESET) ...............................................................
38
17.3
SOFTWARE RESET ...................................................................................................
39
17.4
WATCHDOG TIMER RESET ......................................................................................
39
17.5
RESET CIRCUITRY ...................................................................................................
39
18
POWER REDUCTION MODES ..................................................................................
42
TABLE OF CONTENT
PAGE
ST10F168
3/74
19
SPECIAL FUNCTION REGISTER OVERVIEW..........................................................
43
19.1
IDENTIFICATION REGISTERS ..................................................................................
49
20
ELECTRICAL CHARACTERISTICS ..........................................................................
50
20.1
ABSOLUTE MAXIMUM RATINGS ..............................................................................
50
20.2
PARAMETER INTERPRETATION ..............................................................................
50
20.3
DC CHARACTERISTICS ............................................................................................
50
20.4
A/D CONVERTER CHARACTERISTICS ....................................................................
52
20.5
AC CHARACTERISTICS.............................................................................................
53
20.5.1
Test Waveforms ........................................................................................................
53
20.5.2
Definition of Internal Timing .........................................................................................
54
20.5.3
Clock Generation Modes .............................................................................................
54
20.5.4
Prescaler Operation.....................................................................................................
55
20.5.5
Direct Drive ..................................................................................................................
55
20.5.6
Oscillator Watchdog (OWD) ........................................................................................
55
20.5.7
Phase Locked Loop .....................................................................................................
55
20.5.8
External Clock Drive XTAL1 ........................................................................................
56
20.5.9
Memory Cycle Variables..............................................................................................
57
20.5.10
Multiplexed Bus ...........................................................................................................
57
20.5.11
Demultiplexed Bus.......................................................................................................
63
20.5.12
CLKOUT and READY..................................................................................................
69
20.5.13
External Bus Arbitration ...............................................................................................
71
21
PACKAGE MECHANICAL DATA ..............................................................................
73
22
ORDERING INFORMATION .......................................................................................
73
ST10F168
4/74
1 - INTRODUCTION
The ST10F168 is a derivative of the STMicroelec-
tronics 16-bit single-chip CMOS microcontrollers.
It combines high CPU performance (up to
12.5 million instructions per second) with high
peripheral functionality and enhanced I/O capabil-
ities. It also provides on-chip high-speed Flash
memory, on-chip high-speed RAM, and clock gen-
eration via PLL.
Figure 1 : Logic Symbol
XTAL1
RSTIN
XTAL2
RSTOUT
NMI
EA
READY
ALE
RD
WR/WRL
Port 5
16-bit
Port 6
8-bit
Port 4
8-bit
Port 3
15-bit
Port 2
16-bit
Port 1
16-bit
Port 0
16-bit
V
DD
V
SS
Port 7
8-bit
Port 8
8-bit
V
AREF
V
AGND
ST10F168
V
PP
ST10F168
5/74
2 - PIN DATA
Figure 2 : Pin Configuration (top view)
EA
ALE
RD
V
SS
V
DD
P6.0/CS0
P6.1/CS1
P6.2/CS2
P6.3/CS3
P6.4/CS4
P6.5/HOLD
P6.6/HLDA
P6.7/BREQ
P8.0/CC16IO
P8.1/CC17IO
P8.2/CC18IO
P8.3/CC19IO
P8.4/CC20IO
P8.6/CC22IO
P8.7/CC23IO
V
DD
V
SS
P7.0/POUT0
P7.1/POUT1
P7.2/POUT2
P7.3/POUT3
P8.5/CC21IO
V
PP
/RPD
P7.4/CC28I0
P7.5/CC29I0
P7.6/CC30I0
P7.7/CC31I0
P5.0/AN0
P5.1/AN1
P5.2/AN2
P5.3/AN3
P5.4/AN4
P5.5/AN5
P5.6/AN6
P5.7/AN7
P5.8/AN8
P5.9/AN9
P0H.0/AD8
P0L.7/AD7
P0L.6/AD6
P0L.5/AD5
P0L.4/AD4
P0L.3/AD3
P0L.2AD2
P0L.1/AD1
P0L.0/AD0
READY
WR/WRL
P4.7/A23
P4.6/A22/CAN_TxD
P4.5/A21/CAN_RxD
P4.4/A20
P4.3/A19
P4.2/A18
P4.1/A17
P4.0/A16
V
SS
V
DD
P3.15/CLKOUT
P3.13/SCLK
P3.12/BHE/WRH
P3.11/RXD0
P3.10/TXD0
P3.9/MTSR
P3.8/MRST
P3.7/T2IN
P3.6/T3IN
V
AR
EF
V
AG
N
D
P
5
.
10/
A
N
10/
T
6
E
U
D
P
5
.
11/
A
N
11/
T
5
E
U
D
P
5
.
12/
A
N
12/
T
6
I
N
P
5
.
13/
A
N
13/
T
5
I
N
P
5
.
14/
A
N
14/
T
4
E
U
D
P
5
.
15/
A
N
15/
T
2
E
U
D
V
SS
V
DD
P
2
.
0
/CC
0
IO
P
2
.
1
/CC
1
IO
P
2
.
2
/CC
2
IO
P
2
.
3
/CC
3
IO
P
2
.
4
/CC
4
IO
P
2
.
5
/CC
5
IO
P
2
.
6
/CC
6
IO
P
2
.
7
/CC
7
IO
V
SS
V
DD
P
2
.
8
/C
C8
IO/E
X
0
I
N
P
2
.
9
/C
C9
IO/E
X
1
I
N
P
2
.
10/
C
C
10I
O
E
X
2
I
N
P
2
.
11/
C
C
11I
O
E
X
3
I
N
P
2
.
12/
C
C
12I
O/
E
X
4I
N
P
2
.
13/
C
C
13I
O/
E
X
5I
N
P
2
.
14/
C
C
14I
O/
E
X
6I
N
P
2
.
15/
C
C
15I
O/
E
X
7I
N
/
T
7
I
N
P3
.
0
/
T
0
I
N
P3
.
1
/
T
6
O
U
T
P
3
.2
/
C
A
P
IN
P3
.
3
/
T
3
O
U
T
P3
.
4
/
T
3
E
U
D
P3
.
5
/
T
4
I
N
V
SS
V
DD
V
SS
NM
I
V
DD
RS
T
O
UT
RS
T
I
N
V
SS
XT
AL
1
XT
AL
2
V
DD
P
1
H
.
7/
A
15/
C
C
27I
O
P
1
H
.
6/
A
14/
C
C
26I
O
P
1
H
.
5/
A
13/
C
C
25I
O
P
1
H
.
4/
A
12/
C
C
24I
O
P1
H
.
3
/
A
1
1
P1
H
.
2
/
A
1
0
P1
H
.
1
/
A
9
P1
H
.
0
/
A
8
V
SS
V
DD
P
1L.
7/
A
7
P
1L.
6/
A
6
P
1L.
5/
A
5
P
1L.
4/
A
4
P
1L.
3/
A
3
P
1L.
2/
A
2
P
1L.
1/
A
1
P
1L.
0/
A
0
P
0
H
.
7/
A
D
15
P
0
H
.
6/
A
D
14
P
0H.
5/
A
D13
P
0H.
4/
A
D12
P
0H.
3/
A
D11
P
0
H
.
2/
A
D
10
P
0H.
1/
A
D
9
V
SS
V
DD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
108
107
106
105
104
103
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
144
143
142
141
140
139
138
137
136
135
134
133
132
131
130
129
128
127
126
125
124
123
122
121
120
119
118
117
116
115
114
113
112
111
110
109
ST10F168
ST10F168
6/74
Table 1 : Pin Description
Symbol
Pin
Type
Function
P6.0 - P6.7
1 - 8
I/O
8-bit bidirectional I/O port, bit-wise programmable for input or output via direction bit.
Programming an I/O pin as input forces the corresponding output driver to high
impedance state. Port 6 outputs can be configured as push-pull or open drain
drivers. The following Port 6 pins have alternate functions:
1
O
P6.0
CS0
Chip Select 0 Output
...
...
...
...
...
5
O
P6.4
CS4
Chip Select 4 Output
6
I
P6.5
HOLD
External Master Hold Request Input
7
O
P6.6
HLDA
Hold Acknowledge Output
8
O
P6.7
BREQ
Bus Request Output
P8.0 - P8.7
9-16
I/O
8-bit bidirectional I/O port, bit-wise programmable for input or output via direction bit.
Programming an I/O pin as input forces the corresponding output driver to high
impedance state. Port 8 outputs can be configured as push-pull or open drain
drivers. The input threshold of Port 8 is selectable (TTL or special).
The following Port 8 pins have alternate functions:
9
I/O
P8.0
CC16IO
CAPCOM2: CC16 Capture Input / Compare Output
...
...
...
...
...
16
I/O
P8.7
CC23IO
CAPCOM2: CC23 Capture Input / Compare Output
P7.0 - P7.7
19-26
I/O
8-bit bidirectional I/O port, bit-wise programmable for input or output via direction bit.
Programming an I/O pin as input forces the corresponding output driver to high
impedance state. Port 7 outputs can be configured as push-pull or open drain
drivers. The input threshold of Port 7 is selectable (TTL or special).
The following Port 7 pins have alternate functions:
19
O
P7.0
POUT0
PWM Channel 0 Output
...
...
...
...
...
22
O
P7.3
POUT3
PWM Channel 3 Output
23
I/O
P7.4
CC28IO
CAPCOM2: CC28 Capture Input / Compare Output
...
...
...
...
...
26
I/O
P7.7
CC31IO
CAPCOM2: CC31 Capture Input / Compare Output
P5.0 - P5.9
P5.10 - P5.15
27-36
39-44
I
I
16-bit input-only port with Schmitt-Trigger characteristics. The pins of Port 5 can be
the analog input channels (up to 16) for the A/D converter, where P5.x equals ANx
(Analog input channel x), or they are timer inputs:
39
I
P5.10
T6EUD
GPT2 Timer T6 External Up / Down Control Input
40
I
P5.11
T5EUD
GPT2 Timer T5 External Up / Down Control Input
41
I
P5.12
T6IN
GPT2 Timer T6 Count Input
42
I
P5.13
T5IN
GPT2 Timer T5 Count Input
43
I
P5.14
T4EUD
GPT1 Timer T4 External Up / Down Control Input
44
I
P5.15
T2EUD
GPT1 Timer T2 External Up / Down Control Input
ST10F168
7/74
P2.0 - P2.7
P2.8 - P2.15
47-54
57-64
I/O
16-bit bidirectional I/O port, bit-wise programmable for input or output via direction
bit. Programming an I/O pin as input forces the corresponding output driver to high
impedance state. Port 2 outputs can be configured as push-pull or open drain
drivers. The input threshold of Port 2 is selectable (TTL or special).
The following Port 2 pins have alternate functions:
47
I/O
P2.0
CC0IO
CAPCOM: CC0 Capture Input / Compare Output
...
...
...
...
...
54
I/O
P2.7
CC7IO
CAPCOM: CC7 Capture Input / Compare Output
57
I/O
P2.8
CC8IO
CAPCOM: CC8 Capture Input / Compare Output
I
EX0IN
Fast External Interrupt 0 Input
...
...
...
...
...
64
I/O
P2.15
CC15IO
CAPCOM: CC15 Capture Input / Compare Output
I
EX7IN
Fast External Interrupt 7 Input
I
T7IN
CAPCOM2 Timer T7 Count Input
P3.0 - P3.5
P3.6 - P3.13,
P3.15
65-70,
73-80,
81
I/O
I/O
I/O
15-bit (P3.14 is missing) bidirectional I/O port, bit-wise programmable for input or
output via direction bit. Programming an I/O pin as input forces the corresponding
output driver to high impedance state. Port 3 outputs can be configured as push-pull
or open drain drivers. The input threshold of Port 3 is selectable (TTL or special).
The following Port 3 pins have alternate functions:
65
I
P3.0
T0IN
CAPCOM Timer T0 Count Input
66
O
P3.1
T6OUT
GPT2 Timer T6 Toggle Latch Output
67
I
P3.2
CAPIN
GPT2 Register CAPREL Capture Input
68
O
P3.3
T3OUT
GPT1 Timer T3 Toggle Latch Output
69
I
P3.4
T3EUD
GPT1 Timer T3 External Up / Down Control Input
70
I
P3.5
T4IN
GPT1 Timer T4 Input for Count / Gate / Reload / Capture
73
I
P3.6
T3IN
GPT1 Timer T3 Count / Gate Input
74
I
P3.7
T2IN
GPT1 Timer T2 Input for Count / Gate / Reload / Capture
75
I/O
P3.8
MRST
SSC Master-Receiver / Slave-Transmitter I/O
76
I/O
P3.9
MTSR
SSC Master-Transmitter / Slave-Receiver O/I
77
O
P3.10
TxD0
ASC0 Clock / Data Output (Asynchronous / Synchronous)
78
I/O
P3.11
RxD0
ASC0 Data Input (Asynchronous) or I/O (Synchronous)
79
O
P3.12
BHE
External Memory High Byte Enable Signal
WRH
External Memory High Byte Write Strobe
80
I/O
P3.13
SCLK
SSC Master Clock Output / Slave Clock Input
81
O
P3.15
CLKOUT
System Clock Output (=CPU Clock)
Table 1 : Pin Description (continued)
Symbol
Pin
Type
Function
ST10F168
8/74
P4.0 - P4.7
85-92
I/O
8-bit bidirectional I/O port, bit-wise programmable for input or output via direction bit.
Programming an I/O pin as input forces the corresponding output driver to high
impedance state. For external bus configuration, Port 4 can be used to output the
segment address lines:
85-89
O
P4.0-P4.4 A16-A20
Segment Address Line
90
O
P4.5
A21
Segment Address Line
I
CAN_RxD
CAN Receiver Data Input
91
O
P4.6
A22
Segment Address Line
O
CAN_TxD
CAN Transmitter Data Output
92
O
P4.7
A23
Most Significant Segment Addrress Line
RD
95
O
External Memory Read Strobe. RD is activated for every external instruction or data
read access.
WR/WRL
96
O
External Memory Write Strobe. In WR-mode this pin is activated for every external
data write access. In WRL mode this pin is activated for low Byte data write
accesses on a 16-bit bus, and for every data write access on an 8-bit bus. See
WRCFG in the SYSCON register for mode selection.
READY/
READY
97
I
Ready Input. The active level is programmable. When the Ready function is
enabled, the selected inactive level at this pin, during an external memory access,
will force the insertion of wait state cycles until the pin returns to the selected active
level.
ALE
98
O
Address Latch Enable Output. In case of use of external addressing or of multi-
plexed mode, this signal is the latch command of the address lines.
EA
99
I
External Access Enable pin. A low level at this pin during and after Reset forces the
ST10F168 to start the program from the external memory space. A high level forces
the ST10F168 to start in the internal memory space.
P0L.0 - P0L.7
P0H.0
P0H.1 - P0H.7
100 - 107,
108,
111 - 117
I/O
Two 8-bit bidirectional I/O ports P0L and P0H, bit-wise programmable for input or
output via direction bit. Programming an I/O pin as input forces the corresponding
output driver to high impedance state.
In case of an external bus configuration, Port0 serves as the address (A) and as the
address / data (AD) bus in multiplexed bus modes and as the data (D) bus in demul-
tiplexed bus modes.
Table 1 : Pin Description (continued)
Symbol
Pin
Type
Function
Demultiplexed bus modes
Data Path Width:
8-bit
16-bit
P0L.0 P0L.7:
D0 D7
D0 - D7
P0H.0 P0H.7:
I/O
D8 - D15
Multiplexed bus modes
Data Path Width:
8-bit
16-bit
P0L.0 P0L.7:
AD0 AD7
AD0 - AD7
P0H.0 P0H.7:
A8 A15
AD8 AD15
ST10F168
9/74
P1L.0 - P1L.7
P1H.0 - P1H.7
118-125
128-135
I/O
Two 8-bit bidirectional I/O ports P1L and P1H, bit-wise programmable for input or
output via direction bit. Programming an I/O pin as input forces the corresponding
output driver to high impedance state. Port1 is used as the 16-bit address bus (A) in
demultiplexed bus modes and also after switching from a demultiplexed bus mode
to a multiplexed bus mode.
The following Port1 pins have alternate functions:
132
I
P1H.4
CC24IO
CAPCOM2: CC24 Capture Input
133
I
P1H.5
CC25IO
CAPCOM2: CC25 Capture Input
134
I
P1H.6
CC26IO
CAPCOM2: CC26 Capture Input
135
I
P1H.7
CC27IO
CAPCOM2: CC27 Capture Input
XTAL1
138
I
XTAL1
Oscillator amplifier and internal clock generator input
XTAL2
137
O
XTAL2:
Oscillator amplifier circuit output.
To clock the device from an external source, drive XTAL1 while leaving XTAL2
unconnected. Minimum and maximum high / low and rise / fall times specified in the
AC Characteristics must be observed.
RSTIN
140
I
Reset Input with Schmitt-Trigger characteristics. A low level at this pin for a speci-
fied duration while the oscillator is running resets the ST10F168. An internal pullup
resistor permits power-on reset using only a capacitor connected to V
SS
. In bidirec-
tional reset mode (enabled by setting bit BDRSTEN in SYSCON register), the
RSTIN line is pulled low for the duration of the internal reset sequence.
RSTOUT
141
O
Internal Reset Indication Output. This pin is set to a low level during hardware, soft-
ware or watchdog timer reset.
RSTOUT
remains low until the EINIT (end of initial-
ization) instruction is executed.
NMI
142
I
Non-Maskable Interrupt Input. A high to low transition at this pin causes the CPU to
vector to the NMI trap routine. If bit PWDCFG = `0' in SYSCON register, when the
PWRDN (power down) instruction is executed, the NMI pin must be low in order to
force the ST10F168 to go into power down mode. If NMI is high and PWDCFG ='0',
when PWRDN is executed, the part will continue to run in normal mode.
If it is not used, pin NMI should be pulled high externally.
V
AREF
37
-
A/D converter reference voltage.
V
AGND
38
-
A/D converter reference ground.
V
PP
/RPD
84
-
Flash programming voltage. Programming voltage of the on-chip Flash memory
must be supplied to this pin.
It is used also as the timing pin for the return from interruptible powerdown mode.
V
DD
17,46,
56,72,
82,93,
109, 126,
136, 144
-
Digital Supply Voltage:
= + 5V during normal operation and idle mode.
> 2.5V during power down mode.
V
SS
18,45,
55,71,
83,94,
110, 127,
139, 143
-
Digital Ground.
Table 1 : Pin Description (continued)
Symbol
Pin
Type
Function
ST10F168
10/74
3 - FUNCTIONAL DESCRIPTION
The architecture of the ST10F168 combines
advantages of both RISC and CISC processors
and an advanced peripheral subsystem.
The block diagram gives an overview of the
different on-chip components and the high
bandwidth internal bus structure of the ST10F168.
Figure 3 : Block Diagram
Po
r
t
0
Po
r
t
1
Po
r
t
4
Port 6
Port 5
Port 3
Po
r
t
2
GP
T1
GP
T2
A
S
C
usar
t
BRG
CPU-Core
Internal
RAM
Watchdog
Interrupt Controller
8
16
32
16
PEC
16
16
CAN
Port 7
Port 8
E
x
ter
nal Bus
10
-
B
i
t
A
D
C
BRG
SS
C
PW
M
CA
PC
OM2
CA
PC
O
M
1
16
16
OSC.
6K Byte
16
C
ontrol
l
er
16
8
16
256K Byte
+ PLL
XRAM
Flash
memory
CAN_RxD P4.5
CAN_TxD P4.6
XTAL1
XTAL2
15
8
8
ST10F168
11/74
4 - MEMORY ORGANIZATION
The memory space of the ST10F168 is configured
in a Von Neumann architecture. Code memory,
data memory, registers and I/O ports are orga-
nized within the same linear address space of
16M Byte. The entire memory space can be
accessed bytewise or wordwise. Particular por-
tions of the on-chip memory have additionally
been made directly bit addressable.
