EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

SPECIFICATION

1. General Description

The EM78M611 is a series of Universal Serial Bus 8-bit RISC Multi-Time Programming

(MTP) microcontrollers. It is specifically designed for USB low speed device application and
to support legacy device such as PS/2 keyboard. The EM78M611 also support one device
address and three endpoints. With no firmware involved, these series of microcontrollers can
automatically identify and decode Standard USB Command to EndPoint Zero.

The EM78M611 is implemented on a RISC architecture. It has eight-level stack and eight

interrupt sources. Each device has 144 bytes of general purpose SRAM and 6K bytes of
program ROM, and is embedded with 4 bytes of E

PROM. The EM78M611 has up to 11

pins with the capacity of sinking large current.

These series of chips have many powerful features, including :

Dual Clock mode which allows the device to run on very low power saving frequency

Pattern Detect Application function which is used in a serial transmission to count

waveform width

Width Modulation that can generate a duty-cycle-programmable signal

24-channel AD converter with up to 10 bits resolution.

2. Features

Operating voltage 4.4V ~ 5.25V

Low-cost solution for low-speed USB devices, such as keyboard, joystick, and

Gamepad.

USB Specification Compliance

Universal Serial Bus Specification Version 1.1

USB Device Class Definition for Human Interface Device (HID), Firmware

Specification Version 1.1

Support 1 device address and 3 endpoints

USB Application

P75(D-) has an internal pull-high resistor (1.5K Ohm)

USB protocol handling

USB device state handling

Identifying and decoding of Standard USB commands to EndPoint Zero

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

PS/2 Application Support

Auto-detects PS/2 or USB port

Build-in PS/2 port interface for keyboard and mouse

Built-in 8-bit RISC MCU

8 level stacks for subroutine and interruption

Eight available interruptions

8-bit real time clock/counter (TCC) with overflow interruption

Built-in RC oscillator free running for WatchDog Timer and Dual clock mode

Two independent programmable prescalers for WDT and TCC

Two methods of saving power:

1. Power-down mode (SLEEP mode)

2. Dual clock mode.

Two clocks per instruction cycle

Multi-time programmable

I/O Ports

Up to 11 LED sink pins

Each GPIO pin of Ports 5, 6, 8, P90~P93, P95, and P96; has an internal

programmable pull-high resistor (25K Ohm)

Each GPIO pin of Port 6, P74~P77, and Port 9 can wakeup the MCU from sleep

mode by input state change

Internal Memory

Built-in 6K*13 bits Program ROM

Built-in 144 bytes general purpose registers (SRAM)

Built-in USB Application FIFOs.

Built-in 4 bytes E2PROM

Operation Frequency

Normal Mode: MCU runs at the external oscillator frequency; 6MHz or 12MHz

Dual Clock Mode: MCU runs at the frequency of 256KHz (or 32KHz, 4KHz, 500Hz),

emitted by the internal oscillator with the external ceramic resonator (or crystal)

turned off to save power.

Built-in Pattern Detect Application for serial signal transmission

Built-in Pulse Width Modulation (PWM)

Up to 2 channels PWM function on P.92 (PWM1) and P.93 (PWM2).

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

Up to 8-bit resolution PWM output

Up to 8 selections of duty cycles

Built-in 24-Channel Analog-to-Digital Converter (ADC)

Up to 24 channels

Up to 10 bits resolution

4 ADC conversion rates: 256K/12K/64K/32K

Built-in 3.3V Voltage Regulator

For MCU power supply

Pull-up source for the external USB resistor on D-pin.

Package Type:

40 pin PDIP (EM78M611(A/B/C/D) AP)

44 pin QFP (EM78M611(A/B/C/D) AQ)

20 pin PDIP/SOP (EM78M611(A/B/C/D) BP/BM)

20 pin SSOP (EM78M611(A/B/C/D) DM)

24 pin PDIP/SOP (EM78M611(A/B/C/D) CP/CM)

3. Type Definition

The EM78M611 series has 4 types of packaging. Each type is divided into 4 modules,

namely; original, with E

PROM, with A/D converter, and with both E

PROM and A/D

converter. The Table 3.1 below summarizes which series of the EM78611 belong to which
module.

Original

With E

PROM

With A/D

Converter

With Both

EM78M611A

EM78M611B

EM78M611C

EM78M611D

Table 3-1 Packaging Summary of EM78M611 Series IC

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

5. Pin Configuration

EM78M611AP (40-Pin DIP)

VSS 1

40 OSCO

V3.3 2 39 OSCI

D+ / CLK / P74 3 38 VDD

D- / DATA / P75 4 37 P70

P90 5 36 P71
P91 6 35 P72

P92 / PWM1 / SE1 7 34 P67 / AD23
P93 / PWM2 / SE2 8 33 P66 / AD22

P94/Vpp 9 32 P65 / AD21

VNN 10 31 P64 / AD20

P50 / AD0 11 30 P63 / AD19
P51 / AD1 12 29 P62 / AD18
P52 / AD2 13 28 P61 / AD17
P53 / AD3 14 27 P60 / AD16
P54 / AD4 15 26 P87 / AD15
P55 / AD5 16 25 P86 / AD14
P56 / AD6 17 24 P85 / AD13
P57 / AD7 18 23 P84 / AD12
P80 / AD8 19 22 P83 / AD11
P81 / AD9 20 21 P82 / AD10

EM78M611AQ (44-Pin QFP)

P90

D- / DA

T
A

/ P75

D+ / CLK / P74

V3.3

VSS

VDD

P76

P77

P70

�

P91

P71

P92 / PWM1 / SE1

P72

P93 / PWM2 / SE2

P67 / AD23

P94/Vpp

P66 / AD22

P95

P65 / AD21

P96

P64 / AD20

VNN

P63 / AD19

P50 / AD0

P62 / AD18

P51 / AD1

P61 / AD17

P52 / AD2 10

P60 / AD16

P53 / AD3 11

P87 / AD15

P54 /

AD4

P55 /

AD5

P56 /

AD6

P57 /

AD7

P80 /

AD8

P81 /

AD9

P82 /

AD10

P83 /

AD1

P84 /

AD12

P85 /

AD13

P86 /

AD14

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

EM78M611BP/BM/DM (20-Pin PDIP/SOP/SSOP)

P56/AD6 1

20 P55 / AD5

P57/AD7 2 19 P54 / AD4

P60/AD16 3 18 VNN
P61/AD17 4 17 P94/Vpp
P62/AD18 5 16 P93 / PWM2 / SE2

P77 6 15 P92 / PWM1 /SE1
P76 7 14 D- / DATA / P75

VDD 8 13 D+ / CLK / P74

OSCI 9 12 V3.3

OSCO 10 11 VSS

EM78M611CP/CM (24-Pin PDIP/SOP)

OSCO 1

24 OSCI

VSS 2 23 VDD

V3.3 3 22 P76

D+ / CLK / P74 4 21 P77

D- / DATA / P75 5 20 P66 / AD22

P92 / PWM1 /SE1 6 19 P65 / AD21

P93 / PWM2 / SE2 7 18 P64 / AD20

P94/Vpp 8 17 P63 / AD19

VNN 9 16 P62 / AD18

P54 / AD4 10 15 P61 / AD17
P55 / AD5 11 14 P60 / AD16
P56 / AD6 12 13 P57 / AD7

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

6. Pin Description

Pin Number

I/O

Function

P50 ~ P57
P60 ~ P67
P80 ~ P87

I/O

GPIO pins. These pins can be pulled-high internally through software
control.

