+15V
RF IN
RF OUT
2.1
1.9
1.7
1.5
1.3
1.1
B r o a d b a n d L N A
Parameter
Min Typ
Max Units
Conditions
Operating Frequency
6
12
GHz
DC Current
100
mA
At +15 VDC Supply
Gain
18.5
19.5
dB
Isolation (S12)
30
33
dB
Noise Figure
1.9
2.1
dB
VSWR In /Out
1.5/1
1.8/1
Impedance
50
Ohms
Intercept Points
2nd
31
dBm
3rd
21
dBm
RF Power
Output
+11
+13
dBm
1dB Compression
Input
+20
dBm
Operating Temperature
-40
+25
+85
C
TA
G U A R A N T E E D P E R F O R M A N C E
Rev. N/D / Iss. 2
Removable SMA Connectors
1.31
2X 1.062
2X .13
2X .20
2X .250
2X .32
3X .19
.30
2X .38
.66
PART IDENTIFICATION
CONNECTOR,
SMA FEMALE
2 PLACES
.10
TERMINAL, SOLDER
.093 DIA THRU
MOUNTING HOLE
4 PLACES
.65
RF IN
RF OUT
+15V
.xx = .02
.xxx = .010
