Available on Tape
and Reel For Pick and
Place Manufacturing.
USA/Canada:
Toll Free:
Europe
:
(315) 432-8909
(800) 544-2414
+44 2392-232392
Model 1F1305-3
Rev. A
Hybrid Couplers
3 dB, 90
Description
The 1F1305-3 is a low profile 3dB hybrid coupler in an easy to use surface
mount package specifically designed for the PCS frequencies. The
1F1305-3 is ideal for balanced amplifiers and signal distribution and can be
used in most high power designs. Parts have been subjected to rigorous
qualification testing and units are 100% tested. They are manufactured
using materials with x and y thermal expansion coefficients compatible with
common substrates such as FR4, G-10 and polyamide.
ELECTRICAL
SPECIFICATIONS**
Frequency
Isolation
Insertion
Loss
VSWR
GHz
dB Min
dB Max
Max:1
1.93 1.99
21
0.23
1.17
Amplitude
Balance
Phase
Balance
Power
JC
Operating
Temp.
dB Max
Degrees
Ave. CW Watts
C/ Watt
C
Features:
1.93 1.99 GHz
Low loss
High Isolation
90 Quadrature
Surface Mountable
Tape And Reel
Convenient Package
100% Tested
0.15
2
100
14.6
-55 to +85
**Specification based on performance of unit properly installed on microstrip printed circuit boards
with 50
nominal impedance. Specifications subject to change without notice.
Outline Drawing
1F1305-3 Rev A Mechanical Outline
Dimensions are in Inches [Millimeters]
Bottom View (Far-side)
Side View
Top View (Near-side)
.076
.008
[1.93
0.20
]
.560
.010
[14.22
0.25
]
.350
.010
[8.89
0.25
]
.050
.008
[1.27
0.20
]
.050
.008
[1.27
0.20
]
Pin 4
Pin 4
Pin 3
Pin 1
Pin 2
Denotes
Array Number
GND
GND
Pin 2
Pin 1
Pin 3
.024
.004
TYP
[0.61
0.10
]
Part Is Symmetric About All Axis
USA/Canada:
Toll Free:
Europe:
(315) 432-8909
(800) 544-2414
+44 2392-232392
Available on Tape and
Reel For Pick and Place
Manufacturing.
Model 1F1305-3
Rev. A
Typical Performance: 1.8 GHz. to 2.1 GHz.
Pin Configuration
Mounting Footprint
To ensure proper electrical and thermal performance
there must be a ground plane with 100%
solder connection underneath the part
.063 SQ TYP
[1.60]
50
Transmission
Line
Dimensions are in Inches [Millimeters]
1F1305-3 Rev A Mounting Footprint
.250
[6.35]
.460
[11.68]
Part Is Symmetric About All Axis
.034 TYP
[0.86]
Multiple
plated thru holes
to ground
Coupling 1F1305-3
-4
-3.7
-3.4
-3.1
-2.8
-2.5
1800
1900
2000
2100
Frequency (MHz)
C
oup
l
i
n
g (
d
B
)
Return Loss 1F1305-3
-50
-40
-30
-20
-10
0
1800
1900
2000
2100
Frequency (MHz)
R
e
tu
rn
L
o
s
s
(d
B
)
Isolation 1F1305-3
-50
-40
-30
-20
-10
1800
1900
2000
2100
Frequency (MHz)
I
s
o
l
at
i
on (
d
B
)
Phase Balance 1F1305-3
-93
-92
-91
-90
-89
-88
-87
1800
1900
2000
2100
Frequency (MHz)
P
h
a
s
e
B
a
l
a
nc
e (
D
eg
r
e
es
)
