E L E C T R O N I C S I N C .
Power Choke
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Noise Suppression Choke
11.6 A Max. Rated Current
500 Vrms Isolation
EPZ3013G
Product performance is limited to specified parameters. Data is subject to change without prior notice.
Electrical Parameters @ 25 C
Unless Otherwise Specified Dimensions are in Inches /mm .010 /.25
Schematic
1
3
2
4
Package
CSZ3013G Rev. 2 10/20/03
Turns Ratio
Pins 1-2 : 3-4
1 : 1
SRF
(MHz Typ. )
4.0
Inductance
(mH 25%)
@10 KHz, 0.1 Vrms
Pins 1-2, 3-4
.630
DCR
(m
Max.)
Pins 1-2, 3-4
Matched with 5%
10
1.22 Max.
(30.99)
1.00
Max.
(25.40)
.500
Max.
(12.70)
1.097
(27.86)
.600
(15.24)
.400
(10.16)
.155
(3.94)
1.100
(27.94)
3
4
1
2
3
4
1
2
Suggested
Pad
Layout
PCA
EPZ3013G
D.C.
0.1 MHz
1 MHz
20 MHz
10 MHz
Impedance Curve
Frequency
4K
6K
2K
0
1K
3K
5K
7K
