Model 1A1306-20
Rev. A
Directional Couplers
20 dB
Description
The 1A1306-20 is a low profile 20dB directional coupler in an easy to use
surface mount package for PCS, ISM and wireless LAN applications. The
1A1306-20 is ideal for frequency detection and VSWR monitoring and can
be used in most high power designs. They have been subjected to
rigorous qualification testing and units are 100% tested. Parts are
manufactured using materials with x and y thermal expansion coefficients
compatible with common substrates such as FR4, G-10 and polyamide.
ELECTRICAL
SPECIFICATIONS**
Frequency
Mean
Coupling
Insertion
Loss
VSWR
Freq.
Sensitivity
GHz
dB
dB Max
Max:1
dB Max
2.2 2.6
21.0 1.0
0.30
1.40
0.20
1.8 - 2.7
21.0 1.0
0.30
1.40
0.30
Directivity
Power
Handling
JC
Operating
Temp.
dB Min
Watts
C / Watt
C
17
60
20.8
-55 to +85
Features:
1.8 - 2.7 GHz
Low loss
High Directivity
Surface Mountable
Tape And Reel
Convenient Package
100% Tested
16
60
20.8
-55 to +85
**Specification based on performance of unit properly installed on microstrip printed circuit
boards with 50
nominal impedance. Specifications subject to change without notice.
Outline Drawing
1A1306-20 Rev A Mechanical Outline
Dimensions are in Inches [Millimeters]
Bottom View (Far-side)
Side View
Top View (Near-side)
.073
.007
[1.85
0.18
]
.560
.010
[14.22
0.25
]
.350
.010
[8.89
0.25
]
.050
.008
[1.27
0.20
]
.050
.008
[1.27
0.20
]
Pin 4
Pin 4
Pin 3
Pin 1
Pin 2
Denotes
Array Number
GND
GND
Pin 2
Pin 1
Pin 3
.024
.004
TYP
[0.61
0.10
]
Part Is Symmetric About All Axis
USA/Canada:
Toll Free:
Europe:
(315) 432-8909
(800) 544-2414
+44 2392-232392
Available on Tape and
Reel For Pick and Place
Manufacturing.
Model 1A1306-20
Rev. A
Typical Performance: 1.6 GHz. to 2.8 GHz.
Pin Configuration
Mounting Footprint
To ensure proper electrical and thermal performance
there must be a ground plane with 100%
solder connection underneath the part
.063 SQ TYP
[1.60]
50
Transmission
Line
Dimensions are in Inches [Millimeters]
1A1306-20 Rev A Mounting Footprint
.250
[6.35]
.460
[11.68]
Part Is Symmetric About All Axis
.034 TYP
[0.86]
Multiple
plated thru holes
to ground
Coupling 1A1306-20
-23
-22
-21
