C9047 series is an industrial camera with a high-speed, high resolution CCD (S9037-0902, S9037-1002) and usable in a wide range of
applications including production line inspection and surveying. The CCD used in C9047 series is sensitive in the ultraviolet region (down to 130
nm *
1
) making C9047 series ideal for UV laser applications.
As soon as power is turned on, C9047 series enters standby mode ready to output image data in synchronization with an external trigger signal.
All camera settings can be made through serial communication ports (RS-232C).
The CCD mounted in the camera is a back-thinned FFT-CCD (Full Frame Transfer CCD) that receives light from the backside and therefore has
very high UV sensitivity.
The camera body is compact yet designed to radiate heat efficiently away from the internal circuit and sensor. The CCD focal plane is flush with
the front panel of the camera body making optical design easier.
Features
l
Digital output
l
Real-time digital sensitivity correction
l
High UV sensitivity: sensitive down to 130 nm
l
Fast line rate
S9037-0902: 16 kHz
S9037-1002: 9
kHz
l
External trigger operation
l
Easy handling
PC controllable (RS232C)
l
Compact and lightweight
Applications
l
Spectrophotometry
l
High-speed UV imaging
l
Bio-photon observation
l
Semiconductor inspection
I M A G E S E N S O R
CCD multichannel detector head
Designed for back-thinned CCD area image sensors
C9047 series
PRELIMINARY DATA
Feb. 2003
1
The table below shows CCD image sensors applicable for C9047 series.
Since C9047 series does not include CCD image sensors, so select the desired sensor and order it
separately.
Type No.
Number of total pixels
Number of active pixels
Active area
[mm (H)
mm (V)]
S9037-0902
520
6
512
4
12.288
0.096
S9037-1002
1044
8
1024
4
24.576
0.096
*1: When the CCD sensor faceplate is removed.
CCD multichannel detector head
C9047 series
2
s Specifications
Parameter
C9047
C9047-01
CCD structure
Back-thinned FFT-CCD
S9037-0902
520 (H) 6 (V)
Number of total pixels
S9037-1002
1044 (H) 8 (V)
S9037-0902
512 (H) 4 (V)
Effective number of pixels
S9037-1002
1024 (H) 4 (V)
Pixel size
24 (H) 24 (V) m
S9037-0902
12.288 (H) 0.096 (V) mm
Effective active area
S9037-1002
24.576 (H) 0.096 (V) mm
Scanning rate
10 MHz
S9037-0902
16 kHz
Maximum line rate
S9037-1002
9 kHz
AD conversion resolution
12-bit
Camera interface
RS-422
LVDS
Spectral response range
200 to 1100 nm
Full well capacity
600,000 e
-
Conversion gain
145 e
-
/ADU (600,000 e
-
at 4095 ADC counts)
Dark current
4,000 e
-
/pixel/s at +25 C
Readout noise
435 e
-
(3.0 ADU) at 10 MHz
Digital circuit
D. +5 V 0.25 V (600 mA Max.)
Analog circuit
A. +15 V 0.5 V (300 mA Max.)
Supply voltage
Analog circuit
A. -15 V 0.5 V (300 mA Max.)
Storage temperature
-20 C to +70 C
Operating temperature
0 C to +50 C
Operating humidity
70 % Max. (no condensation)
Dimension
90 (H) 100 (W) 120 (D) mm
Weight
Approx. 800 g
s
Dimensional outline (unit: mm)
KACCA0123EA
50.0
50.0
100.0
120.0
0.5 (FOCAL PLANE)
1.9
90.0
(4 ) M3 DEPTH 4
POWER
RS232C
DIGITAL I/O
CCD multichannel detector head
C9047 series
3
s Pin connection of "DIGITAL I/O" connector (3M 10236-5202JL, 36-pin female connector)
Pin No.
Signal name
Pin No.
Signal name
1
/RESET+
19
/RESET-
2
/CNT+
20
/CNT-
3
LEN+
21
LEN-
4
NC
22
NC
5
DATA-TRIG+
23
DATA-TRIG-
6
GND
24
GND
7
D00+
25
D00-
8
D01+
26
D01-
9
D02+
27
D02-
10
D03+
28
D03-
11
D04+
29
D04-
12
D05+
30
D05-
13
D06+
31
D06-
14
D07+
32
D07-
15
D08+
33
D08-
16
D09+
34
D09-
17
D10+
35
D10-
18
D11+
36
D11-
s Pin connection of "RS-232C" connector (OMRON XM2C-0912-111, 9-pin D-sub male connector)
Pin No.
Signal name
Pin No.
Signal name
1
N
C
6
N
C
2
RX
7
RTS
3
TX
8
CTS
4
NC
9
NC
5
GN D
-
-
s Pin connection of "POWER" connector (HIROSE RM12BRD-5S, 5-pin female connector)
Pin No.
Signal name
1
D. +5 V
2
D. GND
3
A.+15 V
4
A. GND
5
A. -15 V
CCD multichannel detector head
C9047 series
HAMAMATSU PHOTONICS K.K., Solid State Division
1126-1 Ichino-cho, Hamamatsu City, 435-8558 Japan, Telephone: (81) 053-434-3311, Fax: (81) 053-434-5184, http://www.hamamatsu.com
U.S.A.: Hamamatsu Corporation: 360 Foothill Road, P.O.Box 6910, Bridgewater, N.J. 08807-0910, U.S.A., Telephone: (1) 908-231-0960, Fax: (1) 908-231-1218
Germany: Hamamatsu Photonics Deutschland GmbH: Arzbergerstr. 10, D-82211 Herrsching am Ammersee, Germany, Telephone: (49) 08152-3750, Fax: (49) 08152-2658
France: Hamamatsu Photonics France S.A.R.L.: 8, Rue du Saule Trapu, Parc du Moulin de Massy, 91882 Massy Cedex, France, Telephone: 33-(1) 69 53 71 00, Fax: 33-(1) 69 53 71 10
United Kingdom: Hamamatsu Photonics UK Limited: 2 Howard Court, 10 Tewin Road, Welwyn Garden City, Hertfordshire AL7 1BW, United Kingdom, Telephone: (44) 1707-294888, Fax: (44) 1707-325777
North Europe: Hamamatsu Photonics Norden AB: Smidesvgen 12, SE-171 41 Solna, Sweden, Telephone: (46) 8-509-031-00, Fax: (46) 8-509-031-01
Italy: Hamamatsu Photonics Italia S.R.L.: Strada della Moia, 1/E, 20020 Arese, (Milano), Italy, Telephone: (39) 02-935-81-733, Fax: (39) 02-935-81-741
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions.
Specifications are subject to change without notice. No patent rights are granted to any of the circuits described herein. 2003 Hamamatsu Photonics K.K.
Cat. No. KACC1086E01
May 2003 DN
4
s
Hardware setup
Refer to the drawing below to set up the hardware used in conjunction with this camera.
DC+5 V, 15 V
DC POWER SOURCE
CCD MULTICHANNNEL
DETECTOR HEAD
C9047/C9047-01
POWER
RS232C
DIGITAL I/O
SERIAL COMMUNICATION
LEN
DATA-TRIG
D11-D00
/CNT
/RESET,
PC WITH FRAME GRABBER, etc.
KACCC0186EA