FLASH: 256K Byte of on-chip Flash memory. See
Flash Memory
on page 13
IRAM: 2K Byte of on-chip internal RAM
(dual-port) is provided as a storage for data, sys-
tem stack, general purpose register banks and
code. A register bank is 16 wordwide (R0 to R15)
and / or bytewide (RL0, RH0, ..., RL7, RH7) gen-
eral purpose registers.
XRAM: 6K Byte of on-chip extension RAM (single
port XRAM) is provided as a storage for data, user
stack and code. The XRAM is connected to the
internal XBUS and is accessed like an external
memory in 16-bit demultiplexed bus-mode without
wait state or read / write delay (80ns access at
25MHz CPU clock). Byte and Word access are
allowed.
The XRAM address range is 00'D000h -
00'E7FFh if the XRAM is enabled (XPEN bit 2 of
SYSCON register). As the XRAM appears like
external memory, it cannot be used for the
ST10F168's system stack or register banks. The
XRAM is not provided for single bit storage and
therefore is not bit addressable. If bit XPEN is
cleared, then any access in the address range
00'D000h - 00'E7FFh will be directed to external
memory interface, using the BUSCONx register
corresponding to address matching ADDRSELx
register.
SFR/ESFR: 1024 Byte (2 x 512 Byte) of address
space is reserved for the Special Function Regis-
ter areas. SFRs are wordwide registers which are
used for controlling and monitoring functions of
the different on-chip units.
CAN: Address range 00'EF00h - 00'EFFFh is
reserved for the CAN Module access. The CAN is
enabled by setting XPEN bit 2 of the SYSCON
register. Accesses to the CAN Module use demul-
tiplexed addresses and a 16-bit data bus (Byte
accesses are possible). Two wait states give an
access time of 160ns at 25MHz CPU clock. No
tristate wait state is used.
Note: If the CAN module is used, Port 4 can not
be programmed to output all 8 segment
address lines. Therefore, only 4 segment
address lines can be used, reducing the
external memory space to 5M Byte (1M
Byte per CS line)
To meet the needs of designs where more mem-
ory is required than is provided on chip, up to 16M
Byte of external RAM and / or ROM can be con-
nected to the microcontroller.
ST10F168
12/74
Figure 4 : ST10F168 on-chip memory mapping
0x5'0000
0x14
0x4'FFFF
0x4'C000
0x13
0x4'8000
0x12
0x4'4000
0x11
0x4'0000
0x10
0x3'C000
0x0F
0x3'8000
0x0E
Bank 3 : 96K Byte
0x3'7FFF
0x3'4000
0x0D
0x3'0000
0x0C
0x2'C000
0x0B
0x2'8000
0x0A
0x2'4000
0x09
0x2'0000
0x08
Bank 2 : 96K Byte
0x1'FFFF
0x1'C000
0x07
0x1'8000
0x06
Bank 1H : 32K Byte
Bank 1L : 16K Byte
0x1'4000
0x05
0x04
Bank 0 : 16K Byte
0x1'0000
Bank 1L : 16K Byte
0x0'4000
0x01
0x00
Bank 0 : 16K Byte
0x0'0000
0x02
0x0'8000
0x0'FFFF
SFR Area
0x0'FE00
0x0'FDFF
IRAM : 2K Byte
0x0'F600
0x0'EFFF
CAN Module
0x0'EF00
0x0'E7FF
XRAM : 6K Byte
0x0'D000
* Bank 0 and Bank 1 L may be remapped from segment 0
to segment 1 by setting SYSCON.ROMS1 (before EINIT)
RAM, SFR and X-pheripherals are
mapped into the address space.
SYSCON.XPEN=1 enables CAN
and XRAM (before EINIT)
Se
g
m
e
n
t
4
Se
g
m
e
n
t
3
Se
g
m
e
n
t
2
Se
g
m
e
n
t
1
Se
g
m
e
n
t
0
Data
Page
Number
Absolute
Memory
Address
0x1'7FFF
0x1'3FFF
0x0'7FFF
0x0'3FFF
0x0'F1FF
ESFR Area
0x0'F000
ST10F168
13/74
5 - FLASH MEMORY
The ST10F168 provides 256K Byte of an
electrically erasable and reprogrammable Flash
Memory on-chip.
The Flash Memory can be used both for code and
data storage. It is organized into four 32-bit wide
blocks allowing even double Word instructions to
be fetched in one machine cycle. The four blocks
of size16K, 48K, 96K and 96K Byte can be erased
and reprogrammed individually (see Table 2 and
Table 3).
The Flash Memory can be programmed in a pro-
gramming board or in the target system which
provides high system flexibility. The algorithms to
program or erase the flash memory are embed-
ded in the Flash Memory itself (ST Embedded
Algorithm Kernel, or STEAK
TM
).
To start a program / erase operation, the user's
software has just to load GPRs with the address
and data to be programmed, or sector to be
erased. STEAK uses embedded routines, which
check the validity of the programmed parameters,
decode and then execute the programming or
erase command. During operation, the STEAK
routines carry out checks and retries to verify
proper cell programming or erasing. When an
error occurs, STEAK returns an error-code which
identifies the cause of the error.
A Flash Memory protection option prevents the
read-back of the Flash Memory contents from
external memory, or from on-chip RAM. Code
operation from within the Flash continues as nor-
mal.
The first bank (16K Byte) and part of the second
bank (16K Byte out of 48K Byte) of the on-chip
Flash Memory of the ST10F168 can be mapped
to either segment 0 (addresses 00000h to
07FFFh) or to segment 1 (addresses 10000h to
17FFFh) during the initialization phase. External
memory can be used for additional system
flexibility.
V
DD
= 5V 10%, V
PP
= 12V 5%, V
SS
= 0V, f
CPU
= 25MHz, for Q6 version : T
A
= -40C, +85C and for
Q3 version T
A
= -40C, + 125C.
Table 2 : Flash Memory Characteristics
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
f
CPU
CPU Frequency during
erasing / programming operation
5
-
32
MHz
Cyc
Erasing / Programming Cycles
f
CPU
= 25MHz
-
-
10K
t
SPRG
Single Word Programming Time
f
CPU
= 25MHz
-
40
1500
s
t
DPRG
Double Word Programming Time
f
CPU
= 25MHz
-
40
1500
s
t
EBNK
Sector Erasing Time
f
CPU
= 25MHz
-
3
15
s
t
RET
Data Retention Time
Defectivity below 1ppm / year
20
-
-
year
Table 3 : Flash Memory Bank Organisation
Bank
Addresses (segment 0)
Addresses (segment 1)
Size (Byte)
0
1
2
3
000000h to 003FFFh
004000h to 007FFFh + 018000h to 01FFFFh
020000h to 037FFFh
038000h to 04FFFFh
010000h to 013FFFh
014000h to 01FFFFh
020000h to 03FFFFh
038000h to 04FFFFh
16K
48K
96K
96K
ST10F168
14/74
5.1 - Programming / Erasing with ST
Embedded Algorithm Kernel
There are three stages to run STEAK :
To load the registers R0 to R4 with the STEAK
command, the address and the data to be pro-
gramed, or sector to be erased. Table 4 gives
the STEAK parameters for each type of Flash
programming / erasing operation. Table 5 de-
fines the codes used in Table 4.
To initiate the Unlock Sequence. The Unlock Se-
quence is composed of two consecutive writes
to an even address in the Flash active address
space - the first write has direct addressing
mode (MOV mem, Rwn) - the second write has
indirect addressing mode (MOV [Rwm], Rwn).
Rwn can be any unused Word-GPR (R6 to R15)
loaded with a value resulting in the same even
address as "mem".
To read the return values in R0. When the em-
bedded programming / erasing algorithm returns
to trigger point, return values are given in R0.
Table 6 gives the error-code definitions, Table 7
gives the return values in each register for each
type of Flash programming / erasing command.
Note: The Flash Embedded STEAK Algorithms
require at least 50 words on the Internal
System Stack. STEAK verifies that there is
enough free space on the System Stack,
before performing a programming or eras-
ing operation.The MDH, MDL and MDC
register content are modified.
Code examples for programming and erasing the
Flash Memory using STEAK are given in
Section 5.2.
Note
For more details refer to STEAK applica-
tion note on www.st.com web site.
Table 4 : STEAK parameters
Command
R0
R1
R2
R3
R4
Single Word programming
55Ash
AddOff
W
nu
2TCL
Double Word programming
DD4sh
AddOff
DWL
DWH
2TCL
Multiple (block) programming
AA5sh
BegAddOff
EndAddOff
SourceAddr
2TCL
Sector Erasing
EEEEh
5555h
Bnk
Bnk
2TCL
Set Flash Protection UPROG bit
CCCCh
5555h
3333h
AAAAh
2TCL
Read Status
7777h
nu
nu
nu
2TCL
Table 5 : Programming / erasing code definition
s
Segment of the Target Flash Memory cell,
AddOff
Segment Offset of the Target Flash Memory cell. Must be even value (Word-aligned address).
W
Data (Word) to be written in Flash.
DWL,DWH Data (double Word, DHL = low Word, DWH = high Word) to be written in Flash.
BegAddOff
Segment Offset of the FIRST Target Flash Memory Word to be written in a Multiple programming
command. Must be even value (Word-aligned address).
EndAddOff
Segment Offset of the LAST Target Flash Memory Word to be written in a Multiple programming
command.
Must be even value (Word-aligned address). The value D = (EndAddOff - BegAddOff) must be:
0 <= D < 16384 (ie. up to one page (16K Byte) can be written in the flash with one multi-Word
programming command).
SourceAdd
Start address for the block to be programmed.
This address is using implicitly the data paging mechanism of the CPU. SourceAdd value must respect
the following rules :
- SourceAdd + (EndAddOff - BegAddOff) < 16384.
- Page 0 and 1 can NOT be used for source data if bit ROMS1 = `1' (in SYSCON register).
Note that source data can be located in Flash (In pages 0, 1, 6 to 19 if bit ROMS1 = `0', or in pages 4 to 19
if bit ROMS1 = `1').
Bnk
Number of the Bank to be erased. For security, R2 and R3 must hold the same value.
2TCL
CPU clock period in nano-seconds (eg. R4 = 50 (32h) means CPU frequency is 20MHz).
ST10F168
15/74
Table 6 : Error Code Definition (R0 content after STEAK execution)
Note: The Flash Embedded STEAK Algorithms
require at least 50 words on the Internal
System Stack for proper operation. The
program itself verifies that there is enough
free space on the System Stack before
performing a programming or erasing
operation, by computing the Word number
between Stack Pointer (SP) and Stack
Overflow register (STKOV ).
The MDH, MDL and MDC register content
are modified.
Registers R0 to R4 are used as Input Data
for STEAK, and are modified as explained
above (Return Values).
Registers R5 to R15 are used internally by
STEAK, but preserved on entry and
restore on exit of STEAK.
IT IS VERY IMPORTANT TO TAKE INTO
ACCOUNT THE FACT THAT STEAK
USES UP TO 50 WORDS ON THE SYS-
TEM STACK. TO PREVENT ANY
ABNORMAL SITUATION, IT IS VERY
IMPORTANT TO INITIALIZE COR-
RECTLY THE STACK SIZE TO AT LEAST
64 WORDS, AND TO CORRECTLY INI-
TIALIZE REGISTER STKOV.
Error Code
Meaning
00h
Operation was successful
01h
Flash Protection is active
02h
Vpp voltage not present
03h
Programming operation failed
04h
Address value (R1) incorrect: not in Flash address area or odd
05h
CPU period out of range (must be between 30 ns to 500 ns)
06h
Not enough free space on system stack for proper operation
07h
Incorrect bank number (R2,R3) specified
08h
Erase operation failed (phase 1)
09h
Bad source address for Multiple Word programming command
0Ah
Bad number of words to be copied in Multiple Word programming command: one destination will be
out of flash.
0Bh
PLL Unlocked or Oscillator watchdog overflow occured during programming or erasing the flash.
0Ch
Erase operation failed (phase 2)
FFh
Unknown or bad command
Table 7 : Return values for each programming / erase command
Programming
Command
R0
R1
R2
R3
R4-R15
Single or
double Word
programming
Error
code
Unchanged
Data in Flash for
location Segment +
Segment Offset
(R0.[3:0] with R1)
Data in Flash for
location Segment +
Segment Offset + 2
(R0[3:0] with R1+2)
Unchanged
Block
programming
Error
code
The last segment offset address of the
last written Word in Flash (failing Flash
address if R0 is not equal to zero)
Undefined
Unchanged
Erasing
Error
code
Undefined
Unchanged
After status
read
Error
code
Flash embedded rev
MSByte = major release
LSByte = minor revision
Circuit identifiers :
R2 = #0787h
R3 = #0101h for this device
Unchanged
ST10F168
16/74
5.2 - Programming Examples
Programming a double Word
Note: For easier coding, the standard data paging addressing scheme is overriden for the two MOV
instructions of the Flash Trigger Sequence (EXTS instruction). However this coding also locks
both standard and PEC interrupts and class A hardware traps. This override can be replaced by
an ATOMIC instruction if the standard DPP addressing scheme must be preserved.
; code shown below assumes that Flash is mapped in segment 1
; ie. bit ROMS1 = `1' in SYSCON register
; Flash must be enabled, ie. bit ROMEN = `1' in SYSCON.
MOV
R0, #0DD40h
; DD4xh : Double Word programming command
OR
R0, #01h
; Selects segment 1 in flash memory
MOV
R1, #00224h
; Address to be programmed is 01'0224h
MOV
R2, #03456h
; Data to be programmed at 01'0224h
MOV
R3, #04567h
; Data to be programmed at 01'0226h
MOV
R4, #050d
; 50ns is 20MHz CPU clock frequency
MOV
R7, #08000h
; R7 used for Flash trigger sequence
#define FCR 08000h
; Flash Unlock Sequence consists in two consecutive writes, with the direct
addressing mode and then the indirect addressing mode. FCR must represent an
even address in the active address space of the Flash memory, and Rwn can be
any unused Word GPR (R6 to R15)loaded with a value resulting in the same even
address than FCR
EXTS
#1, #2
; Flash can be mapped in segment 0 or 1
MOV
FCR, R7
; first part
MOV
[R7], R7
; second part
NOP
; WARNING: place 2 NOP operations after
NOP
; the Unlock sequence to avoid all possible
; pipeline conflicts in STEAK programs
ST10F168
17/74
Programming a block of data
The following code is provided as an example to program a block of data. Flash to be programmed is from
address 01'9000h to 01'9FFEh (included). Source data (data to be copied into flash) is located in external
RAM from address 05'1000h (to 05'1FFEh, implicitly) :
; code shown below assumes that flash is mapped in segment 1
; ie. bit ROMS1 = `1' in SYSCON register
; Flash must be enabled, ie. bit ROMEN = `1' in SYSCON.
MOV
R0, #0AA50h
; AA5xh : Multi Word programming command
OR
R0, #01h
; Selects segment 1 in Flash memory
MOV
R1, #09000h
; First Flash Segment Offset Address
MOV
R2, #09FFEh
; Last Flash Segment Offset Address
MOV
R3, #09000h
; Source data address: use DPP2 as
; data page pointer
SCXT
DPP2,#20d
; Source is in page 20 (first page of
; segment 5): save previous DPP2 value
; and load it with source page number
MOV
R4, #050d
; 50ns is 20MHz CPU clock frequency
MOV
R7, #08000h
; R7 used for Flash trigger sequence
#define FCR 08000h
EXTS
#1, #2
; Flash can be mapped in segment 0 or 1
MOV
FCR, R7
; first part
MOV
[R7], R7
; second part
NOP
; WARNING: place 2 NOP operations after
NOP
; the Unlock sequence to avoid all possible
; pipeline conflicts in STEAK programs
POP
DPP2
; restore DPP2
ST10F168
18/74
5.3 - Flash Memory Configuration
The default memory configuration of the
ST10F168 Memory is determined by the state of
the EA pin at reset. This value is stored in the
Internal ROM Enable bit : ROMEN of the
SYSCON Register.
When ROMEN = 0, the internal FLASH is disabled
and external ROM is used for startup control.
Flash memory can be enabled later by setting the
ROMEN bit of SYSCON to 1. Ensure that the
code which performs this setting is NOT running
from external ROM in a segment that will be
replaced by FLASH memory, otherwise unex-
pected behaviour may occur.
For example, if the external ROM code is located
in the first 32K Byte of segment 0, the first
32K Byte of the FLASH must then be enabled in
segment 1. This is done by setting the ROMS1 bit
of SYSCON to 0, before or simultaneously with
setting the ROMEN bit. This must be done in the
externally supplied program, before the execution
of the EINIT instruction. If program execution
starts from external memory, but the Flash mem-
ory mapped in segment 0 is accessed later, then
the code that sets the ROMEN bit must be exe-
cuted either in segment 0 but above address
00'8000h, or from the internal RAM.
Bit ROMS1 only affects the mapping of the first
32K Byte of the Flash memory. All other parts of
the Flash memory (addresses 01'8000h -
04'FFFFh) remain unaffected.
Note: The SGTDIS Segmentation Disable /
Enable must also be set to 0 to enable the use of
the full 256K Byte of on-chip memory in addition
to the external boot memory. The correct proce-
dure for changing the segmentation registers
must be observed to prevent an unwanted trap
condition :
Instructions that configure the internal memory
must only be executed from external memory or
from the internal RAM.
An Absolute Inter-Segment Jump (JMPS)
instruction must be executed after Flash enabling,
before the next instruction, even if the next
instruction is located in the consecutive address.
Whenever the internal memory is disabled, ena-
bled or remapped, the DPPs must be explicitly
(re)loaded to enable correct data accesses to
the internal memory and / or external memory.
5.4 - Flash Protection
If Flash Protection is active, data operands in the
on-chip Flash Memory area can only be read by a
program executed from the Flash Memory itself.
Program branches from or into the on-chip Flash
memory are possible in the Flash protection
mode. Erasing and programming of the Flash
memory is not possible as long as protection is
active.
Flash protection is controlled by the Protection
UPROM Programming Bit (UPROG). UPROG is a
'hidden' one-time programmable bit only accessi-
ble in a special mode which can be entered via a
Flash EPROM programming board for example. If
UPROG is set to "1", Flash protection is active
after reset. By default Flash Protection is disabled
(UPROG=0).
When flash protection is active (the default after
reset if UPROG bit is set), then any read access in
the flash by a code executed from external or
internal RAM (IRAM or XRAM) will return the
value 0B88Bh. Any call of STEAK will return the
error code `01' (Protected flash).
Normally Flash protection should never be deacti-
vated, once activated. If this has to be done, for
example because the Flash memory has to be
reprogrammed with updated program / variables,
a zero value has to be written at any even address
in the active address space of the Flash memory.
This write can be done only by an instruction exe-
cuted from the internal Flash Memory itself.
For example:
MOV FLASH,ZEROS ; Deactivate Flash
Protection.
; Flash is any even address in Flash
memory space. This instruction MUST
be executed from Flash memory itself.
After this instruction, the flash is temporarily
de-protected, thus any read access of the flash
from code executed from external memory or
internal RAMs will be correctly executed, and calls
of STEAK can be correctly performed (program-
ming, erasing or status reading).
Note: 1. That all STEAK commands re-activate
the flash protection if bit UPROG is set
when completed.
5.5 - Bootstrap Loader Mode
Pin P0L.4 (BSL) activates the on-chip bootstrap
loader, when low during hardware reset. The
bootstrap loader allows moving the start code into
the internal RAM of the ST10F168 via the serial
interface ASC0. The ST10F168 will remain in
bootstrap loader mode until a hardware reset with
P0L.4 high or a software reset occurs. The boot-
straps loader acknowledge byte is D5h.
ST10F168
19/74
6 - CENTRAL PROCESSING UNIT (CPU)
The CPU includes a 4-stage instruction pipeline, a
16-bit arithmetic and logic unit (ALU) and dedi-
cated SFRs. Additional hardware has been added
for a separate multiply and divide unit, a bit-mask
generator and a barrel shifter.