AD0 ~ AD23

Analog to Digital Converter input pins.

P90 ~ P93
P95 ~ P96

I/O

GPIO pins. These pins can be pulled-high internally through software
control or LED sink pins.

PWM1 ~ PWM2

PWM output pins

SE1 ~ SE2

Serial Signal input pins.

P70 ~ P72, P76,
P77

I/O

LED sink pins.
P76, P77 will have an internal pulled-high resistor when the
EM78M611 is running under PS/2 mode.

D+ / CLK / P74

I/O

USB plus data line interface or CLK for PS/2 keyboard.
When the EM78M611 is running under PS/2 mode, this pin will have
an internal pulled-high resistor (2.2K Ohm), with V

=5.0V.

D- / DATA / P75

I/O

USB minus data line interface or DATA for PS/2 keyboard.

When the EM78M611 is running under PS/2 mode, this pin will have
an internal pulled-high resistor (2.2K Ohm), with V

=5.0V.

When the EM78M611 is running under USB mode, this pin will have
an internal pulled-high resistor, 1.5k Ohm, with V

3.3

=3.3V.

OSCI

6MHz / 12MHz ceramic resonator or crystal input.

OSCO

Return path for 6-MHz / 12MHz ceramic resonator or crystal.

VDD

PWR Power supply pin.

GND PWR

Ground

pin.

MTP program Pin

P94/V

Input only I/O. MTP program pin.

3.3

PWR 3.3v regulator output.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

7. Block Diagram

Oscillator

Timing

Control

Built-in

Prescaler

(TCC)

W DT

Timer

DATA & CONTROL BUS

OSCI

OSCO

(PC)

Stack1

ALU

ACC

(Status)

ROM

Instruction

register

Instruction

Decoder

Interrupt

Control

Reset &
Sleep &

W ake up

Control

3.3V

Regulator

USB

Device

Controller

VDD

V3.3

Transceiver

D+

D-

TCC

W DT

RAM

(RSR)

Stack2
Stack3
Stack4
Stack5

EEPROM

Prescaler

I/O

Port 8

P80/AD

P81/AD

P82/AD

P83/AD

P84/AD

P85/AD

P86/AD

P87/AD

I/O

Port 9

P90

P91

P92/PW M1/SE1

P94/Vpp

P95

P96

I/O

Port 7

P74/D+/Clk

P75/D-/Data

Pattern

Detect

Application

ADC

PW M

Stack6
Stack7

P70

P71

P72

P93/PW M2/SE2

I/O

Port 6

P60/AD

P61/AD

P62/AD

P63/AD

P64/AD

P65/AD

P66/AD

P67/AD

I/O

Port 5

P50/AD

P51/AD

P52/AD

P53/AD

P54/AD

P55/AD

P56/AD

P57/AD

P76

P77

Stack8

8. Function Description

The EM78M611memory is organized into four spaces, namely; User Program memory in

6K*13 bits ROM space, Data Memory in 144 bytes SRAM space, E

PROM space, and USB

Application FIFOs for EndPoint0, EndPoint1, and EndPoint2. Furthermore, several registers
are used for special purposes.

8.1 Program Memory

The program space of the EM78M611 is 6K bytes, and is divided into six pages. Each page

is 1K bytes long. After Reset, the 13-bit Program Counter (PC) points to location zero of the
program space.

The Interrupt Vector is at 0x0001 and accommodates TCC interrupt, RF1(SE1) timing

counter interrupt, RF2(SE2) timing counter interrupt, P74~P77 State Changed interrupt,
EndPoint 0 interrupt, USB Suspend interrupt, USB Reset interrupt, and USB Host Resume
interrupt.

After an interrupt, the MCU will fetch the next instruction from the corresponding address as

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

After reset Address

0x0000

Reset Vector

0x0001

0x03FF

Interrupt Vector
Page 0

0x0400

0x07FF

Page 1

0x0800

0x0BFF

Page 2

0x0C00

0x0FFF

Page 3

0x1000

0x13FF

Page 4

0x1400

0x17FF

Page 5

8.2 Data

Memory

The Data Memory has 144 bytes SRAM space. It is also equipped with USB Application

FIFO space for USB Application. The Figure 8.1 (next page) shows the organization of the
Data Memory Space.

8.2.1 Special Purpose Register

When the microcontroller executes instruction, specific registers are invoked for assistance,

such as; Status Register which records the calculation status, Port I/O Control Registers
which control the I/O pins' direction, etc. EM78M611 provides a lot of other special purpose
registers for different functions.

Note that Special Control Registers can only be read or written by two instructions: IOR and

IOW.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

00
01
02
03
04
05
06
07
08
09

0A
0B
0C
0D

R0
R1(TCC)

R2(PC)

R3(Status)
R4(RSR)
R5(Port5)
R6(Port6)
P7(Port7)
R8(Port8)
R9(Port9)
RA(EECR)
RB(PDACR)
RC(USBSR)
RD(FIFOA)
RE(FIFODR)
RF(ISR)

IOCA

IOCD

IOCE
IOCF

Stack

(8 levels)

IOC5
IOC6
IOC7
IOC8
IOC9

16x8 Com m on

32x8 Bank

00
01

20
21

EndPoint

address

Endpoint 0

10
11

EP0_status

EP_status

10
11

IOCC

IOCB

ERA(ADCR/AD_Sel)
ERB(AD_LSB)
ERC(AD_MSB)

ERE(PWM_CNT)

ERD(AD Rate)

32x8 Bank

0
1
2
3
4
5
6
7

Fig 8.1 The Organization of EM78M611 Data RAM

8.2.1.1 Operation Registers

The following sections will introduce each of the Operation Registers of the Special Purpose

Registers. The Operation Registers are arranged according to the order of registers' address.
Note that some registers are read only, while others are both readable and writable.

R0 (Indirect Addressing Register) Default Value: (0B_0000_0000)

R0 is not a physically implemented register. Its major function is to be an indirect addressing

pointer. Any instruction using R0 as a pointer actually accesses the data pointed by the RAM
Select Register (R4).

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

R1 (Time / Clock Counter) Default Value: (0B_0000_0000)

This register TCC, is an 8-bit timer or counter. It is readable and writable as any other

After Power-on reset and WatchDog reset, the initial value of this register is 0x00.

