"J" LEADED SMD CRYSTAL CLOCK OSCILLATORS
MODEL CN 3.3VDC
CP 5.0VDC
M o d e l
M o d e l
M o d e l
M o d e l
M o d e l
Operating Temperature Range
Frequency Range
Frequency Stability
Symmetry
Rise & Fall Time (Tr, Tf)
Logic "1"
Current Consumption
100ppm Standard, Optional Tolerances Available
C N
C N
C N
C N
C N
C P
C P
C P
C P
C P
Output Load
Aging
Enable Input (optional)
Enable - Logic "1" 2.0VDC Min
Disable - Logic "0" 0.5VDC Max
1.0MHz ~ 70.000MHz
0
o
C ~ +70
o
C Extended Temperature Ranges Available
5nSec Max
1.0MHz to 20.0MHz : 5mA ~ 15mA
20.0MHz to 70.0MHz : 15 mA ~ 40mA Max
1.0MHz ~ 70.000MHz
100ppm Standard, Optional Tolerances Available
Storage Temperature Range
-55
o
C ~ +125
o
C
Supply Voltage
+ 3.3VDC + 10%
+ 5.0VDC + 10%
60/40 @ 50% Vcc
Optional Tolerances Available
60/40 @ 50%
Optional Tolerances Available
6nSec Max
2.9VDC Min
4.5VDC Min
Logic "0"
0.5VDC Max
0.5VDC Max
10 TTL / 15pF
10 TTL / 15pF
< 5ppm per year
< 5ppm per year
Enable - Logic "1" 2.0VDC Min
Disable - Logic "0" 0.5VDC Max
-55
o
C ~ +125
o
C
0
o
C ~ +70
o
C Extended Temperature Ranges Available
1.0MHz to 20.0MHz : 5mA ~ 15mA
20.0MHz to 70.0MHz : 15 mA ~ 40mA Max
CN "J" Lead SMD
#1
N.C. or E/D (TriState)
#2
GND
#3
OUTPUT
#4
3.3VDC + 10%
CP "J" Lead SMD
#1
N.C. or E/D (TriState)
#2
GND
#3
OUTPUT
#4
5VDC + 10%
DIMENSIONS
Inches
(mm)