Most of the ST10F168's instructions can be exe-
cuted in one instruction cycle which requires
62.5ns at 32MHz CPU clock. For example, shift
and rotate instructions are processed in one
instruction cycle independent of the number of bit
to be shifted. Multiple-cycle instructions have
been optimized: branches are carried out in 2
cycles, 16 x 16-bit multiplication in 5 cycles and a
32/16 bit division in 10 cycles.The jump cache
reduces the execution time of repeatedly per-
formed jumps in a loop, from 2 cycles to 1 cycle.
The CPU uses a bank of 16 word registers to run
the current context. This bank of General Purpose
Registers (GPR) is physically stored within the
on-chip RAM area. A Context Pointer (CP) regis-
ter determines the base address of the active reg-
ister bank to be accessed by the CPU. The
number of register banks is only restricted by the
available internal RAM space. For easy parameter
passing, one register bank may overlap others.
A system stack of up to 2048 Byte stores tempo-
rary data. The system stack is allocated in the
on-chip RAM area, and it is accessed by the CPU
via the stack pointer (SP) register. Two separate
SFRs, STKOV and STKUN, are implicitly com-
pared against the stack pointer value on each
stack access, for the detection of a stack overflow
or underflow.
Figure 5 : CPU Block Diagram
32
Internal
RAM
2K Byte
General
Purpose
Registers
R0
R15
MDH
MLD
Barrel-Shift
Mul./Div.-HW
Bit-Mask Gen.
ALU
16-Bit
CP
SP
STKOV
STKUN
Exec. Unit
Instr. Ptr
Instr. Reg
4-Stage
Pipeline
PSW
SYSCON
BUSCON 0
BUSCON 1
BUSCON 2
BUSCON 3
BUSCON 4
ADDRSEL 1
ADDRSEL 2
ADDRSEL 3
ADDRSEL 4
Data Pg. Ptrs
Code Seg. Ptr.
CPU
256K Byte
Flash
memory
16
16
Bank
n
Bank
i
Bank
0
ST10F168
20/74
6.1 - Instruction Set Summary
The Table 8 lists the instructions of the ST10F168.
The various addressing modes, instruction opera-
tion, parameters for conditional execution of
instructions, opcodes and a detailed description of
each instruction can be found in the "ST10 Family
Programming Manual".
Table 8 : Instruction set summary
Mnemonic
Description
Bytes
ADD(B)
Add Word (Byte) operands
2 / 4
ADDC(B)
Add Word (Byte) operands with Carry
2 / 4
SUB(B)
Subtract Word (Byte) operands
2 / 4
SUBC(B)
Subtract Word (Byte) operands with Carry
2 / 4
MUL(U)
(Un)Signed multiply direct GPR by direct GPR (16 x 16-bit)
2
DIV(U)
(Un)Signed divide register MDL by direct GPR (16 / 16-bit)
2
DIVL(U)
(Un)Signed long divide register MD by direct GPR (32 / 16-bit)
2
CPL(B)
Complement direct Word (Byte) GPR
2
NEG(B)
Negate direct Word (Byte) GPR
2
AND(B)
Bitwise AND, (Word / Byte operands)
2 / 4
OR(B)
Bitwise OR, (Word / Byte operands)
2 / 4
XOR(B)
Bitwise XOR, (Word / Byte operands)
2 / 4
BCLR
Clear direct bit
2
BSET
Set direct bit
2
BMOV(N)
Move (negated) direct bit to direct bit
4
BAND, BOR, BXOR
AND / OR / XOR direct bit with direct bit
4
BCMP
Compare direct bit to direct bit
4
BFLDH/L
Bitwise modify masked high / low Byte of bit-addressable direct Word memory with
immediate data
4
CMP(B)
Compare Word (Byte) operands
2 / 4
CMPD1/2
Compare Word data to GPR and decrement GPR by 1/2
2 / 4
CMPI1/2
Compare Word data to GPR and increment GPR by 1/2
2 / 4
PRIOR
Determine number of shift cycles to normalize direct Word GPR and store result in
direct Word GPR
2
SHL/SHR
Shift left / right direct Word GPR
2
ROL/ROR
Rotate left / right direct Word GPR
2
ASHR
Arithmetic (sign bit) shift right direct Word GPR
2
MOV(B)
Move Word (Byte) data
2 / 4
MOVBS
Move Byte operand to Word operand with sign extension
2 / 4
MOVBZ
Move Byte operand to Word operand. with zero extension
2 / 4
JMPA, JMPI, JMPR
Jump absolute / indirect / relative if condition is met
4
JMPS
Jump absolute to a code segment
4
J(N)B
Jump relative if direct bit is (not) set
4
JBC
Jump relative and clear bit if direct bit is set
4
ST10F168
21/74
JNBS
Jump relative and set bit if direct bit is not set
4
CALLA, CALLI, CALLR
Call absolute / indirect / relative subroutine if condition is met
4
CALLS
Call absolute subroutine in any code segment
4
PCALL
Push direct Word register onto system stack and call absolute subroutine
4
TRAP
Call interrupt service routine via immediate trap number
2
PUSH, POP
Push / pop direct Word register onto / from system stack
2
SCXT
Push direct Word register onto system stack and update register with Word operand
4
RET
Return from intra-segment subroutine
2
RETS
Return from inter-segment subroutine
2
RETP
Return from intra-segment subroutine and pop direct Word register from system
stack
2
RETI
Return from interrupt service subroutine
2
SRST
Software Reset
4
IDLE
Enter Idle Mode
4
PWRDN
Enter Power Down Mode (supposes NMI-pin being low)
4
SRVWDT
Service Watchdog Timer
4
DISWDT
Disable Watchdog Timer
4
EINIT
Signify End-of-Initialization on
RSTOUT
-pin
4
ATOMIC
Begin ATOMIC sequence
2
EXTR
Begin EXTended Register sequence
2
EXTP(R)
Begin EXTended Page (and Register) sequence
2 / 4
EXTS(R)
Begin EXTended Segment (and Register) sequence
2 / 4
NOP
Null operation
2
Table 8 : Instruction set summary
Mnemonic
Description
Bytes
ST10F168
22/74
7 - EXTERNAL BUS CONTROLLER
All external memory accesses are performed by
the on-chip external bus controller. The EBC can
be programmed to single chip mode when no
external memory is required, or to one of four dif-
ferent external memory access modes :
16 / 18 / 20 / 24-bit addresses and 16-bit data,
demultiplexed.
16 / 18 / 20 / 24-bit addresses and 16-bit data,
multiplexed.
16 / 18 / 20 / 24-bit addresses and 8-bit data,
multiplexed.
16 / 18 / 20 / 24-bit addresses and 8-bit data,
demultiplexed.
In demultiplexed bus modes addresses are output
on Port1 and data are input / output on Port0 or
P0L, respectively. In the multiplexed bus modes
both addresses and data use Port0 for input / out-
put.
Timing characteristics of the external bus inter-
face (memory cycle time, memory tri-state time,
length of ALE and read / write delay) are program-
mable giving the choice of a wide range of memo-
ries and external peripherals. Up to 4 independent
address windows may be defined (using register
pairs ADDRSELx / BUSCONx) to access different
resources and bus characteristics. These address
windows are arranged hierarchically where
BUSCON4 overrides BUSCON3 and BUSCON2
overrides BUSCON1. All accesses to locations
not covered by these 4 address windows are con-
trolled by BUSCON0. Up to 5 external CS signals
(4 windows plus default) can be generated in
order to save external glue logic. Access to very
slow memories is supported by a `Ready' function.
A HOLD/HLDA protocol is available for bus arbi-
tration which shares external resources with other
bus masters. The bus arbitration is enabled by
setting bit HLDEN in register SYSCON. After set-
ting HLDEN once, pins P6.7...P6.5 (BREQ,
HLDA, HOLD) are automatically controlled by the
EBC. In master mode (default after reset) the
HLDA pin is an output. By setting bit DP6.7 to'1'
the slave mode is selected where pin HLDA is
switched to input. This directly connects the slave
controller to another master controller without
glue logic.
For applications which require less external
memory space, the address space can be
restricted to 1M Byte, 256K Byte or to 64K Byte.
Port4 outputs all 8 address lines if an address
space of 16M Byte is used, otherwise four, two or
no address lines.
Chip select timing can be programmed. By default
(after reset), the CSx lines change half a CPU
clock cycle after the rising edge of ALE. With the
CSCFG bit set in the SYSCON register the CSx
lines can change with the rising edge of ALE.
The active level of the READY pin can be set by
bit RDYPOLx in the BUSCONx registers. When
the READY function is enabled for a specific
address window, each bus cycle within the win-
dow must be terminated with the active level
defined by bit RDYPOLx in the associated BUS-
CONx register.
ST10F168
23/74
8 - INTERRUPT SYSTEM
The interrupt response time for internal program
execution is from 157ns to 375ns at 32MHz CPU
clock.
The ST10F168 architecture supports several
mechanisms for fast and flexible response to ser-
vice requests that can be generated from various
sources (internal or external) to the microcontrol-
ler. Any of these interrupt requests can be ser-
viced by the Interrupt Controller or by the
Peripheral Event Controller (PEC).
In contrast to a standard interrupt service where
the current program execution is suspended and
a branch to the interrupt vector table is performed,
just one cycle is `stolen' from the current CPU
activity to perform a PEC service. A PEC service
implies a single Byte or Word data transfer
between any two memory locations with an
additional increment of either the PEC source or
the destination pointer. An individual PEC transfer
counter is implicitly decremented for each PEC
service except when performing in the continuous
transfer mode. When this counter reaches zero, a
standard interrupt is performed to the
corresponding source related vector location.
PEC services are very well suited to perform the
transmission or the reception of blocks of data.
The ST10F168 has 8 PEC channels, each of
them offers such fast interrupt-driven data transfer
capabilities.
A interrupt control register which contains an
interrupt request flag, an interrupt enable flag and
an interrupt priority bitfield is dedicated to each
existing interrupt source. Thanks to its related
register, each source can be programmed to one
of sixteen interrupt priority levels. Once starting to
be processed by the CPU, an interrupt service
can only be interrupted by a higher prioritized
service request. For the standard interrupt
processing, each of the possible interrupt sources
has a dedicated vector location.
Fast external interrupt inputs are provided to ser-
vice external interrupts with high precision
requirements. These fast interrupt inputs feature
programmable edge detection (rising edge, falling
edge or both edges). Software interrupts are sup-
ported by means of the `TRAP' instruction in com-
bination with an individual trap (interrupt) number.
Table 9 shows all the available ST10F168 inter-
rupt sources and the corresponding hard-
ware-related interrupt flags, vectors, vector
locations and trap (interrupt) numbers:
Table 9 : Interrupt sources
Source of Interrupt or PEC Service Request
Request
Flag
Enable
Flag
Interrupt
Vector
Vector
Location
Trap
Number
CAPCOM Register 0
CC0IR
CC0IE
CC0INT
00'0040h
10h
CAPCOM Register 1
CC1IR
CC1IE
CC1INT
00'0044h
11h
CAPCOM Register 2
CC2IR
CC2IE
CC2INT
00'0048h
12h
CAPCOM Register 3
CC3IR
CC3IE
CC3INT
00'004Ch
13h
CAPCOM Register 4
CC4IR
CC4IE
CC4INT
00'0050h
14h
CAPCOM Register 5
CC5IR
CC5IE
CC5INT
00'0054h
15h
CAPCOM Register 6
CC6IR
CC6IE
CC6INT
00'0058h
16h
CAPCOM Register 7
CC7IR
CC7IE
CC7INT
00'005Ch
17h
CAPCOM Register 8
CC8IR
CC8IE
CC8INT
00'0060h
18h
CAPCOM Register 9
CC9IR
CC9IE
CC9INT
00'0064h
19h
CAPCOM Register 10
CC10IR
CC10IE
CC10INT
00'0068h
1Ah
CAPCOM Register 11
CC11IR
CC11IE
CC11INT
00'006Ch
1Bh
CAPCOM Register 12
CC12IR
CC12IE
CC12INT
00'0070h
1Ch
CAPCOM Register 13
CC13IR
CC13IE
CC13INT
00'0074h
1Dh
CAPCOM Register 14
CC14IR
CC14IE
CC14INT
00'0078h
1Eh
CAPCOM Register 15
CC15IR
CC15IE
CC15INT
00'007Ch
1Fh
CAPCOM Register 16
CC16IR
CC16IE
CC16INT
00'00C0h
30h
CAPCOM Register 17
CC17IR
CC17IE
CC17INT
00'00C4h
31h
ST10F168
24/74
CAPCOM Register 18
CC18IR
CC18IE
CC18INT
00'00C8h
32h
CAPCOM Register 19
CC19IR
CC19IE
CC19INT
00'00CCh
33h
CAPCOM Register 20
CC20IR
CC20IE
CC20INT
00'00D0h
34h
CAPCOM Register 21
CC21IR
CC21IE
CC21INT
00'00D4h
35h
CAPCOM Register 22
CC22IR
CC22IE
CC22INT
00'00D8h
36h
CAPCOM Register 23
CC23IR
CC23IE
CC23INT
00'00DCh
37h
CAPCOM Register 24
CC24IR
CC24IE
CC24INT
00'00E0h
38h
CAPCOM Register 25
CC25IR
CC25IE
CC25INT
00'00E4h
39h
CAPCOM Register 26
CC26IR
CC26IE
CC26INT
00'00E8h
3Ah
CAPCOM Register 27
CC27IR
CC27IE
CC27INT
00'00ECh
3Bh
CAPCOM Register 28
CC28IR
CC28IE
CC28INT
00'00F0h
3Ch
CAPCOM Register 29
CC29IR
CC29IE
CC29INT
00'0110h
44h
CAPCOM Register 30
CC30IR
CC30IE
CC30INT
00'0114h
45h
CAPCOM Register 31
CC31IR
CC31IE
CC31INT
00'0118h
46h
CAPCOM Timer 0
T0IR
T0IE
T0INT
00'0080h
20h
CAPCOM Timer 1
T1IR
T1IE
T1INT
00'0084h
21h
CAPCOM Timer 7
T7IR
T7IE
T7INT
00'00F4h
3Dh
CAPCOM Timer 8
T8IR
T8IE
T8INT
00'00F8h
3Eh
GPT1 Timer 2
T2IR
T2IE
T2INT
00'0088h
22h
GPT1 Timer 3
T3IR
T3IE
T3INT
00'008Ch
23h
GPT1 Timer 4
T4IR
T4IE
T4INT
00'0090h
24h
GPT2 Timer 5
T5IR
T5IE
T5INT
00'0094h
25h
GPT2 Timer 6
T6IR
T6IE
T6INT
00'0098h
26h
GPT2 CAPREL Register
CRIR
CRIE
CRINT
00'009Ch
27h
A/D Conversion Complete
ADCIR
ADCIE
ADCINT
00'00A0h
28h
A/D Overrun Error
ADEIR
ADEIE
ADEINT
00'00A4h
29h
ASC0 Transmitter
S0TIR
S0TIE
S0TINT
00'00A8h
2Ah
ASC0 Transmitter Buffer
S0TBIR
S0TBIE
S0TBINT
00'011Ch
47h
ASC0 Receiver
S0RIR
S0RIE
S0RINT
00'00ACh
2Bh
ASC0 Error
S0EIR
S0EIE
S0EINT
00'00B0h
2Ch
SSC Transmitter
SCTIR
SCTIE
SCTINT
00'00B4h
2Dh
SSC Receiver
SCRIR
SCRIE
SCRINT
00'00B8h
2Eh
SSC Error
SCEIR
SCEIE
SCEINT
00'00BCh
2Fh
PWM Channel 0...3
PWMIR
PWMIE
PWMINT
00'00FCh
3Fh
CAN Interface
XP0IR
XP0IE
XP0INT
00'0100h
40h
X-Peripheral Node
XP1IR
XP1IE
XP1INT
00'0104h
41h
X-Peripheral Node
XP2IR
XP2IE
XP2INT
00'0108h
42h
PLL Unlock
XP3IR
XP3IE
XP3INT
00'010Ch
43h
Table 9 : Interrupt sources (continued)
Source of Interrupt or PEC Service Request
Request
Flag
Enable
Flag
Interrupt
Vector
Vector
Location
Trap
Number
ST10F168
25/74
Hardware traps are exceptions or error conditions
that arise during run-time. They cause immediate
non-maskable system reaction similar to a stan-
dard interrupt service (branching to a dedicated
vector table location).
The occurrence of a hardware trap is
additionally signified by an individual bit in the
trap flag register (TFR). Except when another
higher prioritized trap service is in progress, a
hardware trap will interrupt any other program
execution.
Hardware trap services cannot not be interrupted
by standard interrupt or by PEC interrupts.
Table 10 shows all of the possible exceptions or
error conditions that can arise during run-time :
Table 10 : Exceptions or error conditions that can arise during run-time
Exception Condition
Trap Flag Trap Vector
Vector Location
Trap Number
Trap Priority
Reset Functions
Hardware Reset
RESET
00'0000h
00h
III
Software Reset
RESET
00'0000h
00h
III
Watchdog Timer Overflow
RESET
00'0000h
00h
III
Class A Hardware Traps
Non-Maskable Interrupt
NMI
NMITRAP
00'0008h
02h
II
Stack Overflow
STKOF
STOTRAP
00'0010h
04h
II
Stack Underflow
STKUF
STUTRAP
00'0018h
06h
II
Class B Hardware Traps
Undefined Opcode
UNDOPC
BTRAP
00'0028h
0Ah
I
Protected Instruction Fault
PRTFLT
BTRAP
00'0028h
0Ah
I
Illegal Word Operand Access
ILLOPA
BTRAP
00'0028h
0Ah
I
Illegal Instruction Access
ILLINA
BTRAP
00'0028h
0Ah
I
Illegal External Bus Access
ILLBUS
BTRAP
00'0028h
0Ah
I
Reserved
[2Ch 3Ch]
[0Bh 0Fh]
Software Traps
TRAP Instruction
Any [00'0000h 00'01FCh]
in steps of 4h
Any [00h 7Fh] Current CPU
Priority
ST10F168
26/74
9 - CAPTURE / COMPARE (CAPCOM) UNIT
The ST10F168 has two 16 channel CAPCOM
units which support generation and control of
timing sequences on up to 32 channels with a
maximum resolution of 320ns at 32MHz CPU
clock.
The CAPCOM units are typically used to handle
high speed I/O tasks such as pulse and waveform
generation, pulse width modulation (PMW), Digital
to Analog (D/A) conversion, software timing, or
time recording relative to external events.
Four 16-bit timers (T0/T1, T7/T8) with reload
registers provide two independent time bases for
the capture / compare register array.
The input clock for the timers is programmable to
several prescaled values of the internal system
clock, or may be derived from an overflow / under-
flow of timer T6 in module GPT2.
This provides a wide range of variation for the
timer period and resolution and allows precise
adjustments to application specific requirements.
In addition, external count inputs for CAPCOM
timers T0 and T7 allow event scheduling for the
capture / compare registers relative to external
events.
Each of the two capture / compare register arrays
contain 16 dual purpose capture / compare regis-
ters, each of which may be individually allocated
to either CAPCOM timer T0 or T1 (T7 or T8,
respectively), and programmed for capture
or compare functions. Each register has one
associated port pin which serves as an input pin
for triggering the capture function, or as an output
pin (except for CC24...CC27) to indicate the
occurrence of a compare event.
When a capture / compare register has been
selected for capture mode, the current contents of
the allocated timer will be latched (captured) into
the dedicated capture / compare register in
response to an external event at the
corresponding port pin which is associated with
this register. In addition, a specific interrupt
request for this capture / compare register is
generated.
Either a positive, a negative, or both a positive
and a negative external signal transition at the pin
can be selected as the triggering event.
The contents of all the registers which have been
selected for one of the five compare modes are
continuously compared with the contents of the
allocated timers.
When a match occurs between the timer value
and the value in a capture / compare register, spe-
cific actions will be taken based on the selected
compare mode.