R2 (Program Counter & Stack) Default Value: (0B_0000_0000)

The EM78M611 Program Counter is a 13-bit long register that allows accessing 6k bytes of

Program Memory with 8 level stacks. The eight LSB bits, A0~A7, are located at R2, while
the three MSB bits, A12~A10, are located at R3. The Program Counter is cleared after
Power-on reset or WatchDog reset. The first instruction that is executed after a reset is
located at address 00h.

A9 A8

0800

Page

0BFF
0C00

Page

0FFF
1000

Page

13FF
1400

Page

17FF

Stack

Stack 6

RET
RETL
RETI

000 :

Reset location

101

100

011

010

001

000

CALL

Stack 5

Stack 4

Stack 3

Stack 2

Stack 1

0000

Page

03FF
0400

Page

07FF

A7 ~ A0

A12 A11 A10

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

R3 (Status Register) Default Value:(0B_0001_1XXX)

7 6 5

PS2 PS1 PS0 T P Z DC C

R3 [0] Carry flag.

R3 [1] Auxiliary carry flag.

R3 [2] Zero flag. It will be set to 1 when the result of an arithmetic or logic operation is

zero.

R3 [3] Power down flag. It will be set to 1 during Power-on phase or by "WDTC" command

and cleared when the MCU enters into Power down mode. It remains in previous
state after WatchDog Reset.

Power-on.

0: Power down

R3 [4] Time-out flag. It will be set to 1 during Power-on phase or by "WDTC" command. It

is reset to 0 by WDT time-out.

1: WatchDog timer no overflow.

0: WatchDog timer overflow.

The various states of Power down flag and Time-out flag at different conditions are shown

below:

Condition

1
1
0
1
1

1
1

0
0

Power-on reset
WDTC instruction
WDT time-out
Power down mode
Wakeup caused by port change during Power down mode

*P: Previous status before WDT reset

R3 [5-7] Page selection bits. These three bits are the used to select the page of program

memory.

PS2

PS1

PS0

Program Memory Page [Address]

0 0 0

Page

[0000-03FF]

0 0 1

Page

[0400-07FF]

0 1 0

Page

[0800-0BFF]

0 1 1

Page

[0C00-0FFF]

1 0 0

Page

[1000-13FF]

1 0 1

Page

[1400-17FF]

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

R4 (RAM Select Register) Default Value: (0B_00XX_XXXX)

7 6 5 4 3 2 1 0

BK1 BK0 Ad5 Ad4 Ad3 Ad2 Ad1 Ad0

R4 (RAM select register) contains the address of the registers.

R4 [0~5] are used to select registers in 0x00h~0x3Fh. The address 0x00~0x1F is common

space. After 0x1Fh, SRAM are divided into four banks. Use Bank Select Register.

R4 [6,7] to select the registers bank (refer to the table below).The following are two

examples:

(1) R4=0001100 and R4=1001100 point to the same register 0x0Ch. Since
0x0Ch is in the common space, Bit 6 and Bit 7 are meaningless.

(2) R4=0111100 points to the register 0x3C in Bank 2.

R4[7]Bk1

R4[6]Bk0

RAM Bank #

0
0
1
1

0
1
0
1

Bank 0
Bank 1
Bank 2
Bank 3

R5 (Port5 I/O register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

P57 P56 P55 P54 P53 P52 P51 P50

R6 (Port 6 I/O register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

P67 P66 P65 P64 P63 P62 P61 P60

R7 (Port7 I/O register) Default Value: (0B_0000_0000)

7 6

3 2 1 0

P77

P76

D- / P75 / DATA

D+ / P74 / CLK

P72

P71

P70

R8 (Port 8 I/O register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

P87 P86 P85 P84 P83 P82 P81 P80

R9 (Port 9 I/O register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

- P96 P95 P94 P93 P92 P91 P90

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

RA (E

PROM Control Register) Default Value: (0B_0000_0011)

RA is a command register for E

RPOM control. For detailed usage of this register, refer to

Section 8.2.3 which describes the E

RPOM embedded in the EM78M611.

RB (Pattern Detect Application Control Register) Default Value: (0B_0000_0000)

RB is a control register for controlling the Pattern Detect Application function. For the

detailed description of this register, refer to Section 8.7.2 which describes the PDA function.

RC (USB Application Status Register) Default Value: (0B_0000_0000)

7 6 5 4 3

1 0

EP0_W EP0_R EP1_R

EP2_R

EP2_W Host_Suspend EP0_Busy Stall

RC [0] Stall flag While MCU receives an unsupported command or invalid parameters from

host, this bit will be set to 1 by the firmware to notify the UDC to return a
STALL handshake. When a successful SETUP transaction is received,
this bit is cleared automatically. This bit is readable and writable.

RC [1] EP0_Busy flag When this bit is equal to "1," it indicates that the UDC is writing data

into the EP0'FIFO or reading data from it. During this time, the firmware
will avoid accessing the FIFO until UDC finishes writing or reading. This bit
is only readable.

RC [2] Host Suspend flag If this bit is equal to 1, it indicates that USB bus has no traffic for

the specified period of 3.0 ms. This bit will also be cleared automatically
when there is bus activity. This bit is only readable.

RC [3] EP2_W flag This bit is set when the UDC receives a successful data from USB

Host to EP2. Upon detecting that this bit is equal to One, the firmware will
execute a read sequence to the EP2's FIFO, then clear this bit. Otherwise,
the subsequent data from USB Host won't be accepted by the UDC.

RC [4,5,6] EP0_R / EP1_R / EP2_R flag These three bits inform the UDC to read the data

written by the firmware from the FIFO. Then the UDC will send the data to
the Host automatically. After UDC finishes reading the data from the FIFO,
this bit will be cleared automatically.

Therefore, before writing data into FIFO's, the firmware will first check this
bit to avoid overwriting the data. These two bits can only be set by the
firmware and cleared by the hardware.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

RC [7] EP0_W flag After the UDC completes writing data to the FIFO, this bit will be set

automatically. The firmware will clear it as soon as it gets the data from
EP0's FIFO. Only when this bit is cleared that the UDC will be able to
write a new data into the FIFO.

Therefore, before the firmware can write a data into the FIFO, this bit
must first be set by the firmware to prevent UDC from writing data at
the same time. This bit is both readable and writable.

RD (USB Application FIFO Address Register) Default Value: (0B_0000_0000)

4 3 2 1 0

0 0 0 UAD4 UAD3 UAD2 UAD1 UAD0

RD [0~4] USB Application FIFO address registers. These five bits are the address pointer

of USB Application FIFO.

RD [5~7] Undefined registers. The default value is zero.

RE (USB Application FIFO Data Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

UD7 UD6 UD5 UD4 UD3 UD2 UD1 UD0

RE (USB Application FIFO data register) contains the data in the register of which address

is pointed by RD.

