SPS
KA2S0680
1
SPS
The SPS product family is specially designed for an off line
SMPS with minimal external component. The SPS consist of
high voltage Power SenseFET and current mode PWM IC.
Included control IC features a trimmed oscillator, under
voltage lock out, leading edge blanking, optimized gate turn-
on/turn-off driver, thermal shut down protection, over voltage
protection, and temperature compensated precision current
source for loop compensation and fault protection circuitry.
Compared to discrete MOSFET and controller or RCC
switching converter solution, a SPS can reduce total
component count, design size, weight and at the same time
increase efficiency, productivity and system reliability. It has
a basic platform well suited for cost effective monitor power
supply.
FEATURES
Wide operating frequency range up to 150kHz
Pulse by pulse over current limiting
Over load protection
Over voltage protection (Min. 23V)
Internal thermal shutdown function
Under voltage lockout
Internal high voltage sense FET
External sync terminal
Latch up Mode
ORDERING INFORMATION
Device
Package
Rating
Topr (
C)
KA2S0680
TO-3P-5L
800V, 6A
-
25
C to +85
C
TO-3P-5L
1.DRAIN 2. GND 3. V
CC
4. FB 5. Sync
BLOCK DIAGRAM
#3 V
CC
32V
2
A
5V
2.5R
1R
1mA
0.1V
+
-
OVER VOLTAGE S/D
+
-
7.5V
25V
Thermal S/D
S
R
Q
Power on reset
+
-
L.E.B
S
R
Q
OSC
5V
Vref
Internal
bias
Good
logic
SFET
#1 DRAIN
#2 GND
#4 FB
#5 Sync
9V
+
-
6.4V
Rev. B
1999 Fairchild Semiconductor Corporation
KA2S0680
SPS
2
ABSOLUTE MAXIMUM RATINGS
NOTES:
1.
Tj=25
C to 150
C
2.
Repetitive rating: Pulse width limited by maximum junction temperature
3.
L=24mH, V
DD
=50V, R
G
=25
, starting Tj=25
C
4.
L=13uH, V
DD
=310V, Tj=25
C
Characteristic
Symbol
Value
Unit
Drain-source (GND) voltage
(1)
V
DSS
800
V
Drain-Gate voltage (R
GS
=1M
)
V
DGR
800
V
Gate-source (GND) voltage
V
GS
30
V
Drain current pulsed
(2)
I
DM
24.0
A
DC
Single pulsed avalanche energy
(3)
E
AS
455
mJ
Avalanche current
(4)
I
AS
20
A
Continuous drain current (T
C
=25
C)
I
D
6.0
A
DC
Continuous drain current (T
C
=100
C)
I
D
4.0
A
DC
Supply voltage
V
CC
30
V
Analog input voltage range
V
FB
-
0.3 to V
SD
V
Total power dissipation
P
D
(watt H/S)
150
W
Derating
1.21
W/
C
Operating temperature
T
OPR
-
25 to +85
C
Storage temperature
T
STG
-
55 to +150
C
SPS
KA2S0680
3
NOTE: Pulse test: Pulse width
300
S, duty cycle
2%
ELECTRICAL CHARACTERISTICS (SFET part)
(Ta=25
C unless otherwise specified)
Characteristic
Symbol
Test condition
Min.
Typ.
Max.
Unit
Drain-source breakdown voltage
BV
DSS
V
GS
=0V, I
D
=50
A
800
-
-
V
Zero gate voltage drain current
I
DSS
V
DS
=Max., Rating, V
GS
=0V
-
-
50
A
V
DS
=0.8Max., Rating,
V
GS
=0V, T
C
=125
C
-
-
200
A
Static drain-source on resistance
(note)
R
DS(ON)
V
GS
=10V, I
D
=4.0A
-
1.6
2.0
Forward transconductance
(note)
gfs
V
DS
=15V, I
D
=4.0A
1.5
2.5
-
mho
Input capacitance
Ciss
V
GS
=0V, V
DS
=25V,
f=1MHz
-
1600
-
pF
Output capacitance
Coss
-
140
-
Reverse transfer capacitance
Crss
-
42
-
Turn on delay time
td(on)
V
DD
=0.5BV
DSS
, I
D
=6.0A
(MOSFET switching
time are essentially
independent of
operating temperature)
-
60
-
nS
Rise time
tr
-
150
-
Turn off delay time
td(off)
-
300
-
Fall time
tf
-
130
-
Total gate charge
(gate-source+gate-drain)
Qg
V
GS
=10V, I
D
=6.0A,
V
DS
=0.5BV
DSS
(MOSFET
switching time are
essentially independent of
operating temperature)
-
70
-
nC
Gate-source charge
Qgs
-
16
-
Gate-drain (Miller) charge
Qgd
-
27
-
KA2S0680
SPS
4
NOTES:
1.