The input frequencies f
Tx
, for the timer input
selector Txl, are determined as a function of the
CPU clock. The timer input frequencies, the reso-
lution and the periods which result from the
selected pre-scaler option in TxI when using a
25MHz CPU clock are listed in the Table 12.
The numbers of the timer periods are based on a
reload value of 0000h. Note that some numbers
are rounded to 3 significant figures.
Table 11 : Compare Modes
Compare Modes
Function
Mode 0
Interrupt-only compare mode ; several compare interrupts per timer period are possible.
Mode 1
Pin toggles on each compare match ; several compare events per timer period are possible.
Mode 2
Interrupt-only compare mode ; only one compare interrupt per timer period is generated.
Mode 3
Pin set `1' on match; pin reset `0' on compare time overflow ; only one compare event per
timer period is generated.
Double Register Mode Two registers operate on one pin; pin toggles on each compare match ; several compare
events per timer period are possible.
ST10F168
27/74
Table 12 : CAPCOM timer input frequencies, resolution and periods
Note: 1. Input only.
f
CPU
= 25MHz
Timer Input Selection TxI
000b
001b
010b
011b
100b
101b
110b
111b
f
CPU
pre-scaler
8
16
32
64
128
256
512
1024
Input Frequency
3.125MHz 1.56MHz
781KHz
391KHz
195KHz
97.7KHz
48.8KHz
24.4KHz
Resolution
320ns
640ns
1.28s
2.56s
5.12s
10.24s
20.48s
40.96s
Period
21.0ms
41.9ms
83.9ms
167ms
336ms
671ms
1.34s
2.68s
Table 13 : CAPCOM Channels Pin Assignement
CAPCOM
Unit
Channel
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CAPCOM1 I/O
CC0
CC1
CC2
CC3
CC4
CC5
CC6
CC7
CC8
1
CC9
1
CC10
1
CC11
1
CC12 CC13 CC14 CC15
Port
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
2.10
2.11
2.12
2.13
2.14
2.15
Pin Number
47
48
49
50
51
52
53
54
57
58
59
60
61
62
63
64
CAPCOM2 I/O
CC16 CC17 CC18 CC19 CC20 CC21 CC22 CC23 CC24 CC25
CC26
CC27
CC28 CC29 CC30 CC31
Port
8.0
8.1
8.2
8.3
8.4
8.5
8.6
8.7
1H.4
1H.5
1H.6
1H.7
7.4
7.5
7.6
7.7
Pin Number
9
10
11
12
13
14
15
16
132
133
134
135
23
24
25
26
ST10F168
28/74
10 - GENERAL PURPOSE TIMER UNIT
The GPT unit is a flexible multifunctional timer /
counter structure which is used for time related
tasks such as event timing and counting, pulse
width and duty cycle measurements, pulse
generation, or pulse multiplication. The GPT unit
contains five 16-bit timers organized into two
separate modules GPT1 and GPT2. Each timer
in each module may operate independently in
several different modes, or may be concatenated
with another timer of the same module.
10.1 - GPT1
Each of the three timers T2, T3, T4 of the GPT1
module can be configured individually for one of
four basic modes of operation: timer, gated
timer, counter mode and incremental interface
mode. In timer mode, the input clock for a timer is
derived from the CPU clock, divided by a pro-
grammable prescaler. In counter mode, the timer is
clocked in reference to external events. Pulse width
or duty cycle measurement is supported in gated
timer mode where the operation of a timer is con-
trolled by the `gate' level on an external input pin.
For these purposes, each timer has one associated
port pin (TxIN) which serves as gate or clock input.
Table 14 lists the timer input frequencies, resolu-
tion and periods for each pre-scaler option at
25MHz CPU clock. This also applies to the Gated
Timer Mode of T3 and to the auxiliary timers T2
and T4 in Timer and Gated Timer Mode.
The count direction (up / down) for each timer is
programmable by software or may be altered
dynamically by an external signal on a port pin
(TxEUD).
In Incremental Interface Mode, the GPT1 timers
(T2, T3, T4) can be connected directly to the
incremental position sensor signals A and B by
their respective inputs TxIN and TxEUD. Direction
and count signals are internally derived from
these two input signals so that the contents of the
respective timer Tx corresponds to the sensor
position. The third position sensor signal TOP0
can be connected to an interrupt input.
Timer T3 has output toggle latches (TxOTL) which
changes state on each timer over-flow / under-
flow. The state of this latch may be output on port
pins (TxOUT) e. g. for time out monitoring of
external hardware components, or may be used
internally to clock timers T2 and T4 for high reso-
lution of long duration measurements.
In addition to their basic operating modes, timers
T2 and T4 may be configured as reload or capture
registers for timer T3. When used as capture or
reload registers, timers T2 and T4 are stopped.
The contents of timer T3 is captured into T2 or T4
in response to a signal at their associated input
pins (TxIN). Timer T3 is reloaded with the
contents of T2 or T4 triggered either by an
external signal or by a selectable state transition
of its toggle latch T3OTL. When both T2 and T4
are configured to alternately reload T3 on
opposite state transitions of T3OTL with the low
and high times of a PWM signal, this signal
can be constantly generated without software
intervention.
10.2 - GPT2
The GPT2 module provides precise event control
and time measurement. It includes two timers (T5,
T6) and a capture / reload register (CAPREL).
Both timers can be clocked with an input clock
which is derived from the CPU clock via a pro-
grammable prescaler or with external signals. The
count direction (up / down) for each timer is pro-
grammable by software or may additionally be
altered dynamically by an external signal on a port
pin (TxEUD). Concatenation of the timers is sup-
ported via the output toggle latch (T6OTL) of timer
T6 which changes its state on each timer
overflow / underflow.
Table 14 : GPT1 timer input frequencies, resolution and periods
f
CPU
= 25MHz
Timer Input Selection T2I / T3I / T4I
000b
001b
010b
011b
100b
101b
110b
111b
Pre-scaler Factor
8
16
32
64
128
256
512
1024
Input Frequency
3.125MHz 1.563MHz 781.3MHz
390KHz
195.3KHz
97.66KHz
48.83KHz
24.41KHz
Resolution
320ns
640ns
1.28s
2.56s
5.12s
10.24s
20.48s
40.96s
Period
21.0ms
41.9ms
83.9ms
167ms
336ms
671ms
1.34s
2.68s
ST10F168
29/74
The state of this latch may be used to clock timer
T5, or it may be output on a port pin (T6OUT).
The overflows / underflows of timer T6 can also be
used to clock the CAPCOM timers T0 or T1, and
to cause a reload from the CAPREL register.
The CAPREL register can capture the contents of
T5 from an external signal transition on the
corresponding port pin (CAPIN), and T5 may be
optionally cleared after the capture procedure.
This allows absolute time differences to be
measured or pulse multiplication to be performed
without software overhead.
The capture trigger (timer T5 to CAPREL) may
also be generated on transitions of GPT1 timer T3
inputs T3IN and / or T3EUD. This is useful when
T3 operates in Incremental Interface Mode.
Table 15 GPT2 timer input frequencies, resolution
and periods lists the timer input frequencies, reso-
lution and periods for each pre-scaler option at
25MHz CPU clock. This also applies to the Gated
Timer Mode of T6 and to the auxiliary timer T5 in
Timer and Gated Timer Mode.
Table 15 : GPT2 timer input frequencies, resolution and periods
f
CPU
= 25MHz
Timer Input Selection T5I / T6I
000b
001b
010b
011b
100b
101b
110b
111b
Pre-scaler Factor
4
8
16
32
64
128
256
512
Input Frequency
6.25MHz 3.125MHz 1.563MHz 781.3KHz
390KHz
195.3KHz 97.66KHz 48.83KHz
Resolution
160ns
320ns
640ns
1.28s
2.56s
5.12s
10.24s
20.48s
Period
10.49ms
21.0ms
41.9ms
83.9ms
167ms
336ms
671ms
1.34s
Figure 6 : Block Diagram of GPT1
2
n
n=3...10
2
n
n=3...10
2
n
n=3...10
T2EUD
T2IN
CPU Clock
CPU Clock
CPU Clock
T3EUD
T4IN
T3IN
T4EUD
T2
Mode
Control
T3
Mode
Control
T4
Mode
Control
GPT1 Timer T2
GPT1 Timer T3
GPT1 Timer T4
T3OTL
Reload
Capture
U/D
U/D
Reload
Capture
Interrupt
Request
Interrupt
Request
Interrupt
Request
T3OUT
U/D
ST10F168
30/74
Figure 7 : Block Diagram of GPT2
2n n=2...9
2n n=2...9
T5EUD
T5IN
CPU Clock
CPU Clock
T6IN
T6EUD
T5
Mode
Control
T6
Mode
Control
GPT2 Timer T5
GPT2 Timer T6
U/D
Interrupt
Request
U/D
T60TL
Toggle FF
T6OUT
CAPIN
Reload
Interrupt
Request
to CAPCOM
Timers
Capture
Clear
Interrupt
Request
GPT2 CAPREL
ST10F168
31/74
11 - PWM MODULE
The pulse width modulation module can generate
up to four PWM output signals using edge-aligned
or centre-aligned PWM. In addition, the PWM
module can generate PWM burst signals and sin-
gle shot outputs. The Table 16 shows the PWM
frequencies for different resolutions. The level of
the output signals is selectable and the PWM
module can generate interrupt requests.
Table 16 : PWM unit frequencies and resolution at 25MHz CPU clock
Mode 0
Resolution
8-bit
10-bit
12-bit
14-bit
16-bit
CPU Clock / 1
40ns
97.66KHz
24.41KHz
6.104KHz
1.526KHz
0.381Hz
CPU Clock / 64
2.56
s
1.526KHz
381.5Hz
95.37Hz
23.84Hz
5.96Hz
Mode 1
Resolution
8-bit
10-bit
12-bit
14-bit
16-bit
CPU Clock / 1
40ns
48.82KHz
12.20KHz
3.05KHz
762.9Hz
190.7Hz
CPU Clock / 64
2.56
s
762.9Hz
190.7Hz
47.68Hz
11.92Hz
2.98Hz
Figure 8 : PWM Module Block Diagram
PPx Period Register
Comparator
PTx
16-Bit Up/Down Counter
Shadow Register
PWx Pulse Width Register
Input
Run
Control
Clock 1
Clock 2
Comparator
*
*
*
Up/Down/
Clear Control
Match
Output Control
Match
Write Control
* User readable & writeable register
Enable
POUTx
ST10F168
32/74
12 - PARALLEL PORTS
The ST10F168 provides up to 111 I/O lines
organized into eight input / output ports and one
input port. All port lines are bit-addressable, and
all input / output lines are individually (bit-wise)
programmable as input or output via direction
registers. The I/O ports are true bidirectional ports
which are switched to high impedance state when
configured as inputs. The output drivers of five I/O
ports can be configured (pin by pin) for push-pull
operation or open-drain operation via control
registers. During the internal reset, all port pins
are configured as inputs.
The input threshold of Port 2, Port 3, Port 7 and
Port 8 is selectable (TTL or CMOS-like), where
the special CMOS-like input threshold reduces
noise sensitivity to the input hysteresis. The input
thresholds are selected with bit of PICON register
dedicated to blocks of 8 input pins (2-bit for Port2,
2-bit for Port3, 1-bit for Port7, 1-bit for Port8).
All pins of I/O ports also support an alternate pro-
grammable function:
Port0 and Port1 may be used as address and
data lines when accessing external memory.
Port 2, Port 7 and Port 8 are associated with the
capture inputs or with the compare outputs of
the CAPCOM units and / or with the outputs of
the PWM module.
Port 3 includes the alternate functions of timers,
serial interfaces, the optional bus control signal
BHE and the system clock output (CLKOUT).
Port 4 outputs the additional segment address
bit A16 to A23 in systems where segmentation
is enabled to access more than 64K Byte of
memory.
Port 5 is used as analog input channels of the
A/D converter or as timer control signals.
Port 6 provides optional bus arbitration signals
(BREQ, HLDA, HOLD) and chip select signals.
All port lines that are not used for alternate func-
tions may be used as general purpose I/O lines.
ST10F168
33/74
13 - A/D CONVERTER
A10-bit A/D converter with 16 multiplexed input
channels and a sample and hold circuit is
integrated on-chip. The sample time (for loading
the capacitors) and the conversion time is
programmable and can be adjusted to the
external circuitry.
Overrun error detection / protection is controlled by
the ADDAT register. Either an interrupt request is
generated when the result of a previous conversion
has not been read from the result register at the
time the next conversion is complete, or the next
conversion is suspended until the previous result
has been read. For applications which require less
than 16 analog input channels, the remaining chan-
nel inputs can be used as digital input port pins.
The A/D converter of the ST10F168 supports dif-
ferent conversion modes :
Single channel single conversion : the analog
level of the selected channel is sampled once
and converted. The result of the conversion is
stored in the ADDAT register.
Single channel continuous conversion : the
analog level of the selected channel is repeatedly
sampled and converted. The result of the conver-
sion is stored in the ADDAT register.
Auto scan single conversion : the analog level
of the selected channels are sampled once and
converted. After each conversion the result is
stored in the ADDAT register. The data can be
transfered to the RAM by interrupt software
management or using the powerfull Peripheral
Event Controller data transfert.
Auto scan continuous conversion : the ana-
log level of the selected channels are repeatedly
sampled and converted. The result of the con-
version is stored in the ADDAT register. The
data can be transfered to the RAM by interrupt
software management or using the powerfull
Peripheral Event Controller data transfert.
Wait for ADDAT read mode : when using con-
tinuous modes, in order to avoid to overwrite
the result of the current conversion by the next
one, the ADWR bit of ADCON control register
must be activated. Then, until the ADDAT regis-
ter is read, the new result is stored in a tempo-
rary buffer and the conversion is on hold.
Channel injection mode : when using
continuous modes, a selected channel can be
converted in between without changing the
current operating mode. The 10 bit data of the
conversion are stored in ADRES field of
ADDAT2. The current continuous mode remains
active after the single conversion is completed.
The Table 17 ADC sample clock and conversion
clock shows conversion clock and sample clock of
the ADC unit. A complete conversion will take
14t
CC
+ 2t
SC
+ 4TCL. This time includes the con-
version it self, the sampling time and the time
required to transfer the digital value to the result
register. For example at 25MHz of CPU clock, the
minimum complete conversion time is 7.76
s.
The A/D converter provides automatic offset and
linearity self calibration. The calibration operation
is performed in two ways :
A full calibration sequence is performed after a
reset and lasts 1.25ms minimum (at 25MHz
CPU clock). During this time, the ADBSY flag is
set to indicate the operation. Normal conversion
can be performed during this time. The duration
of the calibration sequence is then extended by
the time consumed by the conversions.
Note : After a power-on reset, the total
unadjusted error (TUE) of the ADC might be
worse than 2LSB (max. 4LSB). During the full
calibration sequence, the TUE is constantly
improved until at the end of the cycle, TUE is
within the specified limits of 2LSB.
One calibration cycle is performed after each
conversion : each calibration cycle takes 4 ADC
clock cycles. These operation cycles ensure
constant updating of the ADC accuracy, com-
pensating changing operating conditions.
Notes: 1. See Section 20.5.5 - Direct Drive on page 55.
2. t
CC
= TCL x 24.
Table 17 : ADC sample clock and conversion clock
ADCTC
Conversion Clock t
CC
ADSTC
Sample Clock t
SC
TCL
1
= 1/2 x f
XTAL
At f
CPU
= 25MHz
t
SC
=
At f
CPU
= 25MHz
00
TCL x 24
0.48
s
00
t
CC
0.48
s
2
01
Reserved, do not use
Reserved
01
t
CC
x 2
0.96
s
2
10
TCL x 96
1.92
s
10
t
CC
x 4
1.92
s
2
11
TCL x 48
0.96
s
11
t
CC
x 8
3.84
s
2
ST10F168
34/74
14 - SERIAL CHANNELS
Serial communication with other microcontrollers,
processors, terminals or external peripheral com-
ponents is provided by two serial interfaces: the
asynchronous / synchronous serial channel
(ASC0) and the high-speed synchronous serial
channel (SSC).
Two dedicated Baud rate generators set up all
standard Baud rates without the requirement of
oscillator tuning. For transmission, reception and
erroneous reception, 3 separate interrupt vectors
are provided for each serial channel.
ASC0
ASC0 supports full-duplex asynchronous commu-
nication at up to 781.25K Baud and half-duplex
synchronous communication up to 5M Baud at
25MHz system clock.
For asynchronous operation, the Baud rate gener-
ator provides a clock with 16 times the rate of the
established Baud rate.
Table 18 lists various commonly used Baud rates
together with the required reload values and the
deviation errors compared to the intended
Baud rate.
For synchronous operation, the Baud rate genera-
tor provides a clock with 4 times the rate of the
established Baud rate.
Table 18 : Commonly used Baud rates by reload value and deviation errors
S0BRS = `0', f
CPU
= 25MHz
S0BRS = `1', f
CPU
= 25MHz
Baud Rate (Baud)
Deviation Error
Reload Value
Baud Rate (Baud)
Deviation Error
Reload Value
781 250
0.0%
0000h
520 833
0.0%
0000h
56 000
+7.3% / -0.4%
000Ch / 000Dh
56 000
+3.3% / -7.0%
0008h / 0009h
38 400
+1.7% / -3.1%
0013h / 0014h
38 400
+4.3% / -3.1%
000Ch / 000Dh
19 200
+1.7% / -0.8%
0027h / 0028h
19 200
+0.5% / -3.1%
001Ah / 001Bh
9 600
+0.5% / -0.8%
0050h/ 0051h
9 600
+0.5% / -1.4%
0035h / 0036h
4 800
+0.5% / -0.1%
00A1h / 00A2h
4 800
+0.5% / -0.5%
006Bh / 006Ch
2 400
+0.2% / -0.1%
0144h / 0145h
2 400
+0.0% / -0.5%
00D8h / 00D9h
1 200
+0.0% / -0.1%
028Ah / 028Bh
1 200
+0.0% / -0.2%
01B1h / 01B2h
600
+0.0% / -0.1%
0515h / 0516h
600
+0.0% / -0.1%
0363h / 0364h
95
+0.4%
1FFFh / 1FFFh
75
+0.0% / -0.0%
1B1Fh / 1B20h
63
+0.9%
1FFFh / 1FFFh
ST10F168
35/74
High Speed Synchronous Serial Channel (SSC)
The High-Speed Synchronous Serial Interface
SSC provides flexible high-speed serial communi-
cation between the ST10F168 and other microcon-
trollers, microprocessors or external peripherals.
The SSC supports full-duplex and half-duplex syn-
chronous communication; The serial clock signal
can be generated by the SSC itself (master mode)
or be received from an external master (slave
mode). Data width, shift direction, clock polarity
and phase are programmable.
This allows communication with SPI-compatible
devices. Transmission and reception of data is
double-buffered. A 16-bit Baud rate generator pro-
vides the SSC with a separate serial clock signal.
The serial channel SSC has its own dedicated
16-bit Baud rate generator with 16-bit reload
capability, allowing Baud rate generation indepen-
dent from the timers.
SSCBR is the dual-function Baud rate Generator /
Reload register. Table 19 lists some possible
Baud rates against the required reload values and
the resulting bit times for a 25MHz CPU clock.
Note: The deviation errors given in the Table 18
are rounded. To avoid deviation errors use
a Baud rate crystal (providing a multiple of
the ASC0/SSC sampling frequency).
Table 19 : Synchronous Baud rate and reload
values
Baud Rate
Bit Time
Reload Value
Reserved use a
reload value > 0.
---
0000h
5M Baud
200ns
0001h
3.3M Baud
303ns
0002h
2.5M Baud
400ns
0004h
2M Baud
500ns
0005h
1M Baud
1
s
000Bh
100K Baud
10
s
007Ch
10K Baud
100
s
04E1h
1K Baud
1ms
30D3h
190.7 Baud
5.2ms
FFFFh
ST10F168
36/74
15 - CAN MODULE
The integrated CAN module completely handles
the autonomous transmission and the reception of
CAN frames according to the CAN specification
V2.0 part B (active). The on-chip CAN module can
receive and transmit standard frames with 11-bit
identifiers as well as extended frames with 29-bit
identifiers.