RF (Interrupt Status Register ) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

USB Host

Resume_IF

SE2_IF

SE1_IF

Port7 state

change_1F

USB

Reset_IF

USB

Suspend_IF

EP0_IF TCC_IF

RF [0]

TCC Overflow interrupt flag. It will be set while TCC overflows, and is cleared by
the firmware.

RF [1]

EndPoint Zero interrupt flag. It will be set when the EM78M611 receives Vender
/Customer Command to EndPoint Zero. This bit is cleared by the firmware.

RF [2]

USB Suspend interrupt flag. It will be set when the EM78M611 finds the USB
Suspend Signal on USB bus. This bit is cleared by the firmware.

RF [3]

USB Reset interrupt flag. It will be set when the host issues the USB Reset
signal.

RF [4]

Port 7 State Change interrupt flag. It will be set at P.74 ~ P.77 State Change
when the EM78M611 is not running under USB mode.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

RF [5,6]

SE1 / SE2 Pattern Detection interrupt flag. These two flags are used for Pattern
detecting application.

RF [7]

USB Host Resume interrupt flag. It will be set only under Dual clock mode when
the USB suspend signal becomes low.

8.2.1.2 Control Registers

Some special purpose registers are available for special control purposes. Except for the

Accumulator (A), these registers must be read and written by special instructions. One of
these registers, CONT, can only be read by the instruction "CONTR" and written by
"CONTW" instruction. The other special control registers can be read by the instruction
"IOR" and written by the instruction "IOW."

The following paragraphs only describe the general functions of the control registers. For

more detailed description, refer to Sections 8.7 to 8.9 of this spec.

A (Accumulator Register)

The accumulator is an 8-bit register that holds operands and results of arithmetic

calculations. It is not addressable.

CONT (Control Register) Default Value: (0B_0011_1111)

7 6 5 4 3 2 1 0

LED

/INT TSR2 TSR1 TSR0 PSR2 PSR1 PSR0

Except for Bit-6 (Interrupt enable control bit), CONT register can be read by the instruction

"CONTR" and written by the instruction "CONTW."

CONT [0~2] WatchDog Timer prescaler bits. These three bits are used as the prescaler of

WatchDog Timer.

CONT [3~5] TCC Timer prescaler bits.

The relationship between the prescaler value and these bits are shown below:

PSR2/TSR2

PSR1/TSR1

PSR0/TSR0

TCC Rate

WDT Rate

0 0 0

0 0 1

0 1 0

0 1 1

1 0 0

1 0 1

1 1 0

128

1 1 1

256

128

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

CONT [6] Interrupt enable control bit. This bit toggles Interrupt function between enable

and disable. It is set to 1 by the interrupt disable instruction "DISI" and reset by
the interrupt enable instructions "ENI" or "RETI."

0: Enable the Interrupt function.

1: Disable the Interrupt function.

Note that this bit can be read only by the instruction "CONTR"

CONT [7] LED bit. This bit is used to enable the LED sink capacity of P76 and P77.

0: Disable the LED sink capacity of P76, P77.

1: Enable the LED sink capacity of P76, P77.

IOC5 ~IOC9 I/O Port Direction Control Registers

These are I/O port (Port5 ~ Port7) direction control registers. Each bit controls the I/O

direction of three I/O ports respectively. When these bits are set to 1, the relative I/O pins
become input pins. Similarly, the I/O pins becomes outputs when the relative control bits are
cleared.

1: Input direction.

0: Output direction.

IOCA (Operation Mode Control Register) Default Value: (0B_1100_0000)

7 6

3 2 1 0

Dual_Frq.1

Dual_Frq.0 - - ExReg_Sel

PDA

PS/2

USB

IOCA [0,1] These two bits are used to select the operation mode. EM78M611 can

auto-detect the type of port device being attached. After identifying the port, the
firmware will set these two bits to enter into a proper operation mode. The
definition of these two control registers is described in the table below.

IOCA[1]

IOCA[0]

Operation Mode

0 0

Detect

Mode

0 1

USB

Mode

1 0

PS/2

Mode

USB Test Mode

IOCA [2]

Pattern Detect Application function enable bit. This bit is used to enable the
Pattern Detect Application (PDA) function. For the details about this function
please refer Section 8.7.

0: Disable PDA function.

1: Enable PDA function.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

IOCA [3]

Extra control register select bit. The five extra control registers (ERA, ERB,
ERC, ERD, and ERD) are located in 0xA~0xE. To access these five registers,
set the bit as follows:

0: Select RA ~ RE.

1: Select Extra Control registers � ERA ~ ERE.

IOCA [6,7]

Selects the operation frequency in Dual Clock Mode. Four frequencies are

available and can be chosen as Dual Clock Mode for running the MCU
program.

Dual_Frq.1

Dual_Frq.0

Frequency

0 0

500Hz

0 1

4kHz

1 0

32kHz

1 1

256kHz

IOCB (Port 9 Wake-up Pin Select Register) Default Value: (0B_1111_1111)

7 6 5 4 3 2 1 0
1 /P96 /P95 /P94 /P93 /P92 /P91 /P90

IOCB [0~6] These bits are used to select which of the Port 9 pins is to be assigned to

wakeup the MCU while in Power down mode.

0: Enable the function.

1: Disable the function.

IOCB [7]

Undefined. The default value is Zero.

IOCC (Port 9 LED Sink Capacity Control Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0
0 P96

P95 0 P93

P92

P91

P90

IOCC [0~3,5,6] LED sink control bit. These bits are used to enable the LED sink capacity of

P90 ~ P93, P95, and P96.

0: Disable the LED sink capacity of respective pin.

1: Enable the LED sink capacity of respective pin.

IOCC [4,7]

Undefined. The default value is Zero.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

IOCD (Port 9 Pull High Control Register) Default Value: (0B_1111_1111)

7 6 5 4 3 2 1 0
1 /PH96

/PH95 1 /PH93

/PH92

/PH91

/PH90

IOCD [0~6] These bits control the 200KOhm pull-high resistor of individual pins in Port 9.

1: Disable the function of pull-high.

0: Enable the function of pull-high.

IOCE (Special Function Control Register) Default Value: (0B_1101_01111)

6 5 4

2 1 0

/Dual clock

/WUE

WTE

RUN

Device_Resume

/PU8

/PU6

/PU5

IOCE [0,1,2] Port 5, Port 6, and Port 8 pull-high control bits.

Disable

Enable

IOCE [3]

Device Resume control bit. Writing this bit to "1" can generate Device
Resume signal on USB bus. As long as the USB bus is not idle, this bit will be
cleared at the same time.

IOCE [4]

Run bit. This bit can be cleared by the firmware and set during power-on, or
by the hardware at the falling edge of wake-up signal. When this bit is cleared,
the clock system is disabled and the MCU enters into Power down mode. At
the transition of wake-up signal from high to low, this bit is set to enable the
clock system.

1: Run mode. The EM78M611 is working normally.

0: Sleep mode. The EM78M611 is in power down mode.