These parameters, although guaranteed, are not 100% tested in production
2.
These parameters, although guaranteed, are tested in EDS (wafer test) process
3.
The amplitude of the sync. pulse is recommended to be between 2V and 3V for stable sync. function.
ELECTRICAL CHARACTERISTICS (Control part)
(Ta=25
C unless otherwise specified)
Characteristic
Symbol
Test condition
Min.
Typ.
Max.
Unit
REFERENCE SECTION
Output voltage
(1)
Vref
Ta=25
C
4.80
5.00
5.20
V
Temperature Stability
(1)(2)
Vref/
T
-
25
C
Ta
+85
C
-
0.3
0.6
mV/
C
OSCILLATOR SECTION
Initial accuracy
F
OSC
Ta=25
C
18
20
22
kHz
Frequency change with temperature
(2)
F/
T
-
25
C
Ta
+85
C
-
5
10
%
Sync threshold voltage
(3)
V
SYTH
Vfb=5V
6.0
6.4
6.8
V
PWM SECTION
Maximum duty cycle
Dmax
-
92
95
98
%
FEEDBACK SECTION
Feedback source current
I
FB
Ta=25
C, Vfb=GND
0.7
0.9
1.1
mA
Shutdown delay current
Idelay
Ta=25
C, 5V
Vfb
V
SD
1.4
1.8
2.2
A
OVER CURRENT PROTECTION SECTION
Over current protection
I
L
(max)
Max. inductor current
3.52
4.00
4.48
A
UVLO SECTION
Start threshold voltage
Vth(H)
-
14
15
16
V
Minimum operating voltage
Vth(L)
After turn on
9
10
11
V
TOTAL STANDBY CURRENT SECTION
Start current
I
ST
V
CC
=14V
0.1
0.3
0.55
mA
Operating supply current
(control part only)
I
OPR
Ta=25
C
6
12
18
mA
V
CC
zener voltage
V
Z
I
CC
=20mA
30
32.5
35
V
SHUTDOWN SECTION
Shutdown Feedback voltage
V
SD
-
6.9
7.5
8.1
V
Thermal shutdown temperature (Tj)
(1)
T
SD
-
140
160
-
C
Over voltage protection voltage
V
OVP
-
23
25
28
V
SOFT START SECTION
Soft start current
I
SS
Sync & S/S=GND
0.8
1.0
1.2
mA
Soft start voltage
V
SS
V
FB
=2V
4.7
5.0
5.3
V
SPS
KA2S0680
5
TYPICAL PERFORMANCE CHARACTERISTICS
(These characteristic graphs are normalized at Ta=25
C)
Figure 1. Operating Frequency
Figure 2. Feedback Source Current
Figure 3. Operating Current
Figure 4. Max. Inductor Current
Figure 5. Start up Current
Figure 6. Start Threshold Voltage
KA2S0680
SPS
6
TYPICAL PERFORMANCE CHARACTERISTICS (Continued)
(These characteristic graphs are normalized at Ta=25
C)
Figure 7. Stop Threshold Voltage
Figure 8. Maximum Duty Cycle
Figure 9. V
CC
Zener Voltage
Figure 10. Shutdown Feedback Voltage
Figure 11. Shutdown Delay Current
Figure 12. Over Voltage Protection
SPS
KA2S0680
7
TYPICAL PERFORMANCE CHARACTERISTICS (Continued)
(These characteristic grahps are normalized at Ta=25
C)
Figure 13. Soft Start Voltage
Figure 14. Drain Source Turn-on Resistance