The CAN Module Provides full CAN functionality
on up to 15 message objects. Message object 15
can be configured for basic CAN functionality.
Both modes provide separate masks for accep-
tance filtering, allowing a number of identifiers in
full CAN mode to be accepted and disregarding a
number of identifiers in basic CAN mode. All mes-
sage objects can be updated independently from
other objects and are equipped for the maximum
message length of 8 Bytes.
The bit timing is derived from the XCLK and is pro-
grammable up to a data rate of 1M Baud. The
CAN module uses two pins to interface to a bus
transceiver.
16 - WATCHDOG TIMER
The Watchdog Timer is a fail-safe mechanism
which prevents the microcontroller from malfunc-
tioning for long periods of time.
The Watchdog Timer is always enabled after a
reset of the chip and can only be disabled in the
time interval until the EINIT (end of initialization)
instruction has been executed.
Therefore, the chip start-up procedure is always
monitored. The software must be designed to ser-
vice the watchdog timer before it overflows. If, due
to hardware or software related failures, the soft-
ware fails to do so, the watchdog timer overflows
and generates an internal hardware reset. It pulls
the RSTOUT pin low in order to allow external
hardware components to be reset.
The Watchdog Timer is 16-bit, clocked with the
system clock divided by 2 or 128. The high Byte of
the watchdog timer register can be set to a
pre-specified reload value (stored in WDTREL).
Each time it is serviced by the application soft-
ware, the high Byte of the watchdog timer is
reloaded.
For security, rewrite WDTCON each
time before the watchdog timer is serviced.
Table 20 shows the watchdog time range for
25MHz CPU clock.
Table 20 : Watchdog time range (25MHz clock)
Reload value
in WDTREL
Prescaler for f
CPU
2 (WDTIN = `0')
128 (WDTIN = `1')
FFh
20.48
s
1.31ms
00h
5.24ms
336ms
ST10F168
37/74
17 - SYSTEM RESET
System reset initializes the MCU in a predefined
state. There are five ways to activate a reset state.
The system start-up configuration is different for
each case as shown in Table 21.
17.1 - Asynchronous Reset (Long Hardware Reset)
An asynchronous reset is triggered when RSTIN
pin is pulled low while V
PP
pin is at low level. Then
the MCU is immediately forced in reset default
state. It pulls low RSTOUT pin, it cancels pending
internal hold states if any, it waits for any internal
access cycles to finish, it aborts external bus cycle,
it switches buses (data, address and control sig-
nals) and I/O pin drivers to high-impedance, it pulls
high Port0 pins and the reset sequence starts.
Power-on Reset
The asynchronous reset must be used during the
power-on of the MCU. Depending on crystal fre-
quency, the on-chip oscillator needs about 10ms
to 50ms to stabilize. The logic of the MCU does
not need a stabilized clock signal to detect an
asynchronous reset, so it is suitable for power-on
conditions. To ensure a proper reset sequence,
the RSTIN pin and the V
PP
pin must be held at low
level until the MCU clock signal is stabilized and
the system configuration value on Port0 is settled.
Hardware Reset
The asynchronous reset must be used to recover
from catastrophic situations of the application. It
may be triggerred by the hardware of the applica-
tion. Internal hardware logic and application cir-
cuitry are described in Reset circuitry chapter and
Figures 12, 13 and 14.
Exit of Asynchrounous Reset State
When the RSTIN pin is pulled high, the MCU
restarts. The system configuration is latched from
Port0 and ALE, RD and R/W pins are driven to their
inactive level. The MCU starts program execution
from memory location 00'0000h in code segment 0.
This starting location will typically point to the gen-
eral initialization routine. Timing of asynchronous
reset sequence are summarized in Figure 9.
Note: 1. RSTIN rising edge to internal latch of Port0 is 3CPU clock cycles (6 TCL) if the PLL is bypassed and the prescaler is on
(f
CPU
= f
XTAL
/ 2), else it is 4 CPU clock cycles (8 TCL).
Table 21 : Reset event definition
Reset Source
Short-cut
Conditions
Power-on reset
PONR
Power-on
Long Hardware reset (synchronous & asynchronous)
LHWR
t
RSTIN
> 1032 TCL
Short Hardware reset (synchronous reset)
SHWR
4 TCL < t
RSTIN
< 1032 TCL
Watchdog Timer reset
WDTR
WDT overflow
Software reset
SWR
SRST execution
Figure 9 : Asynchronous Reset Timing
6 or 8 TCL
1
CPU Clock
RSTIN
Asynchronous
Reset Condition
V
PP
RSTOUT
ALE
Port0
Reset Configuration
INST #1
Internal
Reset
Signal
Latching point of Port0
for system start-up
configuration
ST10F168
38/74
17.2 - Synchronous Reset (Warm Reset)
A synchronous reset is triggered when RSTIN pin
is pulled low while V
PP
pin is at high level. In order
to properly activate the internal reset logic of the
MCU, the RSTIN pin must be held low, at least,
during 4 TCL (2 periods of CPU clock). The I/O
pins are set to high impedance and RSTOUT pin is
driven low. After RSTIN level is detected, a short
duration of 12 TCL (approximately 6 periods of
CPU clock) elapes, during which pending internal
hold states are cancelled and the current internal
access cycle if any is completed. External bus
cycle is aborted. The internal pulldown of RSTIN
pin is activated if bit BDRSTEN of SYSCON reg-
ister was previously set by software. This bit is
always cleared on power-on or after a reset
sequence.
Exit of Synchrounous Reset State
The internal reset sequence starts for 1024 TCL
(512 periods of CPU clock) and RSTIN pin level is
sampled. The reset sequence is extended until
RSTIN level becomes high. Then, the MCU
restarts. The system configuration is latched from
Port0 and ALE, RD and R/W pins are driven to
their inactive level. The MCU starts program exe-
cution from memory location 00'0000h in code
segment 0. This starting location will typically
point to the general initialization routine. Timing of
synchronous reset sequence are summarized in
Figure 10 and 11.
Notes: 1. RSTIN assertion can be released there.
2. If during the reset condition (RSTIN low), Vpp voltage drops below the threshold voltage (about 2.5V for 5V operation), the
asynchronous reset is then immediately entered.
3. RSTIN rising edge to internal latch of Port0 is 3CPU clock cycles (6 TCL) if the PLL is bypassed and the prescaler is on
(f
CPU
= f
XTAL
/ 2)
, else it is 4 CPU clock cycles (8 TCL).
4) RSTIN pin is pulled low if bit BDRSTEN (bit 5 of SUSCON register) was previously set by software. Bit BDRSTEN is cleared after
reset.
Figure 10 : Synchronous Warm Reset: Short low pulse on RSTIN
CPU Clock
RSTIN
V
PP
RSTOUT
ALE
Port0
INST #1
Internal
Reset
Signal
Latching point of Port0
for system start-up configuration
6 or 8 TCL
3
4 TCL
12 TCL
min.
max.
1024 TCL
1
Internally pulled low
4
Reset Configuration
2
V
PP
> 2.5V Asynchronous Reset not entered.
200
A Discharge
ST10F168
39/74
Figure 11 : Synchronous Warm Reset: Long low pulse on RSTIN
Notes: 1. RSTIN rising edge to internal latch of Port0 is 3CPU
clock cycles (6 TCL) if the PLL is bypassed and the
prescaler is on (f
CPU
= f
XTAL
/ 2), else it is 4 CPU clock
cycles (8 TCL).
2. If during the reset condition (RSTIN low), Vpp voltage
drops below the threshold voltage (about 2.5V for 5V
operation), the asynchronous reset is then immediately
entered.
3. RSTIN pin is pulled low if bit BDRSTEN (bit 5 of
SYSCON register) was previously set by soft-ware. Bit
BDRSTEN is cleared after reset.
17.3 - Software Reset
A software reset sequence can be triggered at
any time by the protected SRST (software reset)
instruction. This instruction can be deliberately
executed within a program, e.g. to leave bootstrap
loader mode, or on a hardware trap that reveals
system failure.
On execution of the SRST instruction, the internal
reset sequence is started. The microcontroller
behaviour is the same as for a synchronous reset,
except that only bit P0.12...P0.8 are latched at the
end of the reset sequence, while previously
latched, bit P0.7...P0.2 are cleared.
17.4 - Watchdog Timer Reset
When the watchdog timer is not disabled during
the initialization, or serviced regularly during pro-
gram execution, it will overflow and trigger the
reset sequence.
Unlike hardware and software resets, the watch-
dog reset completes a running external bus cycle
if this bus cycle either does not use READY, or if
READY is sampled active (low) after the pro-
grammed wait states. When READY is sampled
inactive (high) after the programmed wait states
the running external bus cycle is aborted. Then
the internal reset sequence is started.
Bit P0.12...P0.8 are latched at the end of the reset
sequence and bit P0.7...P0.2 are cleared.
17.5 - Reset Circuitry
Internal reset circuitry is described in Figure 13.
The RSTIN pin provides an internal pullup resistor
of 50K
to 250K
(The minimum reset time must
be calculated using the lowest value). It also pro-
vides a programmable (BDRSTEN bit of SYSCON
register) pulldown to output internal reset state
signal (synchronous reset, watchdog timer reset
or software reset).
This bidirectional reset function is useful in appli-
cations where external devices require a reset sig-
nal but cannot be connected to RSTOUT pin.
This is the case of an external memory running
codes before EINIT ( end of initialization) instruc-
tion is executed. RSTOUT pin is pulled high only
when EINIT is executed.
The V
PP
pin provides an internal weak pulldown
resistor which discharges external capacitor at a
typical rate of 200
A. If bit PWDCFG of SYSCON
register is set, an internal pullup resistor is acti-
vated at the end of the reset sequence. This pul-
lup will charge any capacitor connected on V
PP
pin.
CPU Clock
RSTIN
V
PP
RSTOUT
ALE
Port0
Internal
Reset
Signal
Latching point of Port0
for system start-up configuration
6 or 8 TCL
1
4 TCL
12 TCL
1024 TCL
Internally pulled low
3
Reset Configuration
2
V
PP
> 2.5V Asynchronous Reset not entered.
200
A Discharge
ST10F168
40/74
The simplest way to reset the ST10F168 is to
insert a capacitor C1 between RSTIN pin and V
SS
,
and a capacitor between V
PP
pin and V
SS
(C0)
with a pullup resistor R0 between V
PP
pin and
V
CC
. The input RSTIN provides an internal pullup
device equalling a resistor of 50k
to 150k
(the
minimum reset time must be determined by the
lowest value). Select C1 that produce a sufficient
discharge time to permit the internal or external
oscillator and / or internal PLL to stabilize.
To insure correct power-up reset with controlled
supply current consumption, specially if clock sig-
nal requires a long period of time to stabilized, an
asynchronous hardware reset is required during
power-up. It is recommended to connect the exter-
nal R0C0 circuit shown in Figure 12 to the V
PP
pin. On power-up, the logical low level on V
PP
pin
forces an asynchronous harware reset when
RSTIN is asserted.
The external pullup R0 will then charge the capac-
itor C0. Note that an internal pulldown device on
V
PP
pin is turned on when RSTIN pin is low, and
causes the external capacitor (C0) to begin dis-
charging at a typical rate of 100
A to 200
A. With
this mechanism, after power-up reset, short low
pulses applied on RSTIN produce synchronous
hardware reset. If RSTIN is asserted longer than
the time needed for C0 to be discharged by the
internal pulldown device, then the device is forced
in an asynchronous reset. This mechanism
insures recovery from very catastrophic failure.
Figure 12 : Minimum External Reset Circuitry
RSTOUT
V
PP
RSTIN
C1
a) Hardware
V
CC
+
C0
R0
ST10F168
b) For Power-up
(and Interruptible
Power-down
External Hardware
Reset
mode)
Reset
+
Figure 13 : Internal (simplified) Reset Circuitry
RSTOUT
EINIT Instruction
Trigger
Clr
Clock
Reset State
Machine
Internal
Reset
Signal
Reset Sequence
(512 CPU Clock Cycles)
SRST instruction
watchdog overflow
RSTIN
V
CC
BDRSTEN
V
CC
V
PP
(Flash device)
V
PP
Weak Pulldown
(~200
A)
From/to Exit
Powerdown
Circuit
Asynchronous
Reset
Clr
Q
Set
ST10F168
41/74
The minimum reset circuit of Figure 14 is not ade-
quate when the RSTIN pin is driven from the
ST10F168 itself during software or watchdog trig-
gered resets, because of the capacitor C1 that will
keep the voltage on RSTIN pin above V
IL
after the
end of the internal reset sequence, and thus will
triggered an asynchronous reset sequence.
Figure 14 shows an example of a reset circuit. In
this example, R1C1 external circuit is only used to
generate power-up or manual reset, and R0C0
circuit on V
PP
is used for power-up reset and to
exit from powerdown mode. Diode D1 creates a
wired-OR gate connection to the reset pin and
may be replaced by open-collector schmitt trigger
buffer. Diode D2 provides a faster cycle time for
repetitive power-on resets.
R2 is an optional pullup for faster recovery and
correct biasing of TTL Open Collector drivers.
Figure 14 : System Reset Circuit
RSTOUT
V
PP
RSTIN
V
CC
+
C0
R0
ST10F168
External Hardware
V
CC
R2
+
C1
R1
D2
D1
o.d.
External
Reset Source
Open Drain Inverter
V
CC
ST10F168
42/74
18 - POWER REDUCTION MODES
Two different power reduction modes with different
levels of power reduction can be entered under
software control.
In Idle mode the CPU is stopped, while the
peripherals continue their operation. Idle mode
can be terminated by any reset or interrupt
request.
In Power Down mode both the CPU and the
peripherals are stopped. Power Down mode can
be configured by software in order to be termi-
nated only by a hardware reset or by an external
interrupt source on fast external interrupt pins.
There are two different operating Power Down
modes:
Protected power down mode: selected by set-
ting bit PWDCFG in the SYSCON register to `0'.
This mode can be used in conjunction with an
external power failure signal which pulls the NMI
pin low when a power failure is imminent. The
microcontroller enters the NMI trap routine and
saves the internal state into RAM. The trap rou-
tine then sets a flag or writes a bit pattern into
specific RAM locations, and executes the
PWRDN instruction. If the NMI pin is still low at
this time, Power Down mode will be entered, if
not program execution continues. During power
down the voltage at the V
CC
pins can be lowered
to 2.5 V and the contents of the internal RAM will
still be preserved.
Interruptible power down mode: this
mode is selected by setting bit PWDCFG in the
SYSCON register. The CPU and peripheral
clocks are frozen, and the oscillator and PLL are
stopped. To exit power down mode with an ex-
ternal interrupt, an EXxIN (x = 7...0) pin has to
be asserted for at least 40ns. This signal ena-
bles the internal oscillator and PLL circuitry, and
turns on the weak pulldown. If the Interrupt was
enabled before entering power down mode, the
device executes the interrupt service routine,
and then resumes execution after the PWRDN
instruction. If the interrupt was disabled, the de-
vice executes the instruction following PWRDN
instruction, and the Interrupt Request Flag re-
mains set until it is cleared by software.
All external bus actions are completed before Idle
or Power Down mode is entered. However, Idle or
Power Down mode is not entered if READY is
enabled, but has not been activated (driven low for
negative polarity, or driven high for positive polar-
ity) during the last bus access.
ST10F168
43/74
19 - SPECIAL FUNCTION REGISTER OVERVIEW
Table 22 lists all SFRs which are implemented
in the ST10F168 in alphabetical order.
Bit-addressable SFRs are marked with the letter
"b" in column "Name". SFRs within the Extended
SFR-Space (ESFRs) are marked with the letter
"E" in column "Physical Address".
An SFR can be specified by its individual mnemonic
name. Depending on the selected addressing
mode, an SFR can be accessed via its physical
address (using the Data Page Pointers), or via its
short 8-bit address (without using the Data Page
Pointers).