IOCE [5]

WatchDog Timer enable bit. The bit disable/enables the WatchDog Timer.

1: Enable WDT.

0: Disable WDT.

IOCE [6]

Enable the wake-up function as triggered by port-changed. This bit is set by
UDC.

1: Disable the wake-up function.

0: Enable the wake-up function.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

IOCE [7]

Dual clock Control bit. This bit is used to select the frequency of system clock.
When this bit is cleared, the MCU will run on very low frequency for power
saving and the UDC will stop working.

1: Selects EM78M611 to run on normal frequency.

0: Selects to run on slow frequency.

IOCF (Interrupt Mask Register)

Default Value (0B_0000_0000)

7 6 5 4 3 2 1 0

USB Host

Resume_IE

SE2_IE

SE1_IE

Port7 state

change_1E

USB

Reset_IE

USB

Suspend_IE

EP0_IE TCC_IE

IOCF [0~7] TCC / EP0 / USB Suspend / USB Reset / Port 7 State Change / SE1 / SE2 /

USB Host Resume interrupt enable bits. These eight bits control the function of
TCC interrupt, EP0 interrupt, USB Suspend interrupt, USB Reset interrupt,
Port7 State Change interrupt, SE1 pattern detection interrupt, SE2 pattern
detection interrupt and USB Host Resume interrupt respectively. Individual
interrupt is enabled by setting its associated control bit in the IOCF to "1."

1: Enable Interrupt.

0: Disable Interrupt.

Only when the global interrupt is enabled by the ENI instruction that the individual interrupt

will work. After DISI instruction, any interrupt will not work even if the respective control bits
of IOCF are set to 1.

The USB Host Resume Interrupt works only under Dual clock mode. This is because when

the MCU is under sleep mode, it will be waked up by the UDC Resume signal automatically.

8.2.1.3 Extra Control Register

Five extra control registers are available to control special functions. The five registers are

ERA (AD Control register), ERB (AD_LSB), ERC (AD_MSB), ERD (AD_Rate), and ERE
(PWM Control register).

Remember to set IOCA[3] before accessing these five registers. The operating method is

same as other control registers.

More detailed descriptions of the registers are provided in Section 8.7 to 8.9.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.2.2 USB

Application

FIFOs

For USB Application, EM78M611 provides an 8-byte First-In-First-Out (FIFO) buffer for each

endpoint. The buffer cannot be accessed directly. However, a corresponding Data Byte
Pointer register for each endpoint is made available to address the individual byte of the
FIFO buffer. The content of the individual byte will map to a special register.

8.2.3 E

PROM

Four bytes of E

PROM are located in the R2C ~ R2F of Bank 3. The stored data of

PROM are not erased when the power is off and can be read and rewritten by firmware.

In some special case of application, for example, cordless keyboard controller, it can store
important data, such as the cordless keyboard's device identical number.

There is a control register, RA (address : 0x0A in Bank1) that controls the E

PROM, that is,

to read, write, or to erase the data from E

PROM. Writing a command into this register will

execute an action to E

PROM. The command value is defined in the following table. Note

that there is an execution time lapse for each command. Before writing the next command
into the control register, allow enough time for the E

PROM to finish the previous command.

Command Value

Action

Execution Time

0B_0000_0000

Read 1ms

0B_0000_0001

Write 9ms

0B_0000_0010

Erase 128ms

0B_0000_0011

Disable N.A.

8.3 USB

Application

EM78M611 is designed specially for USB device application and has many powerful

functions that help the firmware to free itself from complex situation in various aspects of
USB application.

8.3.1 Auto-Detect PS/2 or USB Mode

When the EM78M611 is connected to the bus, it will auto-detect and identify which type of

bus (USB or PS/2) it is connected to. The condition that influences auto-detect function is
described below:

1. After a Power-on reset, the initial value of IOCA [0,1] is 0b00. Thus the operation

mode is "Detect mode" and the D+ and D- IO pins are internal pulled high by
200KOhm to VDD.

2. The firmware checks the state of R7 [4,5]. If the state of this two bit is 0b00, set the

IOCA [0] to "1" to define the "USB mode." Otherwise, set the IOCA [1] to "1," to
define "PS/2 mode."

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

3. When the operation mode is defined as "USB mode," the D- IO pin will be internal pulled

high by a 1.5KOhm resistor to 3.3V, which is output from a built-in regulator.

4. If the operation mode is in "PS/2 mode," both of the PS/2 interface IO pins are

internal pulled high by a 2.2KOhm resistor to VDD.

{NOTE] If the auto-detect function is not used, the firmware should set the operation mode,

either USB mode or PS/2 mode, in the beginning of program.

An additional mode, "USB Test Mode" is also available. This mode has no load on D+ and

D- IO pins, and can only be used in USB Application case. Therefore, an external 1.5KOhm
resistor is needed to pull up D- IO pin to 3.3V.

Under PS/2 mode, both PS/2 pins are programmed to generate an interrupt. After setting the

P.74 ~ P.77 State changed Interrupt Enable bit, the MCU will interrupt while the state of
these four pins changes.

8.3.2 USB Device Controller

The USB Device Controller (UDC) built-in in the EM78M611 can interpret the USB Standard

Command and response automatically without involving firmware. The embedded Series
Interface Engine (SIE) handles the serialization and deserialization of actual USB
transmission. Thus, a developer can concentrate his efforts more in perfecting the device
actual functions and spend less energy in dealing with USB transaction.

The UDC handles and decodes most Standard USB commands defined in the USB

Specification Rev1.1. If UDC receives an unsupported command, it will set a flag to notify
MCU the receipt of such command. The Standard Commands that EM78M611 supports
includes; Clear Feature, Get Configuration, Get Interface, Get Status, Set Address, Set
Configuration, Set Feature, and Set Interface.

Each time UDC receives a USB command, it writes the command into EP0's FIFO. Only

when it receives unsupported command that the UDC will notify the MCU through interrupt.

Therefore, EM78M611 is very flexible under USB application because the developer can

freely choose the method of decoding the USB command as dictated by different situation.

8.3.3 Device Address and Endpoints

EM78M611 supports one device address and three endpoints, EP0 for control endpoint,

EP1 and EP2 for interrupt endpoint. Sending data to USB host in EM78M611 is very easy.
Just write data into EP's FIFO, then set flag, and the UDC will handle the rest. It will then
confirm that the USB host has received the correct data from EM78M611.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.4 Reset

The EM78M611 provides three types of reset: (1) Power-on Reset, (2) WatchDog Reset,

and (3) USB Reset.

8.4.1 Power-On

Reset

Power-on Reset occurs when the device is attached to power and a reset signal is initiated.

The signal will last until the MCU becomes stable. After a Power-on Reset, the MCU enters
into following predetermined states (see below), and then, it is ready to execute the program.

a. The program counter is cleared.

b. The TCC timer and WatchDog timer are cleared.

c. Special registers and Special Control registers are all set to initial value.

The MCU also has a low voltage detector that detects low output power condition.

Whenever the output voltage of the 3.3V regulator decreases to below 2.2V, a reset signal is
set off.

8.4.2 WatchDog

Reset

When the WatchDog timer overflows, it causes the WatchDog to reset. After it resets, the

program is executed from the beginning and some registers will be reset. The UDC however,
remains unaffected.

8.4.3 USB

Reset

When UDC detects a USB Reset signal on USB Bus, it interrupts the MCU, then proceed to

perform the specified process that follows. After a USB device is attached to the USB port, it
cannot respond to any bus transactions until it receives a USB Reset signal from the bus.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.5 Saving Power Mode

The EM78M611 provides two options of power-saving modes for energy conservation, i.e.,

Power Down mode and Dual clock mode.

8.5.1 Power Down Mode

The EM78M611 enters into Power Down mode by clearing the RUN register (IOCE[4]).

During this mode, the oscillator is turned off and the MCU goes to sleep. It will wake up
when signal from USB host is resumed, or when the WatchDog reset or the input port state
changes.

If the MCU wakes up when I/O port status changes, the direction of I/O port should be set at

input direction, then read the state of port. For example:

:
// Set the Port 6 to input port
MOV A , 0XFF
IOW PORT6
// Read the state of Port 6
MOV PORT6, PORT6
// Clear the RUN bit
IOR 0XE
AND A , 0B11101111
IOW 0XE
:
:

If the MCU is awaken by a USB Resume signal, the next instruction will be executed and

one flag, RC[3] will be set to 1.

8.5.2 Dual Clock Mode

The EM78M611 has one internal oscillator for power saving application. Clearing the Bit

IOCE [7] will enable the low frequency oscillator. At the same time, the external oscillator will
be turned off. Then the MCU will run under very low frequency to conserve power. Four
types of frequency are available for selection in setting Bits IOCA [6, 7].

The USB Host Resume Interrupt can only be used in this mode. If this interrupt is enabled,

the MCU will be interrupted when the USB Suspend signal is detected on USB Bus.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.6 Interrupt

The EM78611 has one interrupt vectors in 0x0001. When an interrupt occurs during the

MCU running program, it will jump to the interrupt vector (0x0001) and execute the
instructions sequentially from interrupt vector. RF is the interrupt status register, which
records the interrupt status in the relative flags/bits.

The interrupt condition could be one of the following:

1. TCC Overflow:

When the Timer Clock / Counter Register (R1) overflows, the
status flag RF[0] will be set to 1. Its interrupt vector is 0X0001.

2. Port7 State Change: When the input signals in Port 7 changes, the status flag RF[4]

will be set to 1. Its interrupt vector is 0X0001.

3. SE1 Pattern Detection Interrupt Conditions: If the Pattern Detection Application function

is enabled, there will be four conditions with which interruption is
generated, and the status flag RF[5] is set to 1 (interrupt vector is
0X0001).

a) Signal from P.92 changes to low, and Pattern Counter value

is bigger than R11 register value.

b) Signal from P.92 changes to high, and Pattern Counter value

bigger than R10 register value.

c) P.92 stays high, and Pattern Counter value equal 0XFF.

d) P.92 stays low, and Pattern Counter value equal 0XFF.

4. SE2 Pattern Counter Interrupt Conditions: If the Pattern Detection Application function is

enabled, there will be three conditions with which interruption is
generated and the status flag RF[6] is set to 1(interrupt vector is
0X0001).

a) Signal from P.93 changes to low, and Pattern Counter value

is bigger than R13 register value.

b) Signal from P.93 changes to high, and Pattern Counter value

is bigger than R12 register value.

c) P.93 stays high, and Pattern Counter value equal 0XFF.

d) P.93 stays low, and Pattern Counter value equal 0XFF.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

5. EP0 interrupt:

When the UDC successfully accepts a setup transaction from

host to EndPoint0, the status flag RF[1] is set to 1. Its interrupt
vector is 0X0001

6. USB suspend:

When UDC detects a USB Suspend signal on USB bus, the
status flag RF[2] is set to 1. Its interrupt vector is 0X0001.

7. USB Reset:

When the UDC detects a USB Reset signal on USB bus, the
status flag R[3] is set to 1. Its interrupt vector is 0X0001.

8. USB Host Resume:

When UDC detects that the USB bus is no longer in Suspend
condition and without Device Resume signal, the status flag R[7]
is set to 1. Its interrupt vector is 0X0001.

IOCF is an interrupt mask register which can be set bit by bit. While their respective bit is

written to 0, the hardware interrupt will inhibit, that is, the EM78M611 will not jump to the
interrupt vector to execute instructions. But the interrupt status flags still records the
conditions no matter whether the interrupt is masked or not. The interrupt status flags must
be cleared by firmware before leaving the interrupt service routine and enabling interrupt.

The global interrupt is enabled by the ENI (RETI) instruction and is disabled by the DISI

instruction.

8.7 Pattern Detect Application (PDA)

8.7.1 Function

Description

This function is designed for the serial signal transmission, e.g., the transmission between a

wireless device and its receiver box. The EM78M611 has two sets of built-in Pattern Detect
Application block that ensures the EM78M611 is equipped with a compound device, such as
the receiver box controller for a wireless keyboard paired with a wireless mouse.

Pattern Detect Application (PDA) can calculate the length of one pattern and interrupt the

MCU while the serial signal is transiting from high to low (or vise-versa). Then the MCU
reads the length value from a specified register.

8.7.2 Control

Register

The PDA includes an enable control bit, one control register and four length counter

registers in 0x10 ~0x13.

IOCA [2] PDA Enable Control Bit. When this bit is set, the PDA function starts and the P92

and P93 become input pin automatically to sample the serial
signal.

1 : enable PDA function.

0 : disable PDA function.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

RB (PDA Control Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

SE2.F SE1.F SR.2

SR.1

SR.0

DB2

DB1

DB0

This register is used to define two parameters of PDA function; signal sampling rate and

debounce length. When a pattern ends, the value in the counter is loaded into its respective
register and the RB[6] or RB[7] is set to indicate which type of pattern (high or low) is at its
end or which type of pattern counter is on overflow.

0: low pattern.

1: high pattern.

R10 (P.92 Low Pattern Counter)

This register records the length of P.92 in low status.

R11 (P.92 High Pattern Counter)

This register records the length of P.92 in high status.

R12 (P.93 Low Pattern Counter)

This register record the length of P.93 in low status.

R13 (P.93 High Pattern Counter)

This register records the length of P.93 in high status.

R10~R13 function as general registers if this function is not enabled. Once the enabled bit is

set, these four registers will be loaded with the value of pattern counter.

8.7.3 Sampling Rate and Debounce Length

Although the two pattern detect pins are separate, and each pin has its own pattern counter.

Both pins use the same Sampling Rate and Debounce Length parameters.