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ADCIC
b
FF98h
CCh
A/D Converter End Of Conversion Interrupt Control Register
0000h
ADCON
b
FFA0h
D0h
A/D Converter Control Register
0000h
ADDAT
FEA0h
50h
A/D Converter Result Register
0000h
ADDAT2
F0A0h
E
50h
A/D Converter 2 Result Register
0000h
ADDRSEL1
FE18h
0Ch
Address Select Register 1
0000h
ADDRSEL2
FE1Ah
0Dh
Address Select Register 2
0000h
ADDRSEL3
FE1Ch
0Eh
Address Select Register 3
0000h
ADDRSEL4
FE1Eh
0Fh
Address Select Register 4
0000h
ADEIC
b
FF9Ah
CDh
A/D converter Overrun Error Interrupt Control Register
0000h
BUSCON0
b
FF0Ch
86h
Bus Configuration Register 0
0XX0h
BUSCON1
b
FF14h
8Ah
Bus Configuration Register 1
0000h
BUSCON2
b
FF16h
8Bh
Bus Configuration Register 2
0000h
BUSCON3
b
FF18h
8Ch
Bus Configuration Register 3
0000h
BUSCON4
b
FF1Ah
8Dh
Bus Configuration Register 4
0000h
CAPREL
FE4Ah
25h
GPT2 Capture / Reload Register
0000h
CC0
FE80h
40h
CAPCOM Register 0
0000h
CC0IC
b
FF78h
BCh
CAPCOM Register 0 Interrupt Control Register
0000h
CC1
FE82h
41h
CAPCOM Register 1
0000h
CC1IC
b
FF7Ah
BDh
CAPCOM Register 1 Interrupt Control Register
0000h
CC2
FE84h
42h
CAPCOM Register 2
0000h
CC2IC
b
FF7Ch
BEh
CAPCOM Register 2 Interrupt Control Register
0000h
CC3
FE86h
43h
CAPCOM Register 3
0000h
CC3IC
b
FF7Eh
BFh
CAPCOM Register 3 Interrupt Control Register
0000h
CC4
FE88h
44h
CAPCOM Register 4
0000h
CC4IC
b
FF80h
C0h
CAPCOM Register 4 Interrupt Control Register
0000h
CC5
FE8Ah
45h
CAPCOM Register 5
0000h
CC5IC
b
FF82h
C1h
CAPCOM Register 5 Interrupt Control Register
0000h
CC6
FE8Ch
46h
CAPCOM Register 6
0000h
CC6IC
b
FF84h
C2h
CAPCOM Register 6 Interrupt Control Register
0000h
CC7
FE8Eh
47h
CAPCOM Register 7
0000h
CC7IC
b
FF86h
C3h
CAPCOM Register 7 Interrupt Control Register
0000h
CC8
FE90h
48h
CAPCOM Register 8
0000h
CC8IC
b
FF88h
C4h
CAPCOM Register 8 Interrupt Control Register
0000h
CC9
FE92h
49h
CAPCOM Register 9
0000h
ST10F168
44/74
CC9IC
b
FF8Ah
C5h
CAPCOM Register 9 Interrupt Control Register
0000h
CC10
FE94h
4Ah
CAPCOM Register 10
0000h
CC10IC
b
FF8Ch
C6h
CAPCOM Register 10 Interrupt Control Register
0000h
CC11
FE96h
4Bh
CAPCOM Register 11
0000h
CC11IC
b
FF8Eh
C7h
CAPCOM Register 11 Interrupt Control Register
0000h
CC12
FE98h
4Ch
CAPCOM Register 12
0000h
CC12IC
b
FF90h
C8h
CAPCOM Register 12 Interrupt Control Register
0000h
CC13
FE9Ah
4Dh
CAPCOM Register 13
0000h
CC13IC
b
FF92h
C9h
CAPCOM Register 13 Interrupt Control Register
0000h
CC14
FE9Ch
4Eh
CAPCOM Register 14
0000h
CC14IC
b
FF94h
CAh
CAPCOM Register 14 Interrupt Control Register
0000h
CC15
FE9Eh
4Fh
CAPCOM Register 15
0000h
CC15IC
b
FF96h
CBh
CAPCOM Register 15 Interrupt Control Register
0000h
CC16
FE60h
30h
CAPCOM Register 16
0000h
CC16IC
b
F160h
E
B0h
CAPCOM Register 16 Interrupt Control Register
0000h
CC17
FE62h
31h
CAPCOM Register 17
0000h
CC17IC
b
F162h
E
B1h
CAPCOM Register 17 Interrupt Control Register
0000h
CC18
FE64h
32h
CAPCOM Register 18
0000h
CC18IC
b
F164h
E
B2h
CAPCOM Register 18 Interrupt Control Register
0000h
CC19
FE66h
33h
CAPCOM Register 19
0000h
CC19IC
b
F166h
E
B3h
CAPCOM Register 19 Interrupt Control Register
0000h
CC20
FE68h
34h
CAPCOM Register 20
0000h
CC20IC
b
F168h
E
B4h
CAPCOM Register 20 Interrupt Control Register
0000h
CC21
FE6Ah
35h
CAPCOM Register 21
0000h
CC21IC
b
F16Ah
E
B5h
CAPCOM Register 21 Interrupt Control Register
0000h
CC22
FE6Ch
36h
CAPCOM Register 22
0000h
CC22IC
b
F16Ch
E
B6h
CAPCOM Register 22 Interrupt Control Register
0000h
CC23
FE6Eh
37h
CAPCOM Register 23
0000h
CC23IC
b
F16Eh
E
B7h
CAPCOM Register 23 Interrupt Control Register
0000h
CC24
FE70h
38h
CAPCOM Register 24
0000h
CC24IC
b
F170h
E
B8h
CAPCOM Register 24 Interrupt Control Register
0000h
CC25
FE72h
39h
CAPCOM Register 25
0000h
CC25IC
b
F172h
E
B9h
CAPCOM Register 25 Interrupt Control Register
0000h
CC26
FE74h
3Ah
CAPCOM Register 26
0000h
CC26IC
b
F174h
E
BAh
CAPCOM Register 26 Interrupt Control Register
0000h
CC27
FE76h
3Bh
CAPCOM Register 27
0000h
CC27IC
b
F176h
E
BBh
CAPCOM Register 27 Interrupt Control Register
0000h
CC28
FE78h
3Ch
CAPCOM Register 28
0000h
CC28IC
b
F178h
E
BCh
CAPCOM Register 28 Interrupt Control Register
0000h
CC29
FE7Ah
3Dh
CAPCOM Register 29
0000h
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ST10F168
45/74
CC29IC
b
F184h
E
C2h
CAPCOM Register 29 Interrupt Control Register
0000h
CC30
FE7Ch
3Eh
CAPCOM Register 30
0000h
CC30IC
b
F18Ch
E
C6h
CAPCOM Register 30 Interrupt Control Register
0000h
CC31
FE7Eh
3Fh
CAPCOM Register 31
0000h
CC31IC
b
F194h
E
CAh
CAPCOM Register 31 Interrupt Control Register
0000h
CCM0
b
FF52h
A9h
CAPCOM Mode Control Register 0
0000h
CCM1
b
FF54h
AAh
CAPCOM Mode Control Register 1
0000h
CCM2
b
FF56h
ABh
CAPCOM Mode Control Register 2
0000h
CCM3
b
FF58h
ACh
CAPCOM Mode Control Register 3
0000h
CCM4
b
FF22h
91h
CAPCOM Mode Control Register 4
0000h
CCM5
b
FF24h
92h
CAPCOM Mode Control Register 5
0000h
CCM6
b
FF26h
93h
CAPCOM Mode Control Register 6
0000h
CCM7
b
FF28h
94h
CAPCOM Mode Control Register 7
0000h
CP
FE10h
08h
CPU Context Pointer Register
FC00h
CRIC
b
FF6Ah
B5h
GPT2 CAPREL Interrupt Control Register
0000h
CSP
FE08h
04h
CPU Code Segment Pointer Register (read only)
0000h
DP0L
b
F100h
E
80h
P0L Direction Control Register
00h
DP0H
b
F102h
E
81h
P0h Direction Control Register
00h
DP1L
b
F104h
E
82h
P1L Direction Control Register
00h
DP1H
b
F106h
E
83h
P1h Direction Control Register
00h
DP2
b
FFC2h
E1h
Port 2 Direction Control Register
0000h
DP3
b
FFC6h
E3h
Port 3 Direction Control Register
0000h
DP4
b
FFCAh
E5h
Port 4 Direction Control Register
00h
DP6
b
FFCEh
E7h
Port 6 Direction Control Register
00h
DP7
b
FFD2h
E9h
Port 7 Direction Control Register
00h
DP8
b
FFD6h
EBh
Port 8 Direction Control Register
00h
DPP0
FE00h
00h
CPU Data Page Pointer 0 Register (10-bit)
0000h
DPP1
FE02h
01h
CPU Data Page Pointer 1 Register (10-bit)
0001h
DPP2
FE04h
02h
CPU Data Page Pointer 2 Register (10-bit)
0002h
DPP3
FE06h
03h
CPU Data Page Pointer 3 Register (10-bit)
0003h
EXICON
b
F1C0h
E
E0h
External Interrupt Control Register
0000h
IDCHIP
F07Ch
E
3Eh
Device Identifier Register
0A8Xh
1
IDMANUF
F07Eh
E
3Fh
Manufacturer Identifier Register
0400h
IDMEM
F07Ah
E
3Dh
On-chip Memory Identifier Register
3040h
IDPROG
F078h
E
3Ch
Programming Voltage Identifier Register
9A40h
MDC
b
FF0Eh
87h
CPU Multiply Divide Control Register
0000h
MDH
FE0Ch
06h
CPU Multiply Divide Register High Word
0000h
MDL
FE0Eh
07h
CPU Multiply Divide Register Low Word
0000h
ODP2
b
F1C2h
E
E1h
Port 2 Open Drain Control Register
0000h
ODP3
b
F1C6h
E
E3h
Port 3 Open Drain Control Register
0000h
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ST10F168
46/74
ODP6
b
F1CEh
E
E7h
Port 6 Open Drain Control Register
00h
ODP7
b
F1D2h
E
E9h
Port 7 Open Drain Control Register
00h
ODP8
b
F1D6h
E
EBh
Port 8 Open Drain Control Register
00h
ONES
b
FF1Eh
8Fh
Constant Value 1's Register (read only)
FFFFh
P0L
b
FF00h
80h
Port 0 Low Register (Lower half of Port0)
00h
P0H
b
FF02h
81h
Port 0 High Register (Upper half of Port0)
00h
P1L
b
FF04h
82h
Port 1 Low Register (Lower half of Port1)
00h
P1H
b
FF06h
83h
Port 1 High Register (Upper half of Port1)
00h
P2
b
FFC0h
E0h
Port 2 Register
0000h
P3
b
FFC4h
E2h
Port 3 Register
0000h
P4
b
FFC8h
E4h
Port 4 Register (8-bit)
00h
P5
b
FFA2h
D1h
Port 5 Register (read only)
XXXXh
P6
b
FFCCh
E6h
Port 6 Register (8-bit)
00h
P7
b
FFD0h
E8h
Port 7 Register (8-bit)
00h
P8
b
FFD4h
EAh
Port 8 Register (8-bit)
00h
PECC0
FEC0h
60h
PEC Channel 0 Control Register
0000h
PECC1
FEC2h
61h
PEC Channel 1 Control Register
0000h
PECC2
FEC4h
62h
PEC Channel 2 Control Register
0000h
PECC3
FEC6h
63h
PEC Channel 3 Control Register
0000h
PECC4
FEC8h
64h
PEC Channel 4 Control Register
0000h
PECC5
FECAh
65h
PEC Channel 5 Control Register
0000h
PECC6
FECCh
66h
PEC Channel 6 Control Register
0000h
PECC7
FECEh
67h
PEC Channel 7 Control Register
0000h
PICON
F1C4h
E
E2h
Port Input Threshold Control Register
0000h
PP0
F038h
E
1Ch
PWM Module Period Register 0
0000h
PP1
F03Ah
E
1Dh
PWM Module Period Register 1
0000h
PP2
F03Ch
E
1Eh
PWM Module Period Register 2
0000h
PP3
F03Eh
E
1Fh
PWM Module Period Register 3
0000h
PSW
b
FF10h
88h
CPU Program Status Word
0000h
PT0
F030h
E
18h
PWM Module Up / Down Counter 0
0000h
PT1
F032h
E
19h
PWM Module Up / Down Counter 1
0000h
PT2
F034h
E
1Ah
PWM Module Up / Down Counter 2
0000h
PT3
F036h
E
1Bh
PWM Module Up / Down Counter 3
0000h
PW0
FE30h
18h
PWM Module Pulse Width Register 0
0000h
PW1
FE32h
19h
PWM Module Pulse Width Register 1
0000h
PW2
FE34h
1Ah
PWM Module Pulse Width Register 2
0000h
PW3
FE36h
1Bh
PWM Module Pulse Width Register 3
0000h
PWMCON0 b
FF30h
98h
PWM Module Control Register 0
0000h
PWMCON1 b
FF32h
99h
PWM Module Control Register 1
0000h
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ST10F168
47/74
PWMIC
b
F17Eh
E
BFh
PWM Module Interrupt Control Register
0000h
RP0H
b
F108h
E
84h
System Start-up Configuration Register (read only)
XXh
S0BG
FEB4h
5Ah
Serial Channel 0 Baud Rate Generator Reload Register
0000h
S0CON
b
FFB0h
D8h
Serial Channel 0 Control Register
0000h
S0EIC
b
FF70h
B8h
Serial Channel 0 Error Interrupt Control Register
0000h
S0RBUF
FEB2h
59h
Serial Channel 0 Receive Buffer Register (read only)
XXh
S0RIC
b
FF6Eh
B7h
Serial Channel 0 Receive Interrupt Control Register
0000h
S0TBIC
b
F19Ch
E
CEh
Serial Channel 0 Transmit Buffer Interrupt Control Register
0000h
S0TBUF
FEB0h
58h
Serial Channel 0 Transmit Buffer Register (write only)
00h
S0TIC
b
FF6Ch
B6h
Serial Channel 0 Transmit Interrupt Control Register
0000h
SP
FE12h
09h
CPU System Stack Pointer Register
FC00h
SSCBR
F0B4h
E
5Ah
SSC Baud Rate Register
0000h
SSCCON
b
FFB2h
D9h
SSC Control Register
0000h
SSCEIC
b
FF76h
BBh
SSC Error Interrupt Control Register
0000h
SSCRB
F0B2h
E
59h
SSC Receive Buffer (read only)
XXXXh
SSCRIC
b
FF74h
BAh
SSC Receive Interrupt Control Register
0000h
SSCTB
F0B0h
E
58h
SSC Transmit Buffer (write only)
0000h
SSCTIC
b
FF72h
B9h
SSC Transmit Interrupt Control Register
0000h
STKOV
FE14h
0Ah
CPU Stack Overflow Pointer Register
FA00h
STKUN
FE16h
0Bh
CPU Stack Underflow Pointer Register
FC00h
SYSCON
b
FF12h
89h
CPU System Configuration Register
0xx0h
2
T0
FE50h
28h
CAPCOM Timer 0 Register
0000h
T01CON
b
FF50h
A8h
CAPCOM Timer 0 and Timer 1 Control Register
0000h
T0IC
b
FF9Ch
CEh
CAPCOM Timer 0 Interrupt Control Register
0000h
T0REL
FE54h
2Ah
CAPCOM Timer 0 Reload Register
0000h
T1
FE52h
29h
CAPCOM Timer 1 Register
0000h
T1IC
b
FF9Eh
CFh
CAPCOM Timer 1 Interrupt Control Register
0000h
T1REL
FE56h
2Bh
CAPCOM Timer 1 Reload Register
0000h
T2
FE40h
20h
GPT1 Timer 2 Register
0000h
T2CON
b
FF40h
A0h
GPT1 Timer 2 Control Register
0000h
T2IC
b
FF60h
B0h
GPT1 Timer 2 Interrupt Control Register
0000h
T3
FE42h
21h
GPT1 Timer 3 Register
0000h
T3CON
b
FF42h
A1h
GPT1 Timer 3 Control Register
0000h
T3IC
b
FF62h
B1h
GPT1 Timer 3 Interrupt Control Register
0000h
T4
FE44h
22h
GPT1 Timer 4 Register
0000h
T4CON
b
FF44h
A2h
GPT1 Timer 4 Control Register
0000h
T4IC
b
FF64h
B2h
GPT1 Timer 4 Interrupt Control Register
0000h
T5
FE46h
23h
GPT2 Timer 5 Register
0000h
T5CON
b
FF46h
A3h
GPT2 Timer 5 Control Register
0000h
T5IC
b
FF66h
B3h
GPT2 Timer 5 Interrupt Control Register
0000h
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ST10F168
48/74
Notes: 1. The value depends on the silicon revision and is described in the chapter 19.1.
2. The system configuration is selected during reset.
3. Bit WDTR indicates a watchdog timer triggered reset.
4. The XPnIC Interrupt Control Registers control the interrupt requests from integrated X-Bus peripherals. Nodes where no
X-Peripherals are connected may be used to generate software controlled interrupt requests by setting the respective XPnIR bit.
T6
FE48h
24h
GPT2 Timer 6 Register
0000h
T6CON
b
FF48h
A4h
GPT2 Timer 6 Control Register
0000h
T6IC
b
FF68h
B4h
GPT2 Timer 6 Interrupt Control Register
0000h
T7
F050h
E
28h
CAPCOM Timer 7 Register
0000h
T78CON
b
FF20h
90h
CAPCOM Timer 7 and 8 Control Register
0000h
T7IC
b
F17Ah
E
BEh
CAPCOM Timer 7 Interrupt Control Register
0000h
T7REL
F054h
E
2Ah
CAPCOM Timer 7 Reload Register
0000h
T8
F052h
E
29h
CAPCOM Timer 8 Register
0000h
T8IC
b
F17Ch
E
BFh
CAPCOM Timer 8 Interrupt Control Register
0000h
T8REL
F056h
E
2Bh
CAPCOM Timer 8 Reload Register
0000h
TFR
b
FFACh
D6h
Trap Flag Register
0000h
WDT
FEAEh
57h
Watchdog Timer Register (read only)
0000h
WDTCON
b
FFAEh
D7h
Watchdog Timer Control Register
000xh
3
XP0IC
b
F186h
E
C3h
CAN Module Interrupt Control Register
0000h
4
XP1IC
b
F18Eh
E
C7h
X-Peripheral 1 Interrupt Control Register
0000h
4
XP2IC
b
F196h
E
CBh
X-Peripheral 2 Interrupt Control Register
0000h
4
XP3IC
b
F19Eh
E
CFh
PLL unlock Interrupt Control Register
0000h
4
ZEROS
b
FF1Ch
8Eh
Constant Value 0's Register (read only)
0000h
Table 22 : Special Function Registers listed by name
Name
Physical
address
8-bit
address
Description
Reset
value
ST10F168
49/74
19.1 - Identification Registers
The ST10F168 has four Identification registers, mapped in ESFR space. These register contain:
A manufacturer identifier,
A chip identifier, with its revision,
A internal memory and size identifier,
Programming voltage description.
IDMANUF (F07Eh / 3Fh)
ESFR
Description
MANUF : Manufacturer Identifier - 020h: STmicroelectronics Manufacturer (JTAG worldwide normalisation).
IDCHIP (F07Ch / 3Eh)
ESFR
Description
REVID :
Device Revision Identifier - 1h for the first step, 2h for the second step,...
CHIPID :
Device Identifier - 0A8h is the identifier of ST10F168.
IDMEM (F07Ah / 3Dh)
ESFR
Description
MEMSIZE :
Internal Memory Size - 040h for ST10F168 (256K Bytes).
Internal Memory size is 4 * <MEMSIZE> (in K Byte).
MEMTYP
:
Internal Memory Type - 3h for ST10F168 (Flash memory).
IDPROG (F078h / 3Ch)
ESFR
Description
PROGVDD :
Programming V
DD
Voltage
V
DD
voltage when programming EPROM or Flash devices is calculated using the follow-
ing formula: V
DD
= 20 * <PROGVDD> / 256 [V] - 40h for ST10F168 (5V).
PROGVPP :
Programming V
PP
Voltage
V
PP
voltage when programming EPROM or Flash devices is calculated using the follow-
ing formula: V
PP
= 20 * <PROGVDD> / 256 [V] - 9Ah for ST10F168 (12V).
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
MANUF
-
-
-
-
-
R
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
CHIPID
REVID
R
R
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
MEMTYP
MEMSIZE
R
R
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
PROGVPP
PROGVDD
R
R
ST10F168
50/74
20 - ELECTRICAL CHARACTERISTICS
20.1 - Absolute Maximum Ratings
Note: 1. Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress
rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of
this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
During overload conditions (V
IN
>V
DD
or V
IN
<V
SS
) the voltage on pins with respect to ground (V
SS
) must not exceed the values
defined by the Absolute Maximum Ratings.
20.2 - Parameter Interpretation
The parameters listed in the following tables represent the characteristics of the ST10F168 and its
demands on the system.
Where the ST10F168 logic provides signals with their respective timing characteristics, the symbol "CC"
for Controller Characteristics is included in the "Symbol" column.
Where the external system must provide signals with their respective timing characteristics to the
ST10F168, the symbol "SR" for System Requirement is included in the "Symbol" column.
20.3 - DC Characteristics
V
DD
= 5V 10%, V
SS
= 0V, Reset active, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40,
+125C, unless otherwise specified.
Symbol
Parameter
Value
Unit
V
DD
Voltage on V
DD
pins with respect to ground
1
-0.5, +6.5
V
V
IO
Voltage on any pin with respect to ground
1
-0.5, (V
DD
+0.5)
V
I
OV
Input Current on any pin during overload condition
1
-10, +10
mA
I
TOV
Absolute Sum of all input currents during overload condition
1
|100 mA|
mA
P
tot
Power Dissipation
1
1.5
W
T
A
Ambient Temperature under bias for - Q6
1
Ambient Temperature under bias for - Q3
1
-40, +85
-40, +125
C
C
T
stg
Storage Temperature
1
-65, +150
C
Symbol
Parameter
Test Conditions
Min.
Max.
Unit
V
IL
SR Input low voltage
0.5
0.2 V
DD
0.1
V
V
ILS
SR Input low voltage (special threshold)
0.5
2.0
V
V
IH
SR
Input high voltage
(all except RSTIN and XTAL1)
0.2 V
DD
+ 0.9
V
DD
+ 0.5
V
V
IH1
SR Input high voltage RSTIN
0.6 V
DD
V
DD
+ 0.5
V
V
IH2
SR Input high voltage XTAL1
0.7 V
DD
V
DD
+ 0.5
V
V
IHS
SR Input high voltage (special threshold)
0.8 V
DD
- 0.2
V
DD
+ 0.5
V
HYS
Input Hysteresis (special threshold)
300
-
mV
V
OL
CC
Output low voltage
1
(Port0, Port1, Port 4, ALE,
RD, WR, BHE, CLKOUT, RSTOUT)
I
OL
= 2.4mA
0.45
V
V
OL1
CC Output low voltage
1
(all other outputs)
I
OL1
= 1.6mA
0.45
V
V
OH
CC
Output high voltage
1
(Port0, Port1, Port4, ALE,
RD, WR, BHE, CLKOUT, RSTOUT)
I
OH
= 500
A
I
OH
= 2.4mA
0.9 V
DD
2.4
V
V
OH1
CC Output high voltage
1 2
(all other outputs)
I
OH
= 250
A
I
OH
= 1.6mA
0.9 V
DD
2.4
V
V
I
OZ1
CC Input leakage current (Port 5)
0V < V
IN
< V
DD
0.5
A
ST10F168
51/74
Notes: 1. ST10F168 pins are equipped with low-noise output drivers which significantly improve the device's EMI performance. These
low-noise drivers deliver their maximum current only until the respective target output level is reached. After this, the output current
is reduced. This results in increased impedance of the driver, which attenuates electrical noise from the connected PCB tracks. The
current specified in column "Test Conditions" is delivered in all cases.