The PDA samples the serial signal every fixed interval. The pattern counter will increase by

one at sampling time if the signal remains unchanged. If the signal is at high state, then the
"high pattern counter" will increase; otherwise the "low pattern counter" increases. As long as
the signal state changes, the PDA will debounce signal and load the value of pattern counter
into the respectively register for the firmware to read. For example, if the signal in P.92 is in
"low" state, the low counter of P.92 will counts continuously until the state of the input signal
in P.92 changes. When the state of change occurs (in this case, the signal changes from
"low" to "high" state), the PDA will take for a time break (which is equal the result of sampling
interval multiplied by the debounce length), to avoid possible noise. After the debounce
length time, if the signal remains in high state, the high pattern counter will start to count and

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

load the low pattern counter's value into R10. At the same time, RB[6] is cleared to indicate
the low pattern is over.

The correlation between the value of control register and debounce time are as follows:

DB.2 DB.1 DB.0

Debounce Time

No Sampling clock.

1 Sampling clock

2 Sampling clock

3 Sampling clock.

4 Sampling clock

5 Sampling clock

6 Sampling clock

7 Sampling clock

Now consider another situation of this case, where the signal of P92 always stays "low". The

low pattern counter of P92 will eventually overflow. Once the counter overflows, the content
of the counter will also be loaded into R10, that is, the register is written to 0xFF, then the
counter is reset to count from zero again.

If the hardware interrupt of PDA function is enabled, (IOCF[5] is equal to "1"), then the

program will go to 0x0001 to execute interrupt routine while the content of a pattern counter
is loaded into the register.

The correlation between the value of control register and actual sampling rate are as shown

below:

SR.2 SR.1 SR.0

Sampling Rate

(External oscillator frequency = 6MHz)

Sampling Rate

(External oscillator frequency = 12MHz)

0 0 0

N.A.

0 0 1

N.A.

1500 (Count / mSec)

N.A.

750 (Count / mSec)

1500 (Count/ mSec)

375 (Count / mSec)

750 (Count / mSec)

188 (Count / mSec)

375 (Count / mSec)

94 (Count / mSec)

188 (Count / mSec)

47 (Count / mSec)

94 (Count / mSec)

After the PDA function is enabled (by setting IOCA[2] to 1), user can write a default value to

the High Pattern counter register and Low Pattern counter register. Then set the
corresponding interrupt enable bit (IOCF[5]). When the counting value of one "H" pattern is
bigger than the default value of R11, the Pattern Detecting interrupt will be generated.
Similarly, if the counting value of one "L" pattern is bigger than the default value of R10, the
Low Pattern Detecting interrupt will occur. Thus, the EM78M611 is notified and aware that
one effective pattern is received from P.92.

If user has no need of these two interrupts, they can be masked. The new value of counting

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

a pattern still will be loaded to the R10 and R11. The firmware must poll and determine
whether the value of these two registers had changed or not.

8.7.4 Example

Initial Setting :

IOCA[5:3] = 5 : Setting Prescaler. Setting 1:32.

IOR

IOCA

AND A,@0XC7

;11 00_0 111

OR A,@0X28

;00 10_1 000

IOW

IOCA

RB[3:0] = 3 : Setting Debonce Times.

MOV

A,@0X03

MOV

RB,A

R10~R13 = 150(800uS) : Setting compare value.

MOV

A,@150

MOV

R10~13,A

IOCA[2] : Enabling RF function :

IOR

IOCA

OR A,@0X04

;0000_0 1 00

IOW

IOCA

The active of the RF timing counter : After setting.

Assume that the T1 is the High pattern counter and the T2 is the Low pattern counter.

The PDA function will compare R11 or R13 with T1 or compare R10 or R12 with T2.

If T1 >= R11 , then setting RB[4] = 1 and making RF1 interrupting.

If T1 >= R13 , then setting RB[5] = 1 and making RF2 interrupting.

If T2 >= R10 , then setting RB[4] = 0 and making RF1 interrupting.

If T2 >= R12 , then setting RB[5] = 0 and making RF2 interrupting.

After interrupting. The program will check Timing Count & save state.

R10 : The low signal counter of the 1st RF module that inputted from P92.

R11 : The high signal counter of the 1st RF module that inputted from P92.

R12 : The low signal counter of the 2nd RF module that inputted from P93.

R13 : The high signal counter of the 2nd RF module that inputted from P93.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.8 Pulse Width Modulation (PWM)

8.8.1 Function

Description

In PWM mode, both of PWM1 (P.92) and PWM2 (P.93) produce plus programmable signal

of up to 8-bits resolution.

The PWM Period is defined as 0xFF * Timer Counter Clock. The Timer Counter clock

source is controlled by an extra control register, ERE. For example; if the Clock source is
1MHz, then the Period will be 255u seconds.

Period = 255 * (1/Timer Counter Clock)

Period (0xFF * Clock)

Duty Cycle

Fig.8.9.2 The PWM Output Timing

8.8.2 Duty

Cycle

The PWM duty cycle is defined by writing to the R10/R11 Register for PWM1/PWM2.

Duty Cycle = ( R10 / 255 ) * 100% for PWM1

( R11 / 255 ) * 100% for PWM2

8.8.3 Control

Register

R10 ( PWM1 Duty Cycle Register)

A specified value keeps the output of PWM1 to remain at high in a Period.

R11 ( PWM2 Duty Cycle Register)

A specified value keeps the output of PWM2 to remain at high in a Period.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

ERE(PWM Control Register) Default Value: (0B_0000_0001)

7 6 5 4 3 2 1 0

PEN2

PEN1

- - -

PS2

PS1

PS0

ERE [0~2] PWM Clock Prescaler.

PS2

PS1

PS0

Clock(Hz)

Period/255 (s)

0 0 0

Fosc/3

0.5u

0 0 1

Fosc/6

0 1 0

Fosc/12

0 1 1

Fosc/24

1 0 0

Fosc/48

1 0 1

Fosc/96

16u

1 1 0

Fosc/192

32u

1 1 1

Fosc/384

64u

ERE [6,7] PWM1/PWM2 Enable Bit

0:Disable

1:Enable

8.9 Analog-To-Digital Converter (ADC)

8.9.1 Function

Description

The Analog to Digital converter consists of a 5-bit analog multiplexer, one Control Register

(ERA), and two data registers (RBS & RCS) for 10-bit resolution.

The ADC module utilizes successive approximation to convert the unknown analog signal to

a digital value. The result is fed to the ADDATA. Input channels are selected by the analog
input multiplexer via the ADCS/RAS bits AD0~AD4.