2. This specification is not valid for outputs which are switched to open drain mode. In this case the respective output will float and the
voltage results from the external circuitry.
3. Partially tested, guaranteed by design characterization.
4. Overload conditions occur if the standard operating conditions are exceeded, i.e. the voltage on any pin exceeds the specified
range (i.e. V
OV
> V
DD
+0.5V or V
OV
< -0.5V). The absolute sum of input overload currents on all port pins may not exceed 50mA. The
supply voltage must remain within the specified limits.
5. The maximum current may be drawn while the respective signal line remains inactive.
6. This specification is only valid during Reset, or during Hold-mode or Adapt-mode. Port 6 pins are only affected if they are used for
CS output and the open drain function is not enabled.
7. The minimum current must be drawn in order to drive the respective signal line active.
8. The power supply current is a function of the operating frequency. This dependency is illustrated in the Figure 15. These
parameters are tested at V
DD
max and 25MHz CPU clock with all outputs disconnected and all inputs at VIL or VIH. The chip is
configured with a demultiplexed 16-bit bus, direct clock drive, 5 chip select lines and 2 segment address lines, EA pin is low during
reset. After reset, Port 0 is driven with the value `00CCh' that produces infinite execution of NOP instruction with 15 wait-state, R/W
delay, memory tristate wait state, normal ALE. Peripherals are not activated.
9. Idle mode supply current is a function of the operating frequency. This dependency is illustrated in the Figure 15. These
parameters are tested at V
DD
max and 25MHz CPU clock with all outputs disconnected and all inputs at V
IL
or V
IH
.
10. This parameter value includes leakage currents. With all inputs (including pins configured as inputs) at 0 V to 0.1V or at
V
DD
0.1V to V
DD
, V
REF
= 0V, all outputs (including pins configured as outputs) disconnected.
11. Apply 12V on V
PP
10ms after V
DD
is stable at power up. V
PP
pin must be switched to 0V before to switch off V
DD
(5V).
I
OZ2
CC Input leakage current (all other)
0V < V
IN
< V
DD
1
A
I
OV
SR Overload current
3
4
5
mA
R
RST
CC RSTIN pull-up resistor
3
0V < V
IN
< V
ILmax
50
250
k
I
RWH
5
Read / Write inactive current
6
V
OUT
= 2.4V
-40
A
I
RWL
7
Read / Write active current
6
V
OUT
= V
OLmax
-500
A
I
ALEL
6
ALE inactive current
6
V
OUT
= V
OLmax
40
A
I
ALEH
6
ALE active current
6
V
OUT
= 2.4V
600
A
I
P6H
6
Port 6 inactive current
6
V
OUT
= 2.4V
-40
A
I
P6L
7
Port 6 active current
6
V
OUT
= V
OL1max
-500
A
I
P0H
6
Port 0 configuration current
6
V
IN
= V
IHmin
-10
A
I
P0L
7
V
IN
= V
ILmax
-100
A
I
IL
CC XTAL1 input current
0V < V
IN
< V
DD
20
A
C
IO
CC Pin capacitance
6
(digital inputs / outputs)
f = 1MHz,
T
A
= 25C
10
pF
I
CC
Power supply current
RSTIN = V
IH1
f
CPU
in [MHz]
8
20 + 6 x f
CPU
mA
I
ID
Idle mode supply current
RSTIN = V
IH1
f
CPU
in [MHz]
9
20 + 3 x f
CPU
mA
I
PD
Power-down mode supply current
V
DD
= 5.5V
10
100
A
I
PPR
V
PP
Read Current
V
PP
< V
DD
200
A
I
PPW
V
PP
Programming / Erasing Current
3
V
PP
= 12V,
f
CPU
= 25MHz
20
mA
V
PP
11
V
PP
during Programming / Erasing Operations
11,4
12,6
V
Symbol
Parameter
Test Conditions
Min.
Max.
Unit
ST10F168
52/74
Figure 15 : Supply / idle current as a function of operation frequency
20.4 - A/D Converter Characteristics
V
DD
= 5V 10%, V
SS
= 0V, 4.0V
V
AREF
V
DD
+ 0.1V, V
SS
- 0.1V
V
AGND
V
SS
+ 0.2V, Q6 version :
T
A
= -40, +85C and for Q3 version T
A
= -40C, +125C, unless otherwise specified
Notes: 1. VAIN may exceed V
AGND
or V
AREF
up to the absolute maximum ratings. However, the conversion result in these cases will be
X000h or X3FFh, respectively.
2. During the t
S
sample time the input capacitance C
ain
can be charged/discharged by the external source. The internal resistance of
the analog source must allow the capacitance to reach its final voltage level within the t
S
sample time. After the end of the t
S
sample
time, changes of the analog input voltage have no effect on the conversion result. Values for the t
SC
sample clock depend on the
programming. Referring to the t
C
conversion time formula of chapter 13, to the table 17 of page 33 and to the table below:
t
S
min = 2 t
SC
min = 2 t
CC
min = 2 x 24 x TCL = 48 TCL
t
S
max = 2 t
SC
max = 2 x 8 t
CC
max = 2 x 8 x 96 TCL = 1536 TCL
TCL is defined in section 20.5.5 at page 55.
3. The conversion time formula is:
t
C
= 14 t
CC
+ t
S
+ 4 TCL (= 14 t
CC
+ 2 t
SC
+ 4 TCL)
The t
C
parameter includes the t
S
sample time, the time for determining the digital result and the time to load the result register with
the result of the conversion. Values for the t
CC
conversion clock depend on the programming. Referring to the table 17 of page 33 and
to the table below:
t
C
min = 14 t
CC
min + t
S
min + 4 TCL = 14 x 24 x TCL + 48 TCL + 4 TCL = 388 TCL
t
C
max = 14 t
CC
max + t
S
max + 4 TCL = 14 x 96 TCL + 1536 TCL + 4 TCL = 2884 TCL
4. This parameter is fixed by ADC control logic.
5. TUE is tested at V
AREF
= 5.0V, V
AGND
= 0V, V
CC
= 4.9V. It is guaranteed by design characterization for all other voltages within the
defined voltage range. The specified TUE is guaranteed only if an overload condition (see Iov specification) occurs on maximum of 2
not selected analog input pins and the absolute sum of input overload currents on all analog input pins does not exceed 10mA.
During the reset calibration sequence the maximum TUE may be
4 LSB.
Symbol
Parameter
Test
Conditions
Min.
Max.
Unit
V
AIN
SR Analog input voltage range
1 - 8
V
AGND
V
AREF
V
t
S
CC Sample time
2 - 4
48 TCL
1 536 TCL
t
C
CC Conversion time
3 - 4
388 TCL
2 884 TCL
TUE
CC Total unadjusted error
5
2
LSB
R
AREF
SR Internal resistance of reference voltage source
t
CC
in [ns]
6 - 7
(t
CC
/ 165) - 0.25
k
R
ASRC
SR Internal resistance of analog source
t
S
in [ns]
2 - 7
(t
S
/ 330) - 0.25
k
C
AIN
CC ADC input capacitance
7
33
pF
00
0
00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0
000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000
0
0
0
0
0
0
0
0
0
0
0
0
0
I [mA]
f
CPU
[MHz]
5
10
15
20
200
100
10
I
IDmax
I
CCmax
25
ST10F168
53/74
6. During the conversion the ADC's capacitance must be repeatedly charged or discharged. The internal resistance of the reference
voltage source must allow the capacitance to reach its respective voltage level within t
CC
. The maximum internal resistance results
from the programmed conversion timing.
7. Partially tested, guaranteed by design characterization.
8. To remove noise and undesirable high frequency components from the analog input signal, a low-pass filter must be connected at
the ADC input. The cut-off frequency of this filter must be twice the highest conversion frequency used in the application as described
in the formula:
f
cut-off
= 2 / t
c app
where t
c app
is the shorter conversion time used in the application, calculated with the following formula:
t
c app
= 14 t
CC
+ t
S
+ 4 TCL (= 14 t
CC
+ 2 t
SC
+ 4 TCL).
ADC Sample time and conversion time are programmable. The table below should be used to calculate
the above timings.
20.5 - AC Characteristics
20.5.1 - Test Waveforms
Conversion Time
Sample Time
ADCON.15|14 (ADCTC)
Conversion clock t
CC
ADCON.13|12 (ADSTC)
Sample clock t
SC
00
TCL x 24
00
t
CC
01
Reserved, do not use
01
t
CC
x 2
10
TCL x 96
10
t
CC
x 4
11
TCL x 48
11
t
CC
x 8
Figure 16 : Input / output waveforms
Figure 17 : Float waveforms
2.4V
0.45V
Test Points
0.2V
DD
+0.9
0.2V
DD
+0.9
0.2V
DD
-0.1
0.2V
DD
-0.1
AC inputs during testing are driven at 2.4V for a logic `1' and 0.4V for a logic `0'.
Timing measurements are made at V
IH
min for a logic `1' and V
IL
max for a logic `0'.
Timing
Reference
Points
V
Load
+0.1V
V
Load
-0.1V
V
OH
-0.1V
V
OL
+0.1V
V
Load
V
OL
V
OH
For timing purposes a port pin is no longer floating when V
LOAD
changes of 100mV.
It begins to float when a 100mV change from the loaded V
OH
/V
OL
level occurs (I
OH
/I
OL
= 20mA).
ST10F168
54/74
20.5.2 - Definition of Internal Timing
The internal operation of the ST10F168 is
controlled by the internal CPU clock f
CPU
. Both
edges of the CPU clock can trigger internal (e.g.
pipeline) or external (e.g. bus cycles) operations.
The specification of the external timing (AC
Characteristics) therefore depends on the time
between two consecutive edges of the CPU clock,
called "TCL" (see Figure 18).
The CPU clock signal can be generated by
different mechanisms. The duration of TCL and its
variation (and also the derived external timing)
depends on the mechanism used to generate
f
CPU
. This influence must be regarded when
calculating the timings for the ST10F168.
The example for PLL operation shown in the
Figure 18 refers to a PLL factor of 4.
The mechanism used to generate the CPU clock
is selected during reset by the logic levels on pins
P0.15-13 (P0H.7-5).
20.5.3 - Clock Generation Modes
The Table 23 associates the combinations of these three bit with the respective clock generation mode.
Notes: 1. The external clock input range refers to a CPU clock range of 1...25MHz.
2. The maximum depends on the duty cycle of the external clock signal.
3. The maximum input frequency is 25MHz when using an external crystal with the internal oscillator; providing that internal serial
resistance of the crystal is less than 40
. However, higher frequencies can be applied with an external clock source on pin XTAL1,
but in this case, the input clock signal must reach the defined levels V
IL
and V
IH2.
Figure 18 : Generation Mechanisms for the CPU Clock
Table 23 : CPU Frequency Generation
P0H.7 P0H.6 P0H.5 CPU Frequency f
CPU
= f
XTAL
x F External Clock Input Range
1
Notes
1
1
1
f
XTAL
x 4
2.5 to 6.25MHz
Default configuration
1
1
0
f
XTAL
x 3
3.33 to 8.33MHz
1
0
1
f
XTAL
x 2
5 to 12.5MHz
1
0
0
f
XTAL
x 5
2 to 5MHz
0
1
1
f
XTAL
x 1
1 to 25MHz
Direct drive
2
0
1
0
f
XTAL
x 1.5
6.66 to 16.6MHz
0
0
1
f
XTAL
/ 2
2 to 50MHz
CPU clock via prescaler
3
0
0
0
f
XTAL
x 2.5
4 to 10MHz
00
00
00
00
00
00
00
00
0
0
0
0
TCL TCL
00
00
00
00
00
00
0
0
0
TCL TCL
f
CPU
f
XTAL
f
CPU
f
XTAL
Phase locked loop operation
Direct Clock Drive
00
00
00
00
0
0
0
0
0
0
0
0
TCL
TCL
f
CPU
f
XTAL
Prescaler Operation
ST10F168
55/74
20.5.4 - Prescaler Operation
When pins P0.15-13 (P0H.7-5) equal '001' during
reset, the CPU clock is derived from the internal
oscillator (input clock signal) by a 2:1 prescaler.
The frequency of f
CPU
is half the frequency of
f
XTAL
and the high and low time of f
CPU
(i.e. the
duration of an individual TCL) is defined by the
period of the input clock f
XTAL
.
The timings listed in the AC Characteristics that
refer to TCL therefore can be calculated using the
period of f
XTAL
for any TCL.
Note that if the bit OWDDIS in SYSCON register
is cleared, the PLL runs on its free-running
frequency and delivers the clock signal for the
Oscillator Watchdog. If bit OWDDIS is set, then
the PLL is switched off.
20.5.5 - Direct Drive
When pins P0.15-13 (P0H.7-5) equal '011' during
reset the on-chip phase locked loop is disabled and
the CPU clock is directly driven from the internal
oscillator with the input clock signal.
The frequency of f
CPU
directly follows the
frequency of f
XTAL
so the high and low time of f
CPU
(i.e. the duration of an individual TCL) is defined
by the duty cycle of the input clock f
XTAL
.
Therefore, the timings given in this chapter refer to
the minimum TCL. This minimum value can be
calculated by the following formula:
For two consecutive TCLs, the deviation caused
by the duty cycle of f
XTAL
is compensated, so the
duration of 2TCL is always 1/f
XTAL
. The minimum
value TCL
min
has to be used only once for timings
that require an odd number of TCLs (1,3,...).
Timings that require an even number of TCLs
(2,4,...) may use the formula:
Note:
The address float timings in Multiplexed
bus mode (t
11
and t
45
) use the maximum
duration of TCL (TCL
max
= 1/f
XTAL
x
DC
max
) instead of TCL
min
.
If bit OWDDIS in the SYSCON register is cleared,
the PLL runs on its free-running frequency and
delivers the clock signal for the Oscillator
Watchdog. If bit OWDDIS is set, then the PLL is
switched off.
20.5.6 - Oscillator Watchdog (OWD)
When the clock option selected is direct drive or
direct drive with prescaler, in order to provide a fail
safe mechanism in case of a loss of the external
clock, an oscillator watchdog is implemented as
an additional functionality of the PLL circuitry. This
oscillator watchdog operates as follows :
After a reset, the Oscillator Watchdog is enabled
by default. To disable the OWD, the bit OWDDIS
(bit 4 of SYSCON register) must be set.
When the OWD is enabled, the PLL runs on its
free-running frequency, and increments the
Oscillator Watchdog counter. On each transition
of XTAL1 pin, the Oscillator Watchdog is cleared.
If an external clock failure occurs, then the
Oscillator Watchdog counter overflows (after 16
PLL clock cycles). The CPU clock signal will be
switched to the PLL free-running clock signal, and
the Oscillator Watchdog Interrupt Request
(XP3INT) is flagged. The CPU clock will not switch
back to the external clock even if a valid external
clock exits on XTAL1 pin. Only a hardware reset
can switch the CPU clock source back to direct
clock input.
When the OWD is disabled, the CPU clock is
always fed from the oscillator input and the PLL is
switched off to decrease power supply current.
20.5.7 - Phase Locked Loop
For all other combinations of pins P0.15-13
(P0H.7-5) during reset the on-chip phase locked
loop is enabled and provides the CPU clock (see
Table 23).
The PLL multiplies the input frequency by the
factor F which is selected via the combination of
pins P0.15-13 (i.e. f
CPU
= f
XTAL
x F). With every
F'th transition of f
XTAL
the PLL circuit
synchronizes the CPU clock to the input clock.
This synchronization is done smoothly, i.e. the
CPU clock frequency does not change abruptly.
Due to this adaptation to the input clock the
frequency of f
CPU
is constantly adjusted so it is
locked to f
XTAL
. The slight variation causes a jitter
of f
CPU
which also effects the duration of
individual TCL.
The timings listed in the AC Characteristics that
refer to TCL therefore must be calculated using
the minimum TCL that is possible under the
respective circumstances.
T CL
mi n
1 f
/
XT AL
DC
m in
=
DC
duty cycle
=
2T CL
1 f
XTAL
/
=
ST10F168
56/74
The real minimum value for TCL depends on the
jitter of the PLL. The PLL tunes f
CPU
to keep it
locked on f
XTAL
. The relative deviation of TCL is
the maximum when it is refered to one TCL
period. It decreases according to the formula and
to the Figure 19 given below. For
N
periods of TCL
the minimum value is computed using the
corresponding deviation D
N
:
where N = number of consecutive TCL periods
and 1
N
40. So for a period of 3 TCL periods
(N = 3):
D
3
= 4 - 3/15 = 3.8%
3TCL
min
= 3TCL
NOM
x (1 - 3.8/100)
= 3TCL
NOM
x 0.962
3TCL
min
= (57.72ns at f
CPU
= 25MHz)
This is especially important for bus cycles using wait
states and e.g. for the operation of timers, serial
interfaces, etc. For all slower operations and longer
periods (e.g. pulse train generation or measurement,
lower Baud rates, etc.) the deviation caused by the
PLL jitter is negligible (see Figure 19).
20.5.8 - External Clock Drive XTAL1
V
DD
= 5V 10%, V
SS
= 0V, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40, + 125C, unless
otherwise specified.
Notes: 1. Theoretical minimum. The real minimum value depends on the duty cycle of the input clock signal.
2. The input clock signal must reach the defined levels V
IL
and V
IH2
.
TCL
MIN
TCL
NOM
1
D
N
100
-------------
=
D
N
4
N 15
)
%
[ ]
/
(
=
Figure 19 : Approximated maximum PLL jitter
Symbol
Parameter
f
CPU
= f
XTAL
f
CPU
= f
XTAL
/ 2
f
CPU
= f
XTAL
x N
N = 1.5 / 2 / 2.5 / 3 / 4 / 5
Unit
Min.
Max.
Min.
Max.
Min.
Max.
t
OSC
SR
Oscillator period
40
1
1000
20
500
40 x N
100 x N
ns
t
1
SR
High time
18
2
6
2
10
2
ns
t
2
SR
Low time
18
2
6
2
10
2
ns
t
3
SR
Rise time
10
2
6
3
10
2
ns
t
4
SR
Fall time
10
2
6
2
10
2
ns
Figure 20 : External clock drive XTAL1
32
16
8
4
2
1
2
3
4
Max.jitter [%]
N
This approximated formula is valid for
1 < N < 40 and 10MHz < f
CPU
< 25MHz.
t
1
t
3
t
4
V
IH2
t
2
t
OSC
V
IL
ST10F168
57/74
20.5.9 - Memory Cycle Variables
The tables below use three variables which are derived from the BUSCONx registers and which
represent the special characteristics of the programmed memory cycle. The following table describes
how these variables are computed.
20.5.10 - Multiplexed Bus
V
DD
= 5V 10%, V
SS
= 0V, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40, + 125C, C
L
= 100pF,
ALE cycle time = 6 TCL + 2t
A
+ t
C
+ t
F
(120ns at 25MHz CPU clock without wait states), unless otherwise
specified.
Symbol
Description
Values
t
A
ALE Extension
TCL x <ALECTL>
t
C
Memory Cycle Time wait states
2TCL x (15 - <MCTC>)
t
F
Memory Tristate Time
2TCL x (1 - <MTTC>)
Table 24 : Multiplexed bus characteristics
Symbol
Parameter
Maximum CPU Clock
25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
t
5
CC ALE high time
10 + t
A
TCL - 10 + t
A
ns
t
6
CC Address setup to ALE
4 + t
A
TCL - 16+ t
A
ns
t
7
CC Address hold after ALE
10 + t
A
TCL - 10 + t
A
ns
t
8
CC ALE falling edge to RD, WR
(with RW-delay)
10 + t
A
TCL - 10 + t
A
ns
t
9
CC ALE falling edge to RD, WR
(no RW-delay)
-10 + t
A
-10 + t
A
ns
t
10
CC Address float after RD, WR
1
(with RW-delay)
6
6
ns
t
11
CC Address float after RD, WR
1
(no RW-delay)
26
TCL + 6
ns
t
12
CC RD, WR low time (with RW-delay)
30 + t
C
2TCL - 10 + t
C
ns
t
13
CC RD, WR low time (no RW-delay)
50 + t
C
3TCL - 10 + t
C
ns
t
14
SR RD to valid data in (with RW-delay)
20 + t
C
2TCL - 20+ t
C
ns
t
15
SR RD to valid data in (no RW-delay)
40 + t
C
3TCL - 20+ t
C
ns
t
16
SR ALE low to valid data in
40 + t
A
+ t
C
3TCL - 20
+ t
A
+ t
C
ns
t
17
SR Address / Unlatched CS to valid
data in
50 + 2t
A
+ t
C
4TCL - 30
+ 2t
A
+ t
C
ns
t
18
SR Data hold after RD rising edge
0
0
ns
t
19
SR Data float after RD
1
26 + t
F
2TCL - 14 + t
F
ns
t
22
CC Data valid to WR
20 + t
C
2TCL - 20 + t
C
ns
ST10F168
58/74
Note: 1. Partially tested, guaranteed by design characterization.
t
23
CC Data hold after WR
26 + t
F
2TCL - 14 + t
F
ns
t
25
CC ALE rising edge after RD, WR
26 + t
F
2TCL - 14 + t
F
ns
t
27
CC Address / Unlatched CS hold
after RD, WR
26 + t
F
2TCL - 14 + t
F
ns
t
38
CC ALE falling edge to Latched CS
-4 - t
A
10 - t
A
-4 - t
A
10 - t
A
ns
t
39
SR Latched CS low to Valid Data In
40 + t
C
+ 2t
A
3TCL - 20
+ t
C
+ 2t
A
ns
t
40
CC Latched CS hold after RD, WR
46 + t
F
3TCL - 14 + t
F
ns
t
42
CC ALE fall. edge to RdCS, WrCS
(with RW delay)
16 + t
A
TCL - 4 + t
A
ns
t
43
CC ALE fall. edge to RdCS, WrCS
(no RW delay)
-4 + t
A
-4 + t
A
ns
t
44
CC Address float after RdCS, WrCS
1
(with RW delay)
0
0
ns
t
45
CC Address float after RdCS, WrCS
1
(no RW delay)
20
TCL
ns
t
46
SR RdCS to Valid Data In (with RW
delay)
16 + t
C
2TCL - 24 + t
C
ns
t
47
SR RdCS to Valid Data In (no RW
delay)
36 + t
C
3TCL - 24 + t
C
ns
t
48
CC RdCS, WrCS Low Time (with RW
delay)
30 + t
C
2TCL - 10 + t
C
ns
t
49
CC RdCS, WrCS Low Time (no RW
delay)
50 + t
C
3TCL - 10 + t
C
ns
t
50
CC Data valid to WrCS
26 + t
C
2TCL - 14+ t
C
ns
t
51
SR Data hold after RdCS
0
0
ns
t
52
SR Data float after RdCS
1
20 + t
F
2TCL - 20 + t
F
ns
t
54
CC Address hold after RdCS, WrCS
20 + t
F
2TCL - 20 + t
F
ns
t
56
CC Data hold after WrCS
20 + t
F
2TCL - 20 + t
F
ns
Table 24 : Multiplexed bus characteristics (continued)
Symbol
Parameter
Maximum CPU Clock
25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
ST10F168
59/74
Figure 21 : External Memory Cycle : multiplexed bus, with / without read/write delay, normal ALE
Data In
Data Out
Address
Address
t
38
t
10
Read Cycle
Write Cycle
t
5
t
16
t
39
t
40
t
25
t
27
t
18
t
14
t
22
t
23
t
12
t
8
t
8
t
6m
t
19
Address
t
17
t
6
t
7
t
9
t
11
t
13
t
15
t
16
t
12
t
13
Address
t
9
t
17
t
6
t
27
CLKOUT
ALE
CSx
A23-A16
(A15-A8)
BUS (P0)
RD
BUS (P0)
WR
WRL
BHE
WRH
ST10F168
60/74
Figure 22 : External Memory Cycle: multiplexed bus, with / without read/write delay, extended ALE
Data Out
Address
Data In
Address
Address
t
5
t
16
t
6
t
7
t
39
t
40
t
14
t
8
t
18
t
23
t
6
t
27
t
38
t
10
t
19
t
25
t
17
t
9
t
11
t
15
t
12
t
13
t
8
t
10
t
9
t
11
t
12
t
13
t
22
t
27
t
17
t
6
Read Cycle
Write Cycle
CLKOUT
ALE
CSx
A23-A16
(A15-A8)
BUS (P0)
RD
BUS (P0)
WR
WRL
BHE
WRH
ST10F168
61/74
Figure 23 : External Memory Cycle: multiplexed bus, with / without read/write delay, normal ALE,
read/write chip select
Read Cycle
Write Cycle
CLKOUT
ALE
A23-A16
(A15-A8)
BUS (P0)
BUS (P0)
BHE
Data In
Data Out
Address
Address
t
44
t
5
t
16
t
25
t
27
t
51
t
46
t
50
t
56
t
48
t
42
t
42
t
6
t
52
Address
t
17
t
6
t
7
t
43
t
45
t
49
t
47
t
16
t
48
t
49
Address
t
43
RdCSx
WrCSx
ST10F168
62/74
Figure 24 : External Memory Cycle: multiplexed bus, with / without read/write delay, extended ALE,
read/write chip select
Data Out
Address
Data In
Address
Address
t
5
t
16
t
6
t
7
t
46
t
42
t
42
t
50
t
18
t
56
t
6
t
54
t
44
t
19
t
25
t
17
t
43
t
45
t
47
t
48
t
49
t
49
t
43
t
48
t
44
t
45
Read Cycle
Write Cycle
CLKOUT
ALE
A23-A16
(A15-A8)
BUS (P0)
BUS (P0)
BHE
RdCSx
WrCSx
ST10F168
63/74
20.5.11 - Demultiplexed Bus
V
DD
= 5V 10%, V
SS
= 0V, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40, +125C, C
L
= 100pF,
ALE cycle time = 4 TCL + 2t
A
+ t
C
+ t
F
(80ns at 25MHz CPU clock without wait states), unless otherwise
specified.
Table 25 : Demultiplexed bus characteristics
Symbol
Parameter
Maximum
CPU Clock = 25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
t
5
CC ALE high time
10 + t
A
TCL - 10+ t
A
ns
t
6
CC Address setup to ALE
4 + t
A
TCL - 16+ t
A
ns
t
80
CC Address / Unlatched CS setup to
RD, WR (with RW-delay)
30 + 2t
A
2TCL - 10 + 2t
A
ns
t
81
CC Address / Unlatched CS setup to
RD, WR (no RW-delay)
10 + 2t
A
TCL -10 + 2t
A
ns
t
12
CC RD, WR low time (with
RW-delay)
30 + t
C
2TCL - 10 + t
C
ns
t
13
CC RD, WR low time (no RW-delay)
50 + t
C
3TCL - 10 + t
C
ns
t
14
SR RD to valid data in (with
RW-delay)
20 + t
C
2TCL - 20 + t
C
ns
t
15
SR RD to valid data in (no
RW-delay)
40 + t
C
3TCL - 20 + t
C
ns
t
16
SR ALE low to valid data in
40 + t
A
+ t
C
3TCL - 20
+ t
A
+ t
C
ns
t
17
SR Address / Unlatched CS to valid
data in
50 + 2t
A
+ t
C
4TCL - 30
+ 2t
A
+ t
C
ns
t
18
SR Data hold after RD rising edge
0
0
ns
t
20
SR Data float after RD rising edge
(with RW-delay)
1
2
26 + t
F
2TCL - 14
+ t
F
+ 2t
A
1
ns
t
21
SR Data float after RD rising edge
(no RW-delay)
1
2
10 + t
F
TCL - 10
+ t
F
+ 2t
A
1
ns
t
22
CC Data valid to WR
20 + t
C
2TCL- 20 + t
C
ns
t
24
CC Data hold after WR
10 + t
F
TCL - 10+ t
F
ns
t
26
CC ALE rising edge after RD, WR
-10 + t
F
-10 + t
F
ns
t
28
CC Address / Unlatched CS hold after
RD, WR
3
0 (no t
F
)
-5 + t
F
(t
F
> 0)
0 (no t
F
)
-5 + t
F
(t
F
> 0)
ns
t
28h
CC Address / Unlatched CS hold
after WRH
-5 + t
F
-5 + t
F
ns
t
38
CC ALE falling edge to Latched CS
-4 - t
A
10 - t
A
-4 - t
A
10 - t
A
ns
ST10F168
64/74
Notes: 1. RW-delay and t
A
refer to the following bus cycle.
2. Partially tested, guaranteed by design characterization.
3. Read data is latched with the same clock edge that triggers the address change and the rising RD edge. Therefore address
changes before the end of RD have no impact on read cycles.
t
39
SR Latched CS low to Valid Data In
40 + t
C
+ 2t
A
3TCL - 20
+ t
C
+ 2t
A
ns
t
41
CC Latched CS hold after RD, WR
6 + t
F
TCL - 14 + t
F
ns
t
82
CC Address setup to RdCS, WrCS
(with RW-delay)
26 + 2t
A
2TCL - 14 + 2t
A
ns
t
83
CC Address setup to RdCS, WrCS
(no RW-delay)
6 + 2t
A
TCL -14 + 2t
A
ns
t
46
SR RdCS to Valid Data In (with
RW-delay)
16 + t
C
2TCL - 24 + t
C
ns
t
47
SR RdCS to Valid Data In (no
RW-delay)
36 + t
C
3TCL - 24 + t
C
ns
t
48
CC RdCS, WrCS Low Time (with
RW-delay)
30 + t
C
2TCL - 10 + t
C
ns
t
49
CC RdCS, WrCS Low Time (no
RW-delay)
50 + t
C
3TCL - 10 + t
C
ns
t
50
CC Data valid to WrCS
26 + t
C
2TCL - 14 + t
C
ns
t
51
SR Data hold after RdCS
0
0
ns
t
53
SR Data float after RdCS (with
RW-delay)
2
20 + t
F
2TCL - 20 + t
F
ns
t
68
SR Data float after RdCS (no
RW-delay)
2
0 + t
F
TCL - 20 + t
F
ns
t
55
CC Address hold after RdCS, WrCS
-10 + t
F
-10 + t
F
ns
t
57
CC Data hold after WrCS
6 + t
F
TCL - 14 + t
F
ns
Table 25 : Demultiplexed bus characteristics (continued)
Symbol
Parameter
Maximum
CPU Clock = 25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
ST10F168
65/74
Figure 25 : External Memory Cycle: demultiplexed bus, with / without read/write delay, normal ALE
Note: 1. Un-latched CSx = t
41u
= t
41
- TCL = -14 + t
F
.
Write Cycle
CLKOUT
ALE
A23-A16
(A15-A8)
Data Bus (P0)
BHE
WR
WRL
WRH
Data In
Data Out
t
38
t
5
t
16
t
39
t
41
t
18
t
14
t
22
t
12
Address
t
17
t
13
t
15
t
12
t
13
t
21
t
20
t
81
t
80
t
26
t
24
t
17
t
6
t
41u
t
6
t
80
t
81
t
28
CSx
Read Cycle
Data Bus (P0)
RD
1)
ST10F168
66/74
Figure 26 : External Memory Cycle: demultiplexed bus, with / without read/write delay, extended ALE
Address
t
5
t
16
t
39
t
41
t
14
t
24
t
6
t
38
t
20
t
26
t
17
t
15
t
12
t
13
t
12
t
13
t
22
Data In
t
18
t
21
t
6
t
17
t
28
t
28
Data Out
t
80
t
81
t
80
t
81
Read Cycle
Write Cycle
CLKOUT
ALE
CSx
A23-A16
(A15-A8)
Data Bus
RD
Data Bus
WR
WRL
BHE
WRH
(P0)
(P0)
ST10F168
67/74
Figure 27 : External Memory Cycle: demultiplexed bus, with / without read/write delay, normal ALE,
read/write chip select
Read Cycle
Write Cycle
CLKOUT
ALE
A23-A16
(A15-A8)
Data Bus (P0)
BHE
Data In
Data Out
t
5
t
16
t
51
t
46
t
50
t
48
Address
t
17
t
49
t
47
t
48
t
49
t
68
t
53
t
83
t
82
t
26
t
57
t
55
t
6
t
82
t
83
RdCsx
Data Bus (P0)
WrCSx
ST10F168
68/74
Figure 28 : External Memory Cycle: demultiplexed bus, no read/write delay, extended ALE, read/write
chip select
Address
t
5
t
16
t
46
t
57
t
6
t
53
t
26
t
17
t
47
t
48
t
49
t
48
t
49
t
50
Data In
t
51
t
68
t
55
Data Out
t
82
t
83
t
82
t
83
Read Cycle
Write Cycle
CLKOUT
ALE
A23-A16
(A15-A8)
Data Bus (P0)
BHE
RdCsx
Data Bus (P0)
WrCSx
ST10F168
69/74
20.5.12 - CLKOUT and READY
V
DD
= 5V 10%, V
SS
= 0V, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40, +125C, C
L
= 100pF,
unless otherwise specified
Notes: 1. These timings are given for test purposes only, in order to assure recognition at a specific clock edge.
2. Demultiplexed bus is the worst case. For multiplexed bus 2TCL are to be added to the maximum values. This adds even more time
for deactivating READY.
The 2t
A
and t
C
refer to the next following bus cycle, t
F
refers to the current bus cycle.
Table 26 : CLKOUT and READY characteristics
Symbol
Parameter
Max. CPU Clock
25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
t
29
CC CLKOUT cycle time
40
40
2TCL
2TCL
ns
t
30
CC CLKOUT high time
14
TCL 6
ns
t
31
CC CLKOUT low time
10
TCL 10
ns
t
32
CC CLKOUT rise time
4
4
ns
t
33
CC CLKOUT fall time
4
4
ns
t
34
CC CLKOUT rising edge to ALE falling
edge
-3 + t
A
+7 + t
A
-3 + t
A
7 + t
A
ns
t
35
SR Synchronous READY setup time to
CLKOUT
14
14
ns
t
36
SR Synchronous READY hold time after
CLKOUT
4
4
ns
t
37
SR Asynchronous READY low time
54
2TCL + 14
ns
t
58
SR Asynchronous READY setup time
1
14
14
ns
t
59
SR Asynchronous READY hold time
1
4
4
ns
t
60
SR Async. READY hold time after RD, WR
high (Demultiplexed Bus)
2
0
0 + 2t
A
+ tC + t
F
2
0
TCL - 20
+ 2t
A
+ tC + t
F
2
ns
ST10F168
70/74
Figure 29 : CLKOUT and READY
Notes: 1. Cycle as programmed, including MCTC wait states (Example shows 0 MCTC WS).
2. The leading edge of the respective command depends on RW-delay.
3. READY sampled HIGH at this sampling point generates a READY controlled wait state, READY sampled LOW at this sampling
point terminates the currently running bus cycle.
4. READY may be deactivated in response to the trailing (rising) edge of the corresponding command (RD or WR).
5. If the Asynchronous READY signal does not fulfill the indicated setup and hold times with respect to CLKOUT (e.g. because
CLKOUT is not enabled), it must fulfill t
37
in order to be safely synchronized. This is guaranteed, if READY is removed in response
to the command (see Note 4)).
6. Multiplexed bus modes have a MUX wait state added after a bus cycle, and an additional MTTC wait state may be inserted here.
For a multiplexed bus with MTTC wait state this delay is 2 CLKOUT cycles, for a demultiplexed bus without MTTC wait state this
delay is zero.
7. The next external bus cycle may start here.
t
30
t
34
t
35
t
36
t
35
t
36
t
58
t
59
t
58
t
59
wait state
READY
MUX / Tristate 6)
t
32
t
33
t
29
Running cycle 1)
t
31
t
37
3)
3)
5)
t
604)
6)
2)
7)
3)
3)
CLKOUT
ALE
RD, WR
Synchronous
Asynchronous
READY
READY
ST10F168
71/74
20.5.13 - External Bus Arbitration
V
DD
= 5V
10%, V
SS
= 0V, for Q6 version : T
A
= -40, +85C and for Q3 version T
A
= -40, +125C, C
L
= 100pF,
unless otherwise specified.
Note: 1. Partially tested, guaranted by design characterization.
Notes: 1. The ST10F168 will complete the currently running bus cycle before granting bus access.
2. This is the first possibility for BREQ to become active.
3. The CS outputs will be resistive high (pullup) after t64.
Symbol
Parameter
Max. CPU Clock
25MHz
Variable CPU Clock
1/2 TCL = 1 to 25MHz
Unit
Minimum
Maximum
Minimum
Maximum
t
61
SR HOLD input setup time to CLKOUT
20
20
ns
t
62
CC CLKOUT to HLDA high or BREQ low delay
20
20
ns
t
63
CC CLKOUT to HLDA low or BREQ high delay
20
20
ns
t
64
CC CSx release
1
20
20
ns
t
65
CC CSx drive
-4
24
-4
24
ns
t
66
CC Other signals release
1
20
20
ns
t
67
CC Other signals drive
-4
24
-4
24
ns
Figure 30 : External bus arbitration, releasing the bus
t
61
t
63
t
66
1)
t
64
1)
2)
t
62
3)
CLKOUT
HOLD
HLDA
BREQ
Others
CSx
(P6.x)
ST10F168
72/74
Figure 31 : External bus arbitration, (regaining the bus)
Notes: 1. This is the last opportunity for BREQ to trigger the indicated regain-sequence.
Even if BREQ is activated earlier, the regain-sequence is initiated by HOLD going high.
Please note that HOLD may also be deactivated without the ST10F168 requesting the bus.
2. The next ST10F168 driven bus cycle may start here.
CLKOUT
HOLD
HLDA
BREQ
Others
CSx
(P6.x)
t
62
t
67
t
62
1)
2)
t
65
t
61
t
63
t
62
ST10F168
73/74
21 - PACKAGE MECHANICAL DATA
Note: 1. Package dimensions are in mm. The dimensions quoted in inches are rounded.
22 - ORDERING INFORMATION
Figure 32 :
Package Outline PQFP144 (28 x 28mm)
144
109
D3
e
37
72
1
36
B
A1
A2
A
D1
D
73
108
E3
E1
E
0,10 mm
.004 inch
SEATING PLANE
c
L
K
L1
Dimensions
Millimeters
1
Inches (approx)
Minimum
Typical
Maximum
Minimum
Typical
Maximum
A
4.07
0.160
A1
0.25
0.010
A2
3.17
3.42
3.67
0.125
0.133
0.144
B
0.22
0.38
0.009
0.015
c
0.13
0.23
0.005
0.009
D
30.95
31.20
31.45
1.219
1.228
1.238
D1
27.90
28.00
28.10
1.098
1.102
1.106
D3
22.75
0.896
e
0.65
0.026
E
30.95
31.20
31.45
1.219
1.228
1.238
E1
27.90
28.00
28.10
1.098
1.102
1.106
L
0.65
0.80
0.95
0.026
0.031
0.037
L1
1.60
0.063
K
0 (Min.), 7 (Max.)
Sales type
Temperature range
Package
ST10F168-Q6
-40
C to 85
C
PQFP144 (28 x 28mm)
ST10F168-Q3
-40
C to 125
C
PQFP144 (28 x 28mm)
74
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the
consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from
its use. No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications
mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information
previously supplied. STMicroelectronics products are not authorized for use as critical components in life support devices or
systems without express written approval of STMicroelectronics.
The ST logo is a registered trademark of STMicroelectronics
2002 STMicroelectronics - All Rights Reserved
STMicroelectronics GROUP OF COMPANIES
Australia - Brazil - Canada - China - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan - Malaysia - Malta - Morocco
Singapore - Spain - Sweden - Switzerland - United Kingdom - United States
http://www.st.com
74/74
ST10F168
F
1
68Q
3Q
6
.
R
E
F
PDF
ZIP