10-bit resolution: 0x00-00~0xC0-FF (0b11000000-11111111)

Start (0x00-00): 0 Vref~(1/1024)*Vref

Full (0xC0-FF): (1023/1024)*Vref~Vref

Converting Time: 12 clock time of internal clock source

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

8.9.2 Control

Register

ERA (AD Channel Select Register) Default Value: (0B_0001_1111)

7 6 5 4 3 2 1 0

ADC 0

0 AD4 AD3 AD2 AD1 AD0

ERA [0~4]:AD Channel Selector

AD4

AD3

AD2

AD1

AD0

Channel

I/O Port

0 0 0 0 0 0

P50

0 0 0 0 1 1

P51

0 0 0 1 0 2

P52

0 0 0 1 1 3

P53

0 0 1 0 0 4

P54

0 0 1 0 1 5

P55

0 0 1 1 0 6

P56

0 0 1 1 1 7

P57

0 1 0 0 0 8

P80

0 1 0 0 1 9

P81

0 1 0 1 0 10 P82
0 1 0 1 1 11 P83
0 1 1 0 0 12 P84
0 1 1 0 1 13 P85
0 1 1 1 0 14 P86
0 1 1 1 1 15 P87
1 0 0 0 0 16 P60
1 0 0 0 1 17 P61
1 0 0 1 0 18 P62
1 0 0 1 1 19 P63
1 0 1 0 0 20 P64
1 0 1 0 1 21 P65
1 0 1 1 0 22 P66
1 0 1 1 1 23 P67

ERA [7] AD Converter ready flag.

0 1: Start AD Converting (set by firmware).

1 0: When AD finishes converting and has moved digital data into AD Data Register,

this bit will be set by hardware.

[NOTE] Hardware can enable this function only at AD Channel Selector of the functional I/O

port. After Power-on reset, the initial value of this register is 0b0001 1111.

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

ERB (AD LSB Data Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

Bit 1

Bit 0

AD Digital Data LSB 8 bits.

ERC (AD MSB Data Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0

Bit 9

Bit 8

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

AD Digital Data MSB 2 bits.

ERD (AD Control Register) Default Value: (0B_0000_0000)

7 6 5 4 3 2 1 0
0 0 0 0 0 -

ADPS1

ADPS0

ERD [0 1]:The clock source of AD converting time.

00: 256kHz

01: 128kHz

10: 64kHz

11: 32kHz

9. Absolute Maximum Ratings

Symbol

Min

Max

Unit

Temperature under bias

�C

Storage temperature

-65

150

�C

Input voltage

-0.5

6.0

Output voltage

-0.5

6.0

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

10. DC Electrical Characteristic

(T = 25�C, V

=5V, V

=0V)

Symble

Parameter

Condition

Min Type Max

Unit

3.3V Regulator

Rag

Output voltage of 3.3v Regulator

= 4.4V ~ 5.25V

3.0

3.3

3.6

ResetL

Low Power Reset detecting low Voltage

2.2

ResetH

Low Power Reset detecting high
Voltage

3.0

MCU operating

Input Leakage Current for input pins

VIN=VDD,VSS

�

IHX

Clock Input High Voltage

OSCI

2.5

ILX

Clock Input Low Voltage

OSCI

1.0

CC1

VDD operating supply current �
Normal frequency operation mode

Crystal type
Freq. = 6MHz
Output pins floating

- - 10

CC2

VDD operating supply current �
Normal frequency operation mode

Crystal type
Freq. = 12MHz
Output pins floating

- - 20

CC3

VDD operating supply current �
Dual clock mode

RC oscillation type
Freq. = 256kHz
Ouput pins floating

- -

250

SB1

Operating supply current 1 � Power
down mode

All input and I/O pins at VDD
Output pins floating
WDT disabled

- - 80

SB2

Operating supply current 2 � Power
down mode

All input and I/O pins at VDD
Output pins floating
WDT enable

- -

100

GPIO Pins

Input High Voltage

Port 5 & Port 6 & Port 7 &
Port 8 & Port 9

2.0 - - V

Input Low Voltage

Port 5 & Port 6 & Port 7 &
Port8 & Port 9

- - 0.8

OH1

Output High Voltage
(P70~P73,P76 and P77)

Sink

= 10.0mA

= 5V

2.4 V

OH2

Output High Voltage
(P74, P75)

Sink

= 5.0mA

= 5V

2.4 V

OH3

Output High Voltage
(Port5 & Port6 & Port8 and P90~P93,
P95, P96)

Sink

= 10.0mA

REG

= 3.3V

2.4 V

OL1

Output Low Voltage
(P76 and P77 normal mode)

Sink

= 10.0mA

= 5V

0.4 V

OL2

Output Low Voltage
(P74, P75)

Sink

= 5.0mA

= 5V

0.4 V

OL3

Output Low Voltage
(P70~P73,P76 and P77 sink LED)

Sink

= 10.0mA

= 5V

3 V

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

This spec. may change without further notice

06/ 18/ 2003(V1.0)

OL4

Output Low Voltage
(P90 ~ P96 normal mode)

Sink

= 10.0mA

REG

= 3.3V

0.4 V

OL5

Output Low Voltage
(P90 ~ P96 sink LED)

Sink

= 10.0mA

REG

= 3.3V

1 V

PH1

Input current with pull-high resister
( Port 5, 6, 8, P.90 ~ P.93, P.95 ~ P.96)

Input pin with pull-high
resistor (25kOhm)
V

= V

125

PH2

Input current with pull-high resister
( P.74 ~ P.77)

Input pin with pull-high
resistor (2.2kOhm)
V

= V

2.27 mA

USB Interface

Static Output High

2.8

3.6

Static Output Low

0.3

Differential Input Sensitivity 0.2

Differential Input Command Mode
Range

USB operation Mode

0.8 - 2.5

Single Ended Receiver Threshold

0.8

2.0

Transceiver

Capacitance

- - 20

Output Voltage of Internal Regulator

USB operation Mode

3.0 - 3.6

EM78M611

Universal Serial Bus Microcontroller Series

Preliminary

06/ 18/ 2003(V1.0)

This spec. may change without further notice

Printed in Taiwan, ROC, 05/2003

The contents of this specification are subject to change without notice. ELAN Microelectronics assumes no
responsibility for errors that may appear in this specification. ELAN Microelectronics makes no commitment
to update, or to keep current, the information contained in this specification. The products described herein
are not intended for use in life support appliances, devices, or systems. Use of ELAN Microelectronics
products in such applications are not supported and is prohibited.

NO PART OF THIS SPECIFICATION MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM OR BY
ANY MEANS WITHOUT THE EXPRESS WRITTEN PERMISSION OF ELAN MICROELECTRONICS.

ELAN MICROELECTRONICS CORPORATION

Headquarters:

No. 12, Innovation Road 1,
Science-based Industrial Park,
Hsinchu, Taiwan, R.O.C.
Tel: +886 3 5639977
Fax: +886 3 5639966

http://www.emc.com.tw

Hong Kong Office:

Rm. 1005B, 10/F Empire Centre
68 Mody Road, Tsimshatsui
Kowloon , HONG KONG
Tel: +852 2838-8715
Fax: +852 2838-0497

Электронный компонент: EM78M611

Document Outline
